| Ref | Part Number | Description |
|---|
| 1 |
24-2090 |
STEERING WHEEL CAP Price: $30.55 |
| 1 |
530047721 |
Bulb-purge Price: $3.99 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 2 |
530015843 |
Screw-tank Price: $1.99 |
| 3 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 3 |
530057973 |
Assy - Fuel Cap w/retainer This part replaces 530049386. Price: $7.99 |
| 4 |
256-202 |
DISCONTINUED Price: Call Us |
| 4 |
530095646 |
Assy-Fuel pick-up Price: $2.99 |
| 5 |
32141-11 |
Adjusting Nut Price: Call Us |
| 5 |
530069247 |
Kit-Fuel Line This part replaces 530071404. Price: $3.99 |
| 6 |
29-1360 |
DISCONTINUED Price: Call Us |
| 6 |
530069216 |
Kit-Fuel/Purge line Price: $3.99 |
| 7 |
28-3940 |
STRG SHAFT COLLAR Price: $52.89 |
| 7 |
530015775 |
Screw Price: $1.99 |
| 8 |
37-1100 |
DISCONTINUED Price: Call Us |
| 8 |
530054935 |
Cover-Air box Price: $1.99 |
| 9 |
302-16 |
ZERK FITTING Price: $7.10 |
| 9 |
530054946 |
Filter-Air Price: $1.99 |
| 10 |
29-0750 |
DISCONTINUED Price: Call Us |
| 10 |
530015849 |
Screw-carb. Price: $1.99 |
| 11 |
32121-31 |
PIN-SPRING Price: $0.26 |
| 11 |
530054934 |
Air Box Price: $3.99 |
| 12 |
29-0770 |
DISCONTINUED Price: Call Us |
| 12 |
530071565 |
Kit-Carb Assy., (WT-619) Price: $19.68 |
| 12 |
530071637 |
Assy-Carb(WT628) This part replaces 530071636. Price: $54.99 |
| 13 |
29-0670 |
STEERING SHAFT Price: $312.47 |
| 13 |
530071401 |
Gasket-Carb. (kit) Price: $3.99 |
| 14 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 14 |
545075305 |
Assy-Fuel Tank This part replaces 530055317. Price: $11.99 |
| 15 |
323-34 |
SCREW-HH Price: $0.54 |
| 15 |
530015771 |
Screw-crankcase Price: $1.99 |
| 16 |
32151-48 |
E-RING Price: $1.41 |
| 16 |
530015952 |
Screw-shrd to f/hsg. Price: $1.99 |
| 17 |
530056044 |
Shroud Price: $11.99 |
| 17 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 18 |
27-2210 |
DISCONTINUED Price: Call Us |
| 18 |
530071401 |
O-ring-c/case (kit) Price: $3.99 |
| 19 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 19 |
530027593 |
Valve-reed Price: $1.99 |
| 20 |
321-4 |
SCREW-HH Price: $0.99 |
| 20 |
530054596 |
Stop-reed valve Price: $1.99 |
| 21 |
29-0980 |
DISCONTINUED Price: Call Us |
| 21 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 22 |
5-1706 |
SPRING-EXTENSION Price: $12.91 |
| 22 |
530015875 |
Screw-tank retainer Price: $1.99 |
| 23 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 23 |
530055492 |
Isolator-fuel tank Price: $1.99 |
| 24 |
3220-4 |
NUT-JAM Price: $2.49 |
| 24 |
530054941 |
Ret.-fuel tank Price: $1.99 |
| 25 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 25 |
530054834 |
Handle-starter Price: $1.99 |
| 26 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 26 |
530071400 |
Kit-Rope Price: $1.20 |
| 27 |
322-3 |
SCREW-HH Price: $0.79 |
| 27 |
530032103 |
Bearing-inner Price: Call Us |
| 28 |
353-618 |
DISCONTINUED Price: Call Us |
| 28 |
530015787 |
Retainer Price: $1.99 |
| 29 |
3253-16 |
DISCONTINUED Price: Call Us |
| 29 |
530019158 |
Seal Price: $2.99 |
| 30 |
353-619 |
DISCONTINUED Price: Call Us |
| 30 |
530032102 |
Bearing-outer Price: $8.99 |
| 31 |
29-0940 |
DISCONTINUED Price: Call Us |
| 31 |
530015789 |
Retainer-crankshaft Price: $2.99 |
| 32 |
32121-35 |
PIN-ROLL Price: $0.79 |
| 32 |
530054948 |
Assy-crankshaft Price: $22.99 |
| 33 |
29-0960 |
DISCONTINUED Price: Call Us |
| 33 |
545081901 |
Assy-Crankcase This part replaces 530012514. Price: $17.99 |
