| Ref | Part Number | Description |
|---|
| 1 |
45061 |
ENGINE DECK WLD Price: Call Us |
| 2 |
45027-01 |
HITCH BRACKET WLD. - RH Price: Call Us |
| 2 |
45027-02 |
HITCH BRACKET WLD. - LH Price: Call Us |
| 7 |
48030-17 |
CLAMP, CABLE - .38 DIA This part replaces 48030-01. Price: Call Us |
| 11 |
04050-02 |
RETAINING RING, 3/4 EXT."E" Price: Call Us |
| 12 |
48104-01 |
BEARING, PILLOW BLOCK Price: Call Us |
| 13 |
04041-08 |
WASHER, 49/64 X 1-1/4 X 16 GA. Price: Call Us |
| 14 |
48114-04 |
Fitting, Grease This part replaces 48114-01. Price: Call Us |
| 16 |
43019-05 |
SPACER - LH AXLE Price: Call Us |
| 17 |
48004 |
WHEEL ASSY 16 X 6.5-8 This part replaces 48004-01. Price: Call Us |
| 17A |
481893 |
Tire Only This part replaces 48004-02. Price: Call Us |
| 17B |
481890 |
Rim Assy This part replaces 48004-04. Price: Call Us |
| 18 |
481892 |
HUB ASSY., WHEEL This part replaces 48004-05. Price: Call Us |
| 19 |
48004-06 |
WHEEL BOLT & WASHER Price: Call Us |
| 20 |
04041-08 |
WASHER, 49/64 X 1-1/4 X 16 GA. Price: Call Us |
| 20A |
04042-03 |
WASHER, 13/16 X 1-3/8 X 3/32 Price: Call Us |
| 21 |
46144 |
IDLER ARM(INCL. 14 & 22) Price: Call Us |
| 22 |
48100-05 |
BRONZE BEARING Price: Call Us |
| 23 |
45014 |
BELT GUIDE Price: Call Us |
| 25 |
48047 |
FOOT CABLE ASSEMBLY Price: Call Us |
| 26 |
43049 |
SLEEVE, FOOT CABLE Price: Call Us |
| 29 |
48046 |
BRAKE CABLE Price: Call Us |
| 30 |
45063 |
BELT GUIDE WLD. Price: Call Us |
| 32 |
48086 |
BELT, BLADE DRIVE SLM40 Price: Call Us |
| 32 |
48088 |
BELT, BLADE DRIVE SLM48 Price: Call Us |
| 33 |
48141 |
Hub, Tapered 1.00" bore This part replaces 48168. Price: Call Us |
| 34 |
48141 |
TAPER HUB Price: Call Us |
| 36 |
48063 |
PULLEY Price: Call Us |
| 38 |
04063-03 |
KEY, 1/4 X 1/4 X 2-1/2 Price: Call Us |
| 39 |
48064 |
PULLEY, TRANSAXLE Price: Call Us |
| 40 |
04063-09 |
KEY, HYPRO #9 Price: Call Us |
| 42 |
48085 |
BELT, TRANSAXLE DRIVE Price: Call Us |
| 43 |
48065 |
PULLEY, IDLER Price: Call Us |
| 44 |
48102 |
BEARING, IDLER PULLEY Price: Call Us |
| 45 |
04050-06 |
RETAINING RING, 1-9/16 INT. BASIC Price: Call Us |
| 46 |
43044 |
SLEEVE, TRANSMISSION IDLER BEARING Price: Call Us |
| 47 |
43039 |
SPACER, TRANSMISSION IDLER Price: Call Us |
| 51 |
45121 |
TRANSAXLE PROTECTOR Price: Call Us |
| 53 |
48160 |
TRANSAXLE Price: Call Us |
| 54 |
04042-02 |
THRUST WASHER Price: Call Us |
| 55 |
43019-06 |
SPACER - RH AXLE Price: Call Us |
| 56 |
42075 |
SPACER, TRANSAXLE Price: Call Us |
| 59 |
04063-04 |
KEY, 3/16 X 3/16 X 2-1/2 Price: Call Us |
| 60 |
42061 |
