Carburetor
Parts (88)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 3274-70 | SCREW-HSH Price: $9.50 |
| 1 | 503283403 | CARBURETOR Price: $69.99 |
| 2 | 353-727 | BONNET-SPECIAL Price: $105.32 |
| 2 | 537020901 | CHOKE SHAFT Price: $8.99 |
| 3 | 353-729 | DETENT STUD Price: $179.48 |
| 3 | 503481801 | SCREW Price: $2.99 |
| 4 | 353-733 | SPACER-BONNET Price: $41.01 |
| 4 | 537370301 | CHOKE CAP This part replaces 537021101. Price: $6.99 |
| 5 | 353-481 | LIFT CHECK ASM Price: $338.44 |
| 5 | 503481901 | BUSHING Price: $5.99 |
| 6 | 237-54 | O-RING Price: $1.97 |
| 6 | 537143401 | LEVER Price: $2.99 |
| 7 | 353-306 | WASHER-BACKUP Price: $9.12 |
| 7 | 537021001 | SPRING Price: $2.99 |
| 8 | 353-305 | O-RING Price: $10.91 |
| 8 | 503479001 | SCREW Price: $2.99 |
| 9 | 353-303 | WASHER-BACKUP Price: $9.06 |
| 9 | 537019801 | LEVER Price: $3.99 |
| 10 | 353-302 | O-RING Price: $10.13 |
| 10 | 503478901 | SPACER Price: $3.99 |
| 11 | 503480501 | SCREW Price: $2.99 |
| 12 | 353-851 | BODY-RELIEF Price: $180.95 |
| 12 | 503974301 | COVER Price: $5.99 |
| 13 | 353-392 | RING-PISTON Price: $13.94 |
| 13 | 537048901 | DIAPHRAGM Price: $11.99 |
| 14 | 353-531 | POPPET AND RING ASM Price: $229.51 |
| 14 | 537020401 | GASKET Price: $3.99 |
| 15 | 353-328 | SHIM (.040) Price: $3.53 |
| 15 | 503480101 | SCREW Price: $2.99 |
| 16 | 353-329 | SHIM (.020) Price: $2.10 |
| 16 | 537020801 | PIN This part replaces 503480001. Price: $2.99 |
| 17 | 353-330 | SHIM (.010) Price: $3.60 |
| 17 | 503665901 | LEVER Price: $3.99 |
| 18 | 353-398 | SPRING This part replaces 353-855. Price: $30.09 |
| 18 | 537273401 | SPRING This part replaces 537020301. Price: $4.99 |
| 19 | 353-334 | CAP-RELIEF Price: $55.48 |
| 19 | 503479701 | INLET NEEDLE Price: $8.99 |
| 20 | 3274-52 | SCREW-HSH Price: $3.19 |
| 20 | 537020801 | PIN Price: $2.99 |
| 21 | 353-575 | BOOT Price: $58.68 |
| 21 | 537012601 | SPRING Price: $2.99 |
| 22 | 537012501 | BALL Price: $2.99 |
| 22 | 93-3651 | RETAINER-BOOT Price: $31.38 |
| 23 | 503535701 | STRAINER Price: $3.99 |
| 24 | 503994301 | SPRING This part replaces 503480801. Price: $2.99 |
| 24 | 92-2547 | SEAL-RETAINER Price: $15.10 |
| 25 | 503974001 | WASHER Price: $2.99 |
| 25 | 92-2546 | WIPER-SEAL Price: $4.56 |
| 26 | 353-957 | CUP-SEAL Price: $16.26 |
| 26 | 537127801 | LOW SPEED NEEDLE Price: $14.99 |
| 27 | 353-301 | CHECK-LIFT, POPPET Price: $23.96 |
| 27 | 537020601 | NEEDLE HIGH SPEED Price: $3.99 |
| 28 | 353-304 | SPRING-CHECK, LIFT Price: $25.31 |
| 28 | 537143501 | CAP Price: $0.89 |
| 29 | 353-331 | O-RING Price: $16.66 |
| 29 | 503974001 | WASHER Price: $2.99 |
| 30 | 353-760 | RELIEF-BODY Price: $239.97 |
| 30 | 537019901 | THROTTLE FLAP Price: $3.99 |
| 31 | 353-758 | O-RING Price: $18.26 |
| 31 | 503479201 | SCREW Price: $2.99 |
| 32 | 353-952 | SEAL-BACK-UP Price: $7.89 |
| 32 | 503755301 | SCREW * Price: $2.99 |
| 33 | 3217-7 | NUT-HEX Price: $0.28 |
| 33 | 537019701 | SPRING THROTTLE Price: $2.99 |
| 34 | 353-772 | COVER-LEFT Price: $415.33 |
| 34 | 537019601 | SHAFT Price: $6.99 |
| 35 | 353-721 | PLUG Price: $44.12 |
| 35 | 537020001 | PUMP DIAPHRAGM Price: $7.99 |
| 36 | 537020101 | GASKET Price: $3.99 |
| 37 | 503481101 | PLUG Price: $3.99 |
| 38 | 537020201 | COVER Price: $19.99 |
| 39 | 503479601 | SCREW Price: $2.99 |
| 40 | 353-417 | COLLAR-STOP Price: $10.31 |
| 40 | 537020701 | SCREW Price: $6.99 |
| 41 | 531004552 | GASKET KIT (ZAMA GND39) Price: $9.99 |
| 41 | 92-3058 | SPRING - CENTERING Price: $31.34 |
| 42 | 353-780 | DETENT ASM This part replaces 353-754. Price: $480.94 |
| 43 | 3274-15 | SCREW-HSH Price: $0.42 |
| 44 | 353-763 | CAP-ADJUSTMENT Price: $161.34 |
| 45 | 104-7727 | SPRING-DETENT This part replaces 353-579. Price: $18.78 |
| 46 | 42-2680 | RACE-BALL Price: $76.92 |
| 47 | 52-5880 | BALL-DETENT Price: $4.60 |
| 48 | 354-29 | PLATE-THRUST Price: $236.43 |
| 49 | 353-728 | SLEEVE Price: $77.42 |
| 50 | 353-762 | SPUD-OUT Price: $152.45 |
| 52 | 353-732 | SLEEVE-DETENT Price: $113.02 |
| 53 | 38-0410 | NUT-HEX Price: $5.77 |
| 54 | 83-1890 | SWITCH-BALL Price: $63.08 |
