| Ref | Part Number | Description |
|---|
| 1 |
121-8470 |
HEADLINER Price: $1,234.25 |
| 2 |
121-8495 |
BOX-MIXING, HEATER A/C Price: $3,723.40 |
| 2 |
532412282 |
DRAWBAR.LOWER.2PC.18/22 Price: $32.99 |
| 3 |
130-0558 |
BACKPLATE-RIVET Price: $10.21 |
| 3 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 4 |
130-5938 |
TUBE-SUPPORT Price: $14.24 |
| 4 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 5 |
104-7201 |
NUT-HF Price: $0.69 |
| 5 |
532448441 |
Price: Call Us |
| 6 |
130-5860 |
HOSE-VENT Price: $34.14 |
| 6 |
532110452 |
NUT PUSH M Price: $2.99 |
| 7 |
130-0455 |
LOUVER-ROUND, SNAP-IN Price: $31.16 |
| 8 |
125-7503 |
RIVET-POP Price: $0.68 |
| 9 |
130-0465 |
LOUVER-ROUND, SNAP-IN (4 INCH) Price: $54.73 |
| 10 |
121-8473 |
HOSE-INTAKE, FRESH AIR Price: $56.10 |
| 11 |
130-5861 |
HOSE-VENT, OUTER (LH) Price: $51.61 |
| 12 |
121-8477 |
HOSE-VENT, DEFROST (LH) Price: $62.74 |
| 13 |
130-0437 |
HOSE-VENT, CENTER Price: $36.68 |
| 14 |
121-8478 |
HOSE-VENT, DEFROST (RH) Price: $62.74 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN Price: $149.99 |
| 15 |
130-5862 |
HOSE-VENT, OUTER (RH) Price: $63.34 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 16 |
2412-110 |
CLAMP-BAND/SCREW Price: $3.60 |
| 17 |
107069 |
CLIP Price: $1.79 |
| 18 |
125-9532 |
FILTER-CAB, INSIDE Price: $13.02 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM Price: $129.99 |
| 19 |
125-9604-03 |
PLATE-COVER, RECIRCULATION Price: $32.77 |
| 20 |
125-7438 |
KNOB-SCREW, THUMB Price: $2.73 |
| 21 |
32115-15 |
PUSHNUT-RETAINER, BOLT This part replaces 106-8737. Price: $0.99 |
| 22 |
130-5927 |
ADAPTER-BLEED Price: $12.10 |
| 23 |
132-3601 |
ROOF ASM Price: $735.66 |
| 24 |
136-8674 |
BOLT-PIVOT, ECCENTRIC Price: $1.79 |
| 25 |
130-5939 |
TUBE-SUPPORT Price: $15.68 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 27 |
130-5999 |
DRIER-RECEIVER Price: $126.38 |
| 29 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 30 |
3274-69 |
SCREW-HSBH Price: $0.43 |
| 31 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 33 |
119-4501 |
SWITCH-FUNCTION, DUAL Price: $66.48 |
| 34 |
46-6560 |
BUSHING Price: $2.94 |
| 35 |
104-5228 |
FITTING-ELBOW, 90 DEG Price: $17.50 |
| 36 |
130-0445 |
BACKPLATE-RIVET Price: $3.74 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
130-0444 |
FOAM-INLET, AIRBOX Price: $15.21 |
| 37 |
532441208 |
FENDER.PNT.TX.GT.CH/FW/DL.HUSQ Price: $219.99 |
| 38 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 39 |
132-3474 |
INSERT-SEAL, FILTER Price: $68.15 |
| 40 |
132-1461-03 |
STRAP-CAB, SIDE Price: $71.49 |
| 41 |
132-1462-03 |
STRAP-CAB Price: $47.00 |
| 58 |
532412281 |
DRAWBAR.UPPER.2PC,LRG.FENDER Price: $37.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532198512 |
AIR.DUCT.HOOD.TEX.GT.HUSQ Price: $29.99 |
| 152 |
532194329 |
SHIELD.BROWNING/DEBRIS Price: $17.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 161 |
532401801 |
FUEL WINDOW This part replaces 532439929. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532194330 |
SUPPORT.TANK.REAR.B/TE Price: $17.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
582033101 |
KITS.TEX.BOLTED.CHASSIS.445559 This part replaces 532194260. Price: $229.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. This part replaces 532439746. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 196 |
532439674 |
CONSOLE.ASM.DECKLIFT.HUSQGT.DL Price: $84.99 |
| 199 |
532198259 |
PLATE.DECK.LIFT.HUSQVARNA.GT Price: $17.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532416613. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 221 |
532198909 |
REFLECTOR.LH.TEX GT HU Price: $14.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
