| Ref | Part Number | Description |
|---|
| 1 |
254-72 |
BEARING-CUP, TAPERED This part replaces 100-4571. Price: $9.67 |
| 1 |
532428610 |
TUBE.PNT.HDL.BAGGER. Price: $11.99 |
| 2 |
254-94 |
BEARING-CONE, TAPERED This part replaces 100-4572. Price: $8.48 |
| 3 |
104-2359 |
BEARING-CUP Price: $41.30 |
| 3 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 4 |
104-2360 |
BEARING-CONE Price: $88.16 |
| 4 |
532169916 |
HANDLE Price: $4.99 |
| 5 |
100-5817 |
BEARING-CUP Price: $42.99 |
| 5 |
874981024 |
SCREW.PAN.HEAD Price: $5.99 |
| 6 |
104-2358 |
BEARING-CONE Price: $78.85 |
| 6 |
532750029 |
SCREW This part replaces 874981032. Price: $3.99 |
| 7 |
100-5818 |
SCREW-HH Price: $16.76 |
| 7 |
873401000 |
NUT Price: $2.99 |
| 8 |
100-5812 |
PLUG Price: $17.99 |
| 8 |
532436933 |
Price: $128.99 |
| 9 |
3257-33 |
KEY-WOODRUFF This part replaces 100-4580. Price: $1.76 |
| 9 |
872140418 |
Bolt Carr. 1/4-20 x 2.25d x Gr. 5 Price: $6.99 |
| 10 |
100-1391 |
NUT-LOCK Price: $14.64 |
| 10 |
532181282 |
Tube Support Bagger CRD Price: $35.99 |
| 11 |
104-2361 |
SEAL Price: $51.07 |
| 11 |
532165719 |
BRACKET Price: $7.99 |
| 12 |
104-2367 |
GEAR-RH Price: $1,160.73 |
| 12 |
532188848 |
Bracket Pivot LH Price: $1.99 |
| 13 |
104-2368 |
GEAR-LH Price: $843.42 |
| 13 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 This part replaces 874760612. Price: $3.99 |
| 14 |
104-2362 |
SHAFT-INPUT Price: $1,158.39 |
| 14 |
874520636 |
BOLT-HEX EAK Price: $3.99 |
| 15 |
100-9984 |
CAP-END, CLOSED Price: $41.71 |
| 15 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 16 |
104-2357 |
CAP-END, OPEN Price: $379.42 |
| 16 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 17 |
100-5826 |
DISCONTINUED Price: Call Us |
| 17 |
539990316 |
RHSNB.5/16-18.X3/4.GR.5.ZD This part replaces 872140506. Price: $1.49 |
| 18 |
104-2363 |
SHAFT-OUTPUT Price: $939.18 |
| 19 |
104-2364 |
SEAL Price: $51.63 |
| 19 |
873900500 |
NUT LOCK HEX FLANGE 5/16-18 Price: $2.99 |
| 20 |
100-5824 |
WASHER Price: $13.99 |
| 20 |
532188847 |
BRKT.PIVOT.RH.CRD Price: $3.99 |
| 21 |
532406180 |
BAGGER.ASM.CRD.2007 Price: $105.99 |
| 22 |
532428236 |
BRACKET.BAGGER.SD. Price: $3.99 |
| 23 |
100-5847 |
O-RING Price: $19.99 |
| 24 |
104-2365 |
HOUSING-PINION Price: $339.24 |
| 24 |
532165783 |
TUBE Price: $14.99 |
| 25 |
100-1393 |
O-RING This part replaces 100-5848. Price: $15.99 |
| 25 |
532193705 |
Tube Front Bagger CRD Price: $31.99 |
| 26 |
100-1394 |
SHIM-GREEN (.003IN) Price: $15.99 |
| 27 |
100-7758 |
SHIM-BLUE (.005) Price: $15.99 |
| 28 |
112-7031 |
SHIM KIT This part replaces 100-1396. Price: $34.20 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $2.99 |
| 29 |
100-1397 |
DISCONTINUED - SEE NOTES FOR OPTIONS This part replaces 100-7760. Price: Call Us |
| 31 |
532169484 |
RETAINER CLIP Price: $4.99 |
| 32 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 33 |
532428683 |
MULCHING.PLUG.1078.CRD.NON-TEX Price: $33.99 |
| 34 |
532165570 |
HANDLE Price: $36.99 |
| 35 |
532165572 |
PIN Price: $11.99 |
| 36 |
819132012 |
WASHER Price: $2.99 |
| 37 |
532444848 |
Price: $1.99 |
| 38 |
872010520 |
BOLT.5/16-18X2.5 Price: $3.99 |
| 39 |
532416257 |
SEAL.BAGGER.CRD Price: $26.99 |
| 41 |
532432755 |
BRACKET.BAGGER.SD. Price: $6.99 |
| 43 |
532174083 |
PLUG, TUBING END Price: $3.99 |
| 46 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $3.99 |
| 47 |
532193704 |
Tube Upper Price: $35.99 |
| 49 |
532193305 |
Bar Spreader Price: $2.99 |
| 50 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.69 |
| 51 |
532199903 |
Latch Spring Price: $1.99 |
| 53 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
| 54 |
872110407 |
BOLT, HEX HEAD This part replaces 872140406. Price: $2.99 |
| 69 |
575180801 |
MEGA-FIRE ELECTR This part replaces 532435611. Price: $2.99 |
