Crankcase
Parts (31)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 532412675 | SPRING.INTERLOCK This part replaces 532416288. Price: $4.99 |
| 1 | 93-3444 | CAP-FILLER Price: $45.82 |
| 2 | 532445291 | CAM.INTERLOCK.RELEASE This part replaces 532414572. Price: $3.99 |
| 2 | 93-3445 | DISCONTINUED Price: Call Us |
| 2 | KB-16851-96260 | PLUG Not Available Price: |
| 3 | 532443215 | SPRING.TORSION.LEVER This part replaces 532178831. Price: $3.99 |
| 3 | 67-2340 | BOLT W/WASHER Price: $2.19 |
| 3 | KB-16851-96270 | PLUG Not Available Price: |
| 4 | 532169675 | SPRING RETAINER Price: $4.99 |
| 4 | 93-3446 | PLATE-FRONT Price: $126.32 |
| 4 | KB-15451-96270 | CAP-SEALIN Not Available Price: |
| 5 | 817060410 | SCREW 14-20 X 5/8 Price: $3.99 |
| 5 | 93-3447 | GASKET-PLATE FRONT Price: $31.81 |
| 5 | KB-15261-96010 | PLUG Not Available Price: |
| 6 | 93-3448 | CASE - GEAR Price: $495.20 |
| 6 | KB-15521-96020 | PLUG Not Available Price: |
| 7 | 42-7390 | OIL SEAL Price: $31.54 |
| 7 | KB-15521-96030 | PLUG Not Available Price: |
| 8 | KB-15261-96160 | PLUG Not Available Price: |
| 9 | KB-05012-00814 | PIN, STRAIGHT Not Available Price: |
| 10 | KB-15221-33650 | PIN Not Available Price: |
| 11 | KB-15231-33960 | PIN-PIPE Not Available Price: |
| 12 | KB-17331-59190 | PIN-PIPE Not Available Price: |
| 13 | KB-15221-33700 | O-RING Not Available Price: |
| 14 | KB-15841-73020 | VALVE Not Available Price: |
| 15 | KB-16851-35010 | OIL PUMP ASSY Not Available Price: |
| 16 | KB-16851-35152 | GASKET-OIL PUMP Not Available This part replaces KB-16851-35150. Price: |
| 17 | KB-15841-91050 | BOLT Not Available Price: |
| 18 | KB-15841-35660 | GEAR Not Available Price: |
| 19 | KB-05712-00408 | KEY Not Available Price: |
| 20 | KB-02783-50100 | NUT Not Available Price: |
