| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER Price: $188.53 |
| 1 |
532143443 |
CONTROL.THROTTLE This part replaces 532137214. Price: $24.99 |
| 2 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 2 |
539990072 |
HCS 1/4C X 5/8 This part replaces 817720410. Price: $1.99 |
| 3 |
282-4 |
SHACKLE Price: $32.98 |
| 4 |
32151-48 |
E-RING Price: $1.41 |
| 4 |
532149723 |
Muffler This part replaces 532137978. Price: $45.99 |
| 5 |
532136215 |
Tube Manifold LH Price: $23.27 |
| 5 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 6 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
532136216 |
Tube Manifold RH Price: $23.71 |
| 7 |
98-4548-03 |
BRACKET-SPRING, RH Price: $42.16 |
| 8 |
532122439 |
Bracket Muffler Mounting Price: $6.27 |
| 8 |
98-4536-03 |
BRACKET-SPRING, LH Price: $42.16 |
| 9 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 9 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 817190408. Price: $1.99 |
| 10 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
532143600 |
Shield Heat LT Price: $6.99 |
| 11 |
100-3831-01 |
BRACKET-ROLLER, LH Price: $69.47 |
| 11 |
810040500 |
Washer Lock Hvy Spr 5/16-18 Price: $2.99 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
874570512 |
Screw Hex Skt 5/16-18 unc x 3/4 Price: $3.99 |
| 13 |
32151-61 |
RING-RETAINING Price: $2.39 |
| 14 |
75-5400 |
PIN-ROLLER Price: $26.06 |
| 14 |
813280336 |
Nipple Pipe 3/8 Npt X 4-1/2" Price: Call Us |
| 15 |
75-5390 |
ROLLER Price: $56.69 |
| 15 |
813200300 |
Elbow Std 90 Degree 3/8-18 Npt Price: $4.99 |
| 16 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 16 |
539990118 |
WASHER.3/8 This part replaces 811050600. Price: $1.49 |
| 17 |
75-5360 |
PIN-CYLINDER Price: $72.33 |
| 17 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $3.99 |
| 18 |
108-4432 |
CYLINDER-HYD, LIFT This part replaces 93-9311. Price: $730.09 |
| 18 |
532133747 |
Shield Heat Electric Price: $3.99 |
| 19 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 19 |
532105839 |
Receptacle 1/4 Turn Price: $3.99 |
| 20 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 20 |
532105838 |
Retainer 1/4 Turn Price: $3.99 |
| 21 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 22 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 22 |
532123650 |
Stud 1/4 Turn Price: $3.99 |
| 23 |
532128953 |
Shield Heat Browning LT/YT Price: $3.08 |
| 23 |
93-0069-03 |
PIN-REAR Price: $424.34 |
| 24 |
817021008 |
Screw Tap Hex #10-24unc X 1/2 Price: $1.99 |
| 25 |
322-6 |
SCREW-HH Price: $0.45 |
| 26 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 29 |
532137180 |
Kit Spark Arrestor (Flat Scrn) Price: $128.99 |
| 30 |
532105037 |
Foam Strip 18" Price: $2.38 |
| 31 |
532151346 |
SUB= 151346 This part replaces 532141069. Price: $58.99 |
| 32 |
581075501 |
CAP.FUEL.TANK.SS/SNO.EPA.DOME This part replaces 532140527. Price: $14.99 |
| 33 |
532123487 |
Clamp Hose Blk Price: $3.99 |
| 34 |
532106082 |
Pad, Spacer Price: $2.99 |
| 35 |
539976934 |
HCS.5/16-18X3/4 This part replaces 817490512. Price: $1.99 |
| 36 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131614. Price: $3.99 |
| 37 |
532008543 |
Line Fuel 54" Price: $7.99 |
| 39 |
532109227 |
Pad, Idler Price: $2.99 |
| 40 |
532003645 |
Bushing This part replaces 532124952. Price: $2.99 |
| 41 |
532139277 |
Stem Tank Fuel Price: $5.99 |
| 42 |
532132781 |
SUB= 132781 This part replaces 532132782. Price: $19.99 |
