| Ref | Part Number | Description |
|---|
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
532178557 |
AXLE.FRONT.CAST.MACHINE.W/ZERK Price: $179.99 |
| 3 |
132-3468 |
DUCT-A/C Price: $1,135.16 |
| 3 |
532183226 |
FITTING.GREASE.TAPERED This part replaces 532124836. Price: $4.99 |
| 4 |
132-3488 |
PANEL-FAN Price: $664.03 |
| 4 |
532161849 |
SPINDLE ASSY LH Price: $27.99 |
| 5 |
532161848 |
SPINDLE ASM RH Price: $24.99 |
| 6 |
132-3531-03 |
SEAL-FRONT Price: $33.28 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
132-3532-03 |
SEAL-REAR Price: $27.57 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
132-3533-03 |
SEAL-SIDE, LEFT Price: $25.48 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
132-3534-03 |
SEAL-SIDE, RIGHT Price: $31.14 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
104-7201 |
NUT-HF Price: $0.69 |
| 10 |
874781044 |
Bolt, Hex 5/8 -11 x 2 - 3/4 Gr. 5 Price: $3.99 |
| 11 |
121-8457 |
FILTER-AIR Price: $34.12 |
| 11 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 12 |
107069 |
CLIP Price: $1.79 |
| 12 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 13 |
126-5846 |
KNOB-T Price: $9.75 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
125-9825-03 |
COVER-AIR, FRESH Price: $80.77 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
3230-9 |
SCREW-CARR Price: $0.68 |
| 15 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 16 |
3230-22 |
SCREW-CARR Price: $1.99 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 17 |
532186799 |
ROD.TIE.NON-ADJUSTABLE This part replaces 532137347. Price: $59.99 |
| 18 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 18 |
532175572 |
DRAGLINK, BALL JOINT (3SPG1401 Price: $64.99 |
| 19 |
32115-15 |
PUSHNUT-RETAINER, BOLT This part replaces 106-8737. Price: $0.99 |
| 19 |
532156011 |
SUPPORT ASM., STEERING VGT Price: $22.99 |
| 20 |
130-5871 |
BRACKET-WIPER Price: $42.69 |
| 20 |
532163887 |
BOOT.STEERING.BLACK.STEALTH This part replaces 532177592. Price: $5.99 |
| 21 |
125-7452 |
WIPER MOTOR ASM Price: $435.07 |
| 21 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 22 |
125-7453 |
ARM-WIPER Price: $121.52 |
| 22 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 23 |
125-7454 |
BLADE-WIPER Price: $49.61 |
| 23 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 24 |
120-4654 |
SCREW-HHF Price: $0.34 |
| 25 |
32105-15 |
SCREW-HWH Price: $1.79 |
| 25 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 26 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 26 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 27 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 28 |
117-5976 |
KNOB-HANDLE Price: $2.17 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
130-5661 |
TUBE-SLEEVE Price: $37.14 |
| 29 |
532104239 |
BEARING-FLANGE GT Price: $9.99 |
| 30 |
3229-30 |
SCREW-CARR Price: $1.39 |
| 31 |
130-5854 |
BRACE-SEAL Price: $4.07 |
| 31 |
532138136 |
BUSHING.NYLINER. Price: $8.99 |
| 32 |
363-8245 |
SCREW-TAP Price: $0.66 |
| 32 |
819111610 |
WASHER Price: $4.99 |
| 33 |
132-3608 |
SEAL-EDGE Price: $2.50 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
132-3609 |
SEAL-STRIP Price: $4.11 |
| 34 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 35 |
531165701 |
SERVICE KIT GEAR.ASM.SECT This part replaces 532138059. Price: $49.99 |
| 36 |
532186799 |
ROD.TIE.NON-ADJUSTABLE This part replaces 532137156. Price: $59.99 |
| 37 |
873360600 |
NUT Price: $4.99 |
| 38 |
532121160 |
JOINT.RH This part replaces 532109850. Price: $19.99 |
| 39 |
873700600 |
NUT Price: $2.99 |
| 40 |
532109851 |
JOINT.LH Price: $27.99 |
| 41 |
532155246 |
BRACKET INTERLOCK Price: $4.99 |
| 42 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 44 |
532160135 |
EXT.STEERING.PREM.BLACK This part replaces 532177593. Price: $4.99 |
| 45 |
819132411 |
Washer 13/32 x 1-1/20 x 11 Gauge Price: $2.99 |
| 46 |
819131610 |
WASHER PM Price: $4.99 |
| 47 |
529846001 |
SERVICE.KIT BRKT.ASM.IDLER.STA This part replaces 532177863. Price: $7.99 |
| 48 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 49 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
