| Ref | Part Number | Description |
|---|
| 1 |
483366 |
Key, Ignition Price: Call Us |
| 2 |
48017-04 |
Nut, Hex 5/8-32 Price: Call Us |
| 3 |
48017-03 |
Lockwasher, 5/8" Internal Price: Call Us |
| 4 |
462862 |
Instrument Panel w/Decal Price: Call Us |
| 5 |
04017-04 |
Bolt, Hex Head Serrated Flange 1/4-20 x 1/2" Price: Call Us |
| 6 |
04003-43 |
Bolt, Carriage #10-24 x 1/2" Price: Call Us |
| 7 |
485610 |
Choke Control Cable (Kohler CV) Price: Call Us |
| 7 |
485628 |
Choke Control Cable (Kawasaki FX) Price: Call Us |
| 8 |
04021-26 |
Locknut, #10-24 Price: Call Us |
| 9 |
485628 |
Throttle Control Cable (Kawasaki FX, Kohler CV) Price: Call Us |
| 11 |
482588 |
Clip, Wire Price: Call Us |
| 12 |
483643 |
Cover, Sealed Single Price: Call Us |
| 13 |
485674 |
Fuse, 5 Amp Price: Call Us |
| 14 |
483629 |
Fuse Holder Price: Call Us |
| 15 |
48798 |
Switch, Starter Price: Call Us |
| 16 |
463034 |
SEALED PTO SWITCH KIT This part replaces 483957. Price: Call Us |
| 17 |
484721 |
Cluster Gauge Price: Call Us |
| 19 |
482253 |
Diode Price: Call Us |
| 20 |
483571 |
Cover, Sealed Double Price: Call Us |
| 21 |
48298 |
Fuse, 20 Amp Price: Call Us |
| 22 |
04021-10 |
Nut, Elastic Stop 5/16-18 Price: Call Us |
| 23 |
483013 |
Relay Price: Call Us |
| 24 |
481638 |
Switch Price: Call Us |
| 25 |
485568 |
Power Plug Price: Call Us |
| 26 |
485640 |
Wire Harness Price: Call Us |
| 27 |
04001-44 |
Bolt, Hex Head 1/4-20 x 1/2” Price: Call Us |
| 28 |
48029-28 |
Battery Cable, 25" Red Price: Call Us |
| 29 |
48029-11 |
Battery Cable, 27" Black Price: Call Us |
| 31 |
04020-02 |
Nut, 1/4-20 UNC Price: Call Us |
| 32 |
483958 |
Diode, 600V - 6A Price: Call Us |
| 33 |
04102-03 |
Bolt, Hex Head 7/16-20 x 2-1/4" w/Patch Price: Call Us |
| 34 |
485673 |
Wire Harness Adapter, Kohler - 23CV Price: Call Us |
| 34 |
485678 |
Wire Harness Adapter, Kawasaki FX & FT Price: Call Us |
| 35 |
485589 |
Pulley, 5.75" Dia. - 1.125 Bore Price: Call Us |
| 36 |
04001-11 |
Bolt, Hex Head 5/16-18 x 1-1/2" Price: Call Us |
| 37 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 Price: Call Us |
| 38 |
431009 |
Bushing, UHMW Price: Call Us |
| 39 |
04003-12 |
Bolt, Carriage 5/16-18 x 3/4" Price: Call Us |
| 40 |
427111 |
Anti-Rotation Bracket Price: Call Us |
| 41 |
04117-01 |
Nut, Flange Elastic Stop 5/16-18 Price: Call Us |
| 42 |
04063-28 |
Key, 1/4 x 1/4 x 3-1/2" Price: Call Us |
| 43 |
462339 |
Clutch, GT3.5 - 1.125 Bore Price: Call Us |
| 44 |
04041-28 |
Flatwasher, 7/16-.469 x 1.75 x .25 Price: Call Us |