SHIFT LEVER Price: Call Us |
| 61 |
04001-55 |
HEX HD. BOLT, 1/4-28 X 3/4 GRD.8 Price: Call Us |
| 63 |
04043-01 |
WASHER, 17/64 X 7/8 X 1/8 H.T. Price: Call Us |
| 64 |
48021 |
NEUTRAL SAFETY SWITCH Price: Call Us |
| 65 |
48122-01 |
FIBER WASHER, .010 Price: Call Us |
| 65A |
48122-02 |
FIBER WASHER, .020 Price: Call Us |
| 66 |
48118 |
BALL JOINT Price: Call Us |
| 67 |
04021-06 |
HEX LOCK NUT, 3/8-24 Price: Call Us |
| 68 |
43029 |
SHIFT CONNECTOR ROD Price: Call Us |
| 69 |
45067 |
BELT GUIDE Price: Call Us |
| 71 |
45064 |
TRANSAXLE SUPPORT. Price: Call Us |
| 72 |
48052 |
SPRING, BRAKE RETURN Price: Call Us |
| 73 |
04062-02 |
HAIR PIN, SMALL Price: Call Us |
| 74 |
44015 |
BLADE CLUTCH ROD(GOLD COLOR IS USED W/2 Price: Call Us |
| 75 |
43043 |
SLEEVE Price: Call Us |
| 78 |
04062-01 |
HAIR PIN, LARGE Price: Call Us |
| 80 |
45037 |
PIVOT BASE WLD. Price: Call Us |
| 81 |
48051 |
SPRING, BELT CLUTCH Price: Call Us |
| 82 |
42060 |
BRACKET, SPRING MOUNTING Price: Call Us |
| 83 |
48066 |
PULLEY, BRAKE CABLE Price: Call Us |
| 84 |
43024 |
SPACER, PULLEY Price: Call Us |
| 88 |
04029-03 |
Knob This part replaces 04022-04. Price: Call Us |
| 89 |
42187 |
BATTERY MOUNTING BRACKET Price: Call Us |
| 92 |
42188 |
BATTERY SHELF Price: Call Us |
| 93 |
42024 |
BATTERY COVER Price: Call Us |
| 94 |
48099 |
BATTERY COVER PAD Price: Call Us |
| 95 |
04029-01 |
Wing Nut, 1/4-20 x .75" This part replaces 04022-01. Price: Call Us |
| 96 |
04003-39 |
Bolt, Carriage 1/4-20 x 6" This part replaces 04003-01. Price: Call Us |
| 97 |
42055 |
BATTERY CLAMP Price: Call Us |
| 98 |
48015 |
BATTERY Price: Call Us |
| 100 |
42370 |
TANK MTG. BRACKET(VERT.) Price: Call Us |
| 101 |
42377 |
SUPPORT, FUEL TANK(HOR.) Price: Call Us |
| 102 |
46846 |
Fuel Tank Assy. This part replaces 46174. Price: Call Us |
| 103 |
481603 |
Fuel Tank Cap This part replaces 48311. Price: Call Us |
| 104 |
483747 |
Ball Valve w/Screen This part replaces 48308. Price: Call Us |
| 105 |
421239 |
Strap, Fuel Tank This part replaces 42369. Price: Call Us |
| 107 |
48016 |
SOLENOID Price: Call Us |
| 110 |
48057 |
FUEL FILTER This part replaces 48057-01. Price: Call Us |
| 111 |
48059-01 |
FUEL HOSE CLAMP Price: Call Us |
| 112 |
483617 |
Fuel Hose, 1/4" I.D. Non-Perm (791DFI Fuel Return) This part replaces 48058-05. Price: Call Us |
| 115 |
48019 |
SAFETY SWITCH, BLADE CLUTCH Price: Call Us |
| 121 |
48205 |
PAD, TANK SUPPORT Price: Call Us |
| 122 |
48292 |
PAD, STRAP CUSHION Price: Call Us |
| 127 |
45062 |
BELT GUIDE WLD. Price: Call Us |
