| Ref | Part Number | Description |
|---|
| 1 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 1 |
KH-25-100-15-S |
WING NUT 1/4-20 Not Available This part replaces KH-X-276-7. Price: |
| 2 |
98-4517 |
AIR CLEANER ASM Price: $272.15 |
| 2 |
KH-220537 |
GASKET Not Available Price: |
| 3 |
93-6692 |
DISCONTINUED Price: Call Us |
| 3 |
KH-231847-S |
AIR CLEANER ELEMENT Not Available This part replaces KH-231847. Price: |
| 4 |
48-7430 |
PRECLEANER Price: $50.85 |
| 4 |
KH-231855 |
COVER, AIR CLEANER Not Available Price: |
| 5 |
None |
Base, Air Cleaner |
| 5 |
98-4578-03 |
BRACKET-FILTER, FUEL Price: $35.38 |
| 6 |
None |
Baffle, Side Air |
| 6 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 7 |
None |
Baffle, Cylinder |
| 7 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 8 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 8 |
KH-234796 |
BAFFLE Not Available Price: |
| 9 |
32128-33 |
NUT-HF Price: $0.25 |
| 10 |
98-4525 |
BRACKET-CLEANER, AIR Price: $52.87 |
| 10 |
KH-230043 |
Stud, Valve Cover Price: Call Us |
| 11 |
322-4 |
SCREW-HH Price: $0.35 |
| 11 |
KH-230046 |
SEAL Not Available Price: |
| 12 |
66-2750 |
DISCONTINUED Price: Call Us |
| 12 |
KH-230048 |
GASKET Not Available Price: |
| 13 |
104-0086 |
CABLE-BATTERY, POSITIVE Price: $78.07 |
| 13 |
KH-230066 |
BREATHER Not Available Price: |
| 14 |
None |
Cover Assy, Valve |
| 14 |
323-9 |
SCREW-HH Price: $1.29 |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 15 |
KH-231419-S |
FILTER Not Available This part replaces KH-231419. Price: |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
KH-230008 |
VALVE Not Available Price: |
| 17 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 17 |
KH-230010 |
SPRING Not Available Price: |
| 18 |
94-7343 |
BASE-BATTERY Price: $118.61 |
| 18 |
KH-230011 |
RETAINER-SPRING Not Available Price: |
| 19 |
None |
Tappet, Intake Valve |
| 19 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 20 |
93-7276 |
DECAL-DANGER Price: $15.13 |
| 20 |
KH-230293 |
SPACER Not Available Price: |
| 21 |
32128-20 |
NUT-HF Price: $0.99 |
| 21 |
KH-230710 |
VALVE Not Available Price: |
| 22 |
98-4576-03 |
BRACKET-RESERVOIR, WATER Price: $43.21 |
| 22 |
KH-41-380-03 |
PIN, CAMSHAFT Not Available Price: |
| 23 |
321-5 |
SCREW-HH Price: $0.22 |
| 23 |
KH-A-230155-S |
KIT-CAMSHA Not Available Price: |
| 24 |
93-9164 |
INDICATOR-MINI Price: $55.24 |
| 24 |
KH-47-089-01 |
SPRING Not Available Price: |
| 25 |
None |
Tappet, Exhaust Valve |
| 25 |
98-4518-03 |
BRACKET-CLEANER, AIR Price: $75.61 |
| 26 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 27 |
94-1416 |
ADAPTER-INDICATOR Price: $11.87 |
| 27 |
IH-401967-R1 |
ELBOW Not Available Price: |
| 28 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 28 |
KH-210223 |
GASKET Not Available Price: |
| 29 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 29 |
KH-41-853-08 |
CARBURETOR ASSEMBLY Not Available Price: |
| 30 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 30 |
KH-232683 |
BRACKET Not Available Price: |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 31 |
KH-235603 |
CLIP-CHOKE CABLE Not Available Price: |
| 32 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 98-9323. Price: $33.20 |
| 32 |
IH-172548 |
Plug, Expansion Price: Call Us |
| 33 |
98-4509 |
HOSE-CLEANER, AIR Price: $97.00 |
| 33 |
KH-X-583-1 |
OIL SEAL Not Available Price: |
| 34 |
98-9305 |
WATER / FUEL FILTER ASM Price: $116.51 |
| 34 |
KH-X-583-2 |
OIL SEAL Not Available Price: |
| 35 |
353-783 |
FITTING-STR Price: $29.05 |
| 35 |
KH-230071 |
GASKET Not Available Price: |
| 36 |
322-6 |
SCREW-HH Price: $0.45 |
