| Ref | Part Number | Description |
|---|
| 1 |
None |
Frame Assy, Front Outlets |
| 1 |
532184588 |
DRIVE CONTROL 59.8 FWGD Price: $44.99 |
| 1 |
57-5420 |
SCREW-SHOULDER Price: $5.89 |
| 2 |
588636301 |
BEARING ASM. This part replaces 532088058. Price: $5.99 |
| 2 |
69-1170 |
GLASS-SIGHT Price: $31.63 |
| 3 |
2414-36 |
Clamp-Hose Price: Call Us |
| 3 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 3 |
913-3000 |
CHAIN LINK Not Available This part replaces 713-3000. Price: |
| 4 |
532158755 |
SCREW.PAN.HEAD Price: $4.99 |
| 4 |
93-6793 |
FITTING-BARB Price: $95.69 |
| 4 |
IH-9411104 |
Elbow, 9/16-18 C-Z 37 Deg Hyd Flared Tube Adj Str Thd 45 Deg Price: Call Us |
| 5 |
32128-44 |
NUT Price: $2.69 |
| 5 |
532175436 |
BELT.DRIVE.21FGD.1SPEED Price: $19.99 |
| 5 |
721-3001 |
O-Ring, 3/8 OD Tube Price: $3.15 |
| 6 |
532150495 |
SPRING RETAINER Price: $3.99 |
| 6 |
93-7160 |
CAP-OIL, HYD Price: $42.72 |
| 6 |
IH-106875-C1 |
TUBE Not Available Price: |
| 7 |
532191730 |
NUT.HEX.FLANGE.1/4 Price: $3.99 |
| 7 |
61-2790 |
FILTER-SCREEN Price: $49.91 |
| 7 |
IH-106874-C1 |
Shaft Assy, Valve Handle Price: Call Us |
| 8 |
106-8111 |
DISCONTINUED This part replaces 93-6811. Price: Call Us |
| 8 |
532150182 |
CAP.HUB.ARC.SPOKE.8".LP This part replaces 532180626. Price: $3.99 |
| 8 |
IH-61702-C1 |
HANDLE Not Available Price: |
| 9 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 9 |
83-9920 |
BRACKET-TANK, HYD Price: $15.71 |
| 9 |
IH-106266-C1 |
HUB Not Available Price: |
| 10 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 10 |
IH-396454-R1 |
GRIP Not Available Price: |
| 11 |
532180775 |
WHEEL.8X2.PR.LP.RADII.BLACK.BU This part replaces 532180767. Price: $29.99 |
| 11 |
63-8410 |
WASHER Price: $1.76 |
| 11 |
IH-106877-C1 |
TUBE Not Available Price: |
| 12 |
323-5 |
SCREW-HH Price: $0.41 |
| 12 |
812000058 |
E-RING 7/16 RE Price: $2.99 |
| 12 |
IH-106878-C1 |
Tube, Pressure Supply Lower Price: Call Us |
| 13 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 13 |
532137054 |
PINION GEAR Price: $4.99 |
| 13 |
727-3014 |
Coupling Body, Hydraulic This part replaces IH-166122-C92. Price: $93.34 |
| 14 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 14 |
581840401 |
COVER.DUST.WHEEL.INNER.WALK This part replaces 532189403. Price: $5.99 |
| 14 |
716-3014 |
RING, EXTERNAL RET Not Available Price: |
| 15 |
83-9651 |
DISCONTINUED Price: Call Us |
| 15 |
IH-9402708 |
CONNECTOR Not Available Price: |
| 16 |
354-127 |
FITTING-ELBOW45 Price: $55.53 |
| 16 |
532067725 |
WASHER FLUT Price: $5.99 |
| 16 |
731-3022 |
Plug, Protective Price: $17.67 |
| 17 |
94-3633 |
U-BRACKET ASM Price: $73.76 |
| 17 |
IH-106876-C1 |
TUBE Not Available Price: |
| 18 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 18 |
532185574 |
SELECTOR KNOB Price: $5.99 |
| 19 |
93-6799 |
DISCONTINUED Price: Call Us |
| 19 |
IH-106531-C3 |
LEVER Not Available This part replaces IH-106531-C2. Price: |
| 20 |
54-0110 |
FILTER-OIL, TRANSMISSION Price: $14.20 |
| 20 |
727-3012 |
Elbow, 9/16-18 C-Z 37 Deg Hyd Flared Tube Adj Str Thd 90 Deg Price: $23.35 |
| 21 |
68-8990 |
HEAD-FILTER Price: $153.83 |
| 21 |
927-3002 |
Fitting, Hydraulic Swivel This part replaces 727-3002. Price: $10.88 |
| 22 |
353-987 |
FITTING-ELBOW, 90 Price: $74.72 |
| 22 |
IH-140231-C1 |
Tube, Valve Handle Price: Call Us |
| 23 |
93-6857 |
HOSE-SUCTION Price: $44.37 |
| 24 |
93-6804 |
HOSE Price: $54.29 |
| 25 |
93-6806 |
HOSE-RETURN Price: $18.75 |
| 26 |
237-81 |
O-RING Price: $2.76 |
| 28 |
532432664 |
COVER.DRIVE.ASM.185579.CE.WALK This part replaces 532185579. Price: $19.99 |
| 31 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532132010. Price: $3.99 |
| 32 |
532194126 |
DRIVEN PULLEY This part replaces 532189407. Price: $9.99 |
| 36 |
532180184 |
TRANSMISSION.21.HT.GWGD Price: $99.99 |
| 38 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 40 |
532137090 |
SPRING.EXTENSION Price: $4.99 |
| 54 |
580953406 |
GBAG.34710090.H-GREY MS498 This part replaces 532194724. Price: $54.99 |
| 55 |
532175739 |
DRIVESHAFT COVER Price: $2.94 |
| 57 |
532194643 |
FRAME.GBAG.21.FWGD. This part replaces 532188815. Price: $44.99 |
| 62 |
532183499 |
GEAR.27.TEETH.WALK.MOWER Price: $14.99 |
| 63 |
532183500 |
LEVER, CLUTCH Price: $4.99 |
| 64 |
532183501 |
SPRING, RETURN Price: $4.99 |
| 65 |
532183502 |
SHAFT INPUT (13041) Price: $24.99 |
| 66 |
532183503 |
DOG, MOVABLE (11032) Price: $4.99 |
| 67 |
532183504 |
DOG, FIXED GT11031 Price: $3.99 |
| 68 |
532183505 |
WIRE, FORMED (15966) Price: $5.99 |
| 69 |
532183506 |
BEARING Price: $5.99 |
| 70 |
532183507 |
FORK, SHIFT Price: $7.99 |
| 71 |
532183508 |
SEAL.OUTPUT.SHAFT Price: $9.99 |
| 72 |
532183509 |
WASHER Price: $3.99 |
| 73 |
532183510 |
SEAL, CASE O-RING Price: $4.99 |
| 74 |
532183511 |
BUSHING Price: $4.99 |
| 75 |
532183512 |
SHAFT OUTPUT (12159) Price: $37.99 |
| 76 |
532183513 |
SCREW Price: $3.99 |
