| Ref | Part Number | Description |
|---|
| 1 |
323-14 |
SCREW-HH Price: $1.34 |
| 1 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 2 |
24-2690-01 |
CLAMP PLATE This part replaces 24-2690. Price: $48.58 |
| 2 |
530036345 |
Shroud Price: $12.99 |
| 3 |
24-2680-01 |
DISCONTINUED This part replaces 24-2680. Price: Call Us |
| 3 |
530029929 |
Cover-Crankcase Price: $1.99 |
| 4 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 5 |
3217-7 |
NUT-HEX Price: $0.28 |
| 5 |
530014307 |
Assy-Crankshaft Price: $14.99 |
| 6 |
5-3505-01 |
PIN This part replaces 5-3505. Price: $74.63 |
| 6 |
530032125 |
Bearing-Inner Price: $11.99 |
| 7 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 7 |
530015945 |
Retainer-C'case Price: $1.99 |
| 8 |
23-9930 |
DISCONTINUED Price: Call Us |
| 8 |
530019179 |
Seal-Crankcase Price: $2.99 |
| 9 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 9 |
530032124 |
Bearing-Outer Price: $4.99 |
| 10 |
3217-9 |
NUT-HH Price: $0.37 |
| 11 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 11 |
530015941 |
Ring-Ret. (C'shaft) Price: $1.99 |
| 12 |
24-2660-01 |
OUTSIDE WEIGHT This part replaces 24-2660. Price: $479.27 |
| 12 |
530016080 |
Screw Price: $1.99 |
| 13 |
325-4 |
SCREW-HH Price: $0.95 |
| 13 |
545221701 |
FLYWHEEL ASSY This part replaces 530039149. Price: $8.99 |
| 14 |
24-2630-01 |
STOP WA This part replaces 24-2630. Price: $123.09 |
| 14 |
530036145 |
Spacer-Ignit. Mod. Price: $1.99 |
| 15 |
25-1350 |
PIN-PLAIN Price: $174.74 |
| 15 |
530039163 |
Module-Ignition Price: $34.99 |
| 16 |
24-2670-01 |
INSIDE WEIGHT This part replaces 24-2670. Price: $244.62 |
| 16 |
530015954 |
Screw Price: $1.99 |
| 17 |
530016191 |
Spring-Starter Dog Price: $0.72 |
| 18 |
530054061 |
STARTER DOG & SPRING ASSEMBLY This part replaces 530049284. Price: $2.99 |
| 19 |
530015828 |
Washer-Flat Price: $1.99 |
| 20 |
530015930 |
Spacer-Flywheel Price: $0.99 |
| 21 |
530069232 |
Kit-Rope Price: $3.99 |
| 22 |
530015963 |
Retainer Price: $0.99 |
| 23 |
530015496 |
Screw Price: $1.99 |
| 24 |
530069353 |
Kit-Starter Pulley Price: $5.99 |
| 25 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 26 |
530027569 |
Handle-Starter Price: $1.99 |
| 27 |
530015886 |
Screw Price: $1.99 |
| 28 |
530014396 |
Kit-Clutch Ass'y. Price: $14.99 |
| 29 |
530014361 |
Assy-Fan Housing Price: $9.99 |
| 30 |
530019182 |
Grommet-Ignit. Module Price: $1.99 |
| 31 |
530015882 |
Screw Price: $1.99 |
| 32 |
530016197 |
Spring-Muffler Price: $1.99 |
| 33 |
530023877 |
Fitting-Fuel Line Price: $1.99 |
| 34 |
530036180 |
Screen-Muffler Price: $1.99 |
| 35 |
530015934 |
Screw Price: $1.99 |
| 36 |
530069659 |
Kit-Muffler Price: $11.99 |
| 37 |
530019223 |
Gasket-Cylinder Price: $1.99 |
| 38 |
530036404 |
Ring-Piston Price: $4.99 |
| 40 |
530015953 |
Screw Price: $1.99 |
| 41 |
530012353 |
CYLINDER This part replaces 530069619. Price: $6.99 |
| 42 |
503235112 |
Spark Plug This part replaces 952030201. Price: $5.99 |
| 43 |
530019233 |
Gasket-Cylinder/Carb. Adaptor Price: $1.99 |
| 44 |
530049024 |
Carb. Adaptor Price: $5.99 |
| 45 |
530016014 |
Screw Price: $1.99 |
| 46 |
530014384 |
Assy-Throttle Cable Price: $5.99 |
| 47 |
530015775 |
Screw Price: $1.99 |
| 48 |
530019194 |
Gasket-Carburetor Price: $1.99 |
| 49 |
530036192 |
Air Box Price: $2.99 |
| 51 |
530015849 |
Screw Price: $1.99 |
| 52 |
530029934 |
Air Filter- Foam Price: $1.99 |
| 53 |
530036193 |
Air Filter -Cover Price: $1.99 |
| 54 |
530015635 |
Screw Price: $1.99 |
| 55 |
530015162 |
Piston Pin Retainer Price: $1.99 |
| 59 |
530016103 |
Retainer Clip Price: $1.99 |
| 60 |
530095647 |
Assy-Fuel Pick-up Price: $3.99 |
| 61 |
530069615 |
Kit-Connecting Rod Price: $14.99 |