| 34 |
29-0970 |
BRAKE ROD Price: $15.02 |
| 35 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 35 |
530071402 |
Kit-Flywheel Assy. Price: $8.64 |
| 36 |
29-0950 |
DISCONTINUED Price: Call Us |
| 36 |
530016030 |
Washer Price: $1.99 |
| 37 |
3220-7 |
NUT-JAM Price: $4.09 |
| 37 |
530055620 |
Spacer Price: $4.99 |
| 38 |
530015775 |
Screw-baffle Price: $1.99 |
| 38 |
68-7530 |
BUSHING This part replaces 19-9750. Price: $19.19 |
| 39 |
32128-29 |
NUT-LOCK, FLANGE Price: $1.63 |
| 39 |
530056864 |
Plate-baffle Price: $3.33 |
| 40 |
3220-5 |
NUT-JAM Price: $0.65 |
| 40 |
530016391 |
Screw-rope Price: $1.99 |
| 41 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 42 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 42 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 43 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 43 |
530019182 |
Grommet Price: $1.99 |
| 44 |
10-7880 |
DISCONTINUED Price: Call Us |
| 44 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 45 |
10-7890 |
DISCONTINUED Price: Call Us |
| 45 |
530056226 |
Housing-Fan w/eyelet Price: $9.72 |
| 46 |
10-8140 |
SPRING-LATCH, BRAKE Price: $18.38 |
| 46 |
530094189 |
Washer-Clutch Price: $2.99 |
| 47 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 47 |
530055122 |
Assy.-Clutch Price: $8.99 |
| 48 |
10-7850 |
LATCH-BRAKE, PARKING Price: $111.12 |
| 48 |
530028799 |
Assy-Drum Price: $4.48 |
| 49 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 49 |
530010960 |
Assy-Connecting rod Price: $14.99 |
| 50 |
530015162 |
Retainer-piston pin Price: $1.99 |
| 51 |
29-0890 |
DISCONTINUED Price: Call Us |
| 51 |
530025875 |
Ring-Piston Price: $4.99 |
| 52 |
256-148 |
FLANGE BUSHING Price: $14.60 |
| 52 |
530069899 |
Kit-Piston Price: $19.99 |
| 53 |
37-0500 |
FOLLOWER STEER SHAFT Price: $41.37 |
| 53 |
530071401 |
Gasket-Cylinder (kit) Price: $3.99 |
| 54 |
29-0720 |
DISCONTINUED Price: Call Us |
| 54 |
530069310 |
Kit-Muffler Price: $9.99 |
| 55 |
321-2 |
SCREW-HH Price: $2.79 |
| 55 |
530058957 |
Shield This part replaces 530053346. Price: $3.99 |
| 56 |
29-0730 |
DISCONTINUED Price: Call Us |
| 56 |
530036409 |
Spring-muffler Price: $1.99 |
| 57 |
29-0700 |
LOWER SLEEVE Price: $27.17 |
| 57 |
530071582 |
Kit-Cylinder Price: $19.99 |
| 58 |
38-3330 |
EXT SPRING *O This part replaces 29-0740. Price: $12.55 |
| 58 |
952030249 |
Spark plug (RCJ-6Y) Price: $3.99 |
| 59 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 59 |
530001624 |
Bolt-Cylinder Price: $1.99 |
| 60 |
29-0910 |
DISCONTINUED Price: Call Us |
| 60 |
530039218 |
Module-Ignition Price: $32.99 |
| 61 |
27-2830 |
PARKING BRAKE DECAL Price: $8.92 |
| 61 |
530016357 |
Screw-module Price: $1.99 |
| 62 |
29-0710 |
UPPER SLEEVE Price: $20.85 |
| 62 |
530057238 |
Assy-Rear wire Price: $5.99 |
| 63 |
29-0790 |
DISCONTINUED Price: Call Us |
| 63 |
530054942 |
Assy-Throttle Cable Price: $3.99 |
| 64 |
322-6 |
SCREW-HH Price: $0.45 |
| 65 |
3217-6 |
NUT-HEX Price: $1.19 |
| 66 |
253-84 |
SEAL-OIL Price: $10.00 |
| 67 |
29-0990 |
DISCONTINUED Price: Call Us |
| 68 |
3217-7 |
NUT-HEX Price: $0.28 |
| 69 |
29-0110 |
DISCONTINUED Price: Call Us |
| 70 |
29-1000 |
DISCONTINUED Price: Call Us |
| 71 |
29-0850 |
DISCONTINUED Price: Call Us |
| 72 |
29-0930 |
DISCONTINUED Price: Call Us |
| 73 |
29-2390 |
DISCONTINUED Price: Call Us |
| 74 |
32121-10 |
PIN-ROLL Price: $6.99 |
| 75 |
9547 |
WASHER-THRUST This part replaces 25-6260. Price: $5.69 |