| 36 |
KH-230125-S |
SHAFT-GOVE Not Available Price: |
| 37 |
106-1126 |
HOSE-FUEL This part replaces 71-3381. Price: $10.06 |
| 37 |
941-3033A |
Bearing, Ball This part replaces IH-ST429. Price: $50.07 |
| 38 |
110-4107 |
HOSE-FUEL This part replaces 95-4275. Price: $7.77 |
| 39 |
KH-B-238001 |
Mini Block Assy Price: Call Us |
| 40 |
KH-230007-S |
GUIDE Not Available Price: |
| 41 |
KH-230170 |
INSERT Not Available Price: |
| 42 |
KH-231767 |
CRANKSHAFT Not Available Price: |
| 43 |
None |
Stud |
| 44 |
KH-220534 |
WASHER-CYLINDER HE Not Available Price: |
| 45 |
KH-41-041-10 |
GASKET Not Available Price: |
| 46 |
KH-41-086-02 |
SCREW Not Available This part replaces IH-454871. Price: |
| 47 |
KH-41-755-25 |
KIT-CYLINDER HEAD Not Available Price: |
| 48 |
KH-234847 |
SPACER Not Available Price: |
| 49 |
KH-A-231725 |
DIPSTICK ASSEMBLY Not Available Price: |
| 50 |
KH-231726 |
TUBE Not Available Price: |
| 51 |
712-0250 |
CONDUIT L-NUT Not Available Price: |
| 52 |
KH-230410 |
MUFFLER Not Available Price: |
| 53 |
KH-231820-S |
ELBOW Not Available This part replaces KH-231820. Price: |
| 54 |
KH-X-286-17 |
KEY Not Available This part replaces IH-532004-R1. Price: |
| 55 |
KH-41-071-04 |
CUP ASSEMB Not Available Price: |
| 60 |
KH-52-041-17 |
GASKET, FUEL PUMP Not Available Price: |
| 61 |
KH-240282 |
COVER-FUEL Not Available Price: |
| 62 |
None |
Pin |
| 63 |
KH-230078 |
LINKAGE Not Available Price: |
| 64 |
KH-230476 |
BUSHING Not Available Price: |
| 65 |
KH-230477 |
BRACKET Not Available Price: |
| 66 |
KH-230540-S |
SHAFT Not Available Price: |
| 67 |
KH-231355-S |
PIN Not Available This part replaces KH-231355. Price: |
| 68 |
KH-234866 |
BEARING Not Available Price: |
| 69 |
KH-230149 |
DISC Not Available Price: |
| 70 |
KH-A-235743-S |
GEAR Not Available Price: |
| 71 |
KH-232614 |
LEVER Not Available Price: |
| 72 |
KH-232617 |
SPRING Not Available Price: |
| 73 |
KH-230540-S |
SHAFT Not Available This part replaces IH-55170-C1. Price: |
| 74 |
KH-41-411-01 |
ROD Not Available Price: |
| 75 |
KH-52-041-11-S |
GASKET Not Available This part replaces KH-52-041-11. Price: |
| 76 |
KH-47-150-03 |
Breaker Assy Price: $22.85 |
| 77 |
KH-47-150-03 |
Bracket, Breaker Point Price: $22.85 |
| 78 |
KH-47-150-03 |
Points Price: $22.85 |
| 79 |
KH-230249 |
CLIP Not Available Price: |
| 81 |
KH-47-150-03 |
Cover, Breaker Price: $22.85 |
| 82 |
759-3339 |
SPARK PLUG J8C Not Available This part replaces IH-J8C. Price: |
| 89 |
KH-25-139-57-S |
Plug, Sq. Hd. Solid 3/8" This part replaces KH-X-75-10. Price: $2.29 |
| 90 |
KH-41-041-03 |
GASKET Not Available Price: |
| 91 |
KH-41-199-08 |
PAN Not Available Price: |
| 92 |
KH-232575 |
KIT-PISTON RING Not Available Price: |
| 93 |
KH-41-874-05 |
PISTON W/RINGS KIT Not Available Price: |
| 94 |
KH-230004 |
RETAINER Not Available Price: |
| 95 |
None |
Pin, Piston, Std |
| 96 |
KH-41-067-10 |
ROD Not Available Price: |
| 97 |
KH-230525 |
LOCK-CONNE Not Available Price: |
| 98 |
None |
Screw, Connecting Rod |
| 99 |
IH-263515-R91 |
Clip, Choke Cable Price: Call Us |
| 501527801 |
501527801 |
BUSHING Price: $3.99 |
| 501770002 |
501770002 |
GASKET Price: $4.99 |
| 503105202 |
503105203 |
CHOKE CONTROL This part replaces 503105202. Price: $5.99 |
| 503213216 |
503213216 |
SCREW Price: $2.99 |
| 503281320 |
503281320 |
CARBURETOR Price: $89.99 |
| 503413101 |
503413101 |
FILTER HOLDER Price: $22.99 |
| 503413203 |
503413203 |
AIR FILTER Price: $12.99 |
| 505310751 |
505310751 |
IMPULSE PIPE Price: $8.99 |
| 506013502 |
503786601 |
HEATSHIELD This part replaces 506013502. Price: $12.99 |
| 729213245 |
729213245 |
Price: Call Us |
