| Ref | Part Number | Description |
|---|
| 1 |
104-3728 |
HYD TUBE ASM Price: $136.98 |
| 1 |
195632X421 |
Deck Weldment Mower Price: Call Us |
| 2 |
104-3731 |
HYD TUBE ASM Price: $108.53 |
| 3 |
340-70 |
NUT-LOCK Price: $2.10 |
| 4 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 5 |
322-4 |
SCREW-HH Price: $0.35 |
| 6 |
196066 |
Cover Mandrel LH Price: Call Us |
| 6 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 7 |
197181 |
Cover Mandrel RH Price: Call Us |
| 7 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 8 |
174365 |
Bolt 7/16 Asm. Blade Price: Call Us |
| 8 |
340-6 |
FITTING-STRAIGHT Price: $18.79 |
| 9 |
104-3734 |
HYD COOLER TUBE ASM Price: $177.34 |
| 10 |
340-105 |
FITTING-ELBOW, 90 DEG Price: $39.67 |
| 11 |
112-6554 |
MOW MANIFOLD BLOCK KIT This part replaces 99-6978. Price: $3,269.67 |
| 11 |
187254 |
Blade High Lift Price: Call Us |
| 11 |
187255 |
Blade Mulching Price: Call Us |
| 11 |
187256 |
Blade Bagging Price: Call Us |
| 12 |
104-3741 |
HYD TUBE ASM Price: $161.92 |
| 12 |
400337 |
Rod Anti-Sway Price: Call Us |
| 13 |
104-3739 |
HYD TUBE ASM Price: $144.97 |
| 13 |
187291 |
Shaft Asm. w/Lower Bearing Price: Call Us |
| 14 |
187281 |
Housing, Mandrel Price: Call Us |
| 14 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
110485X |
Bearing, Ball, Mandrel Price: Call Us |
| 15 |
340-161 |
FITTING-BULKHEAD Price: $72.14 |
| 16 |
104-3723 |
HYD TUBE ASM Price: $145.21 |
| 16 |
19131312 |
Washer 13/32 x 13/16 x 12 Ga. Price: Call Us |
| 17 |
104-3724 |
HYD TUBE ASM Price: $127.31 |
| 18 |
105-7903 |
HYD HOSE ASM This part replaces 99-5613. Price: $174.38 |
| 18 |
72140505 |
Bolt RDHD SQNK 5/16-18 x 4/8 Price: Call Us |
| 19 |
194208 |
Pin Cotter 5/16 Bow Tie Lock Price: Call Us |
| 19 |
99-5614 |
HYD HOSE ASM Price: $103.23 |
| 20 |
104-3732 |
RETURN DRAIN ASM Price: $65.91 |
| 21 |
240-5 |
GROMMET Price: $13.66 |
| 21 |
73680500 |
Nut, Crownlock 5/16-18 unc Price: Call Us |
| 22 |
69-8960 |
SPACER Price: $5.29 |
| 23 |
69-8930 |
WASHER Price: $0.81 |
| 24 |
105304X |
Cap Sleeve Price: Call Us |
| 24 |
56-7972 |
CLAMP-TUBE Price: $13.55 |
| 25 |
178102 |
Spring, Torsion Price: Call Us |
| 25 |
340-154 |
UNION-BULKHEAD Price: $44.48 |
| 26 |
110452X |
Nut, Push Price: Call Us |
| 26 |
354-77 |
FITTING-QUICK Price: $55.94 |
| 27 |
187257X428 |
Defl ector Shield Price: Call Us |
| 27 |
354-79 |
CAP-DUST Price: $7.81 |
| 28 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 29 |
131491 |
Rod, Hinge Price: Call Us |
| 30 |
173984 |
Screw, Thdroll Washer Head Price: Call Us |
| 30 |
94-1402 |
PLUG-HOLE Price: $1.54 |
| 31 |
187690 |
Washer, Spacer Mower Vented Price: Call Us |
| 31 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 32 |
173436 |
Pulley, Mandrel Price: Call Us |
| 32 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 33 |
400234 |
Nut, Flg. Top Lock Price: Call Us |
| 33 |
75-6640 |
FITTING-HYD, SPECIAL Price: $80.34 |
| 34 |
73680600 |
Nut Crownlock 3/8-16 unc Price: Call Us |
| 34 |
98-8199 |
BRACKET-SWITCH Price: $71.51 |
| 35 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 36 |
3256-76 |
WASHER-FLAT Price: $1.42 |
| 37 |
329-3 |
SCREW-HH Price: $0.22 |
| 38 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 39 |
196104 |
Pulley, Idler, Stationary Price: Call Us |
| 39 |
322-7 |
SCREW-HH Price: $0.89 |
| 40 |
340-105 |
FITTING-ELBOW, 90 DEG Price: $39.67 |
| 43 |
196065 |
Arm, Idler Price: Call Us |
| 46 |
137729 |
Screw, Thdroll. 1/4-20 x 5/8 Price: Call Us |
| 47 |
196103 |
V-Belt, Mower Price: Call Us |
| 49 |
73900600 |
Nut, Lock Flg. 3/8-16 unc Price: Call Us |
| 50 |
72110616 |
Bolt Rdhd Sqnk 3/8-16 unc x 2 Price: Call Us |
| 52 |
196106 |
Pulley Idler Clutching Price: Call Us |
| 58 |
187342 |
Baffl e Right Price: Call Us |
| 59 |
187344 |
Baffl e Left Price: Call Us |
| 60 |
187607 |
Baffl e Center Price: Call Us |
| 97 |
178515 |
Washer Hardened Price: Call Us |
| 98 |
196105 |
Spring Drive Price: Call Us |
| 113 |
72110508 |
Bolt Rdhd Sqnk 5/16-18 x 3/4 Price: Call Us |
| 114 |
187556 |
Rod Tension Relief Price: Call Us |
| 116 |
193406 |
Bolt, Shoulder Price: Call Us |
| 117 |
174873 |
Gauge Wheel Price: Call Us |
| 120 |
19132012 |
Washer 13/32 x 1-1/4 x 12 Ga. Price: Call Us |
| 122 |
187557 |
Bushing Tension Relief Price: Call Us |
| 184 |
73900500 |
Nut Lock Hex Flange 5/16-18 Price: Call Us |
| 185 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 187 |
195161 |
Stud Fastener w/"D" Anti-Rotation Price: Call Us |
| 189 |
195185 |
Arm Susp. Mower Rear Price: Call Us |
| 190 |
196539 |
Bolt Shoulder Price: Call Us |
| 192 |
198468 |
Keeper Belt Idler Price: Call Us |
| 194 |
72140716 |
Bolt Carr Sqnk 3/8-16 x 2-1/4 Price: Call Us |
| 196 |
72140620 |
Bolt RDHD SQNK 23/8-16 x 2-1/2 Gr.5 Price: Call Us |
