| Ref | Part Number | Description |
|---|
| 1 |
532176027 |
DECK.SVC.42".BLACK This part replaces 532165892. Price: $329.99 |
| 1 |
X-8-20 |
Screw-H.C. Price: Call Us |
| 2 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 2 |
X-23-1 |
Washer-Lock Price: Call Us |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 3 |
X-286-8 |
Key Price: Call Us |
| 4 |
270219 |
Plug-Vent Price: Call Us |
| 4 |
532165460 |
BRACKET SWAY BAR 42" DECK Price: $11.99 |
| 5 |
274042 |
Gasket-Clutch Price: Call Us |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 6 |
B-274041 |
Clutch Assembly Price: Call Us |
| 7 |
X-5-4 |
Screw, H.C. Price: Call Us |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 8 |
X-5-7 |
Screw, H.C. Price: Call Us |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 9 |
X-7-2 |
Screw-HH Price: Call Us |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 10 |
X-20-1 |
Washer Price: Call Us |
| 11 |
X-22-1 |
Washer Price: Call Us |
| 12 |
X-25-37 |
Washer-Plain Price: Call Us |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 13 |
X-50-13 |
Screw-R.H. Price: Call Us |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 14 |
X-75-2 |
Plug Price: Call Us |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
X-271-19 |
Seal Oil Price: Call Us |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 16 |
X-230-20 |
Plug-Welch Price: Call Us |
| 17 |
234025 |
Shaft, Yoke Price: Call Us |
| 18 |
234032 |
Cover Price: Call Us |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
234033 |
Gasket-Clutch Cover Price: Call Us |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
234089 |
Plate Instruction Price: Call Us |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
234035 |
Bearing-Ball Price: Call Us |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
234036 |
Plate, Bearing Price: Call Us |
| 23 |
234037 |
Ring-Snap Price: Call Us |
| 23 |
529845901 |
SERVICE KIT BRKT This part replaces 532177563. Price: $4.99 |
| 24 |
234038 |
SEE 234036 Price: Call Us |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
234039 |
Shaft-Drive Price: Call Us |
| 25 |
532123713 |
SPRING TORSION Price: $6.99 |
| 26 |
234040 |
Key Price: Call Us |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
234074 |
Housing Price: Call Us |
| 27 |
532130968 |
SHIELD.DEFLECTOR.MOWER.42".BLK This part replaces 532171859. Price: $34.99 |
| 28 |
234145 |
Screw, Drive Price: Call Us |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 29 |
274101 |
Pin-Roll Price: Call Us |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 30 |
A-234027 |
Yoke-Clutch Price: Call Us |
| 31 |
274117 |
Shaft-Yoke Price: Call Us |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 32 |
A-234026 |
Lever-Shifting Price: Call Us |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 33 |
A-234075 |
Clutch Assembly Price: Call Us |
| 34 |
234041 |
Housing-Clutch Price: Call Us |
| 34 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 35 |
234042 |
Bearing Price: Call Us |
| 36 |
234043 |
Lock-Adjusting Price: Call Us |
| 36 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
A-234044 |
Member-Drive Price: Call Us |
| 38 |
A-234045 |
Plate-Pressure Price: Call Us |
| 39 |
234050 |
Link Connecting Price: Call Us |
| 40 |
234051 |
Pin-Link, Long Price: Call Us |
| 40 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 41 |
234052 |
Pin-Link, Short Price: Call Us |
| 42 |
A-234053 |
Bearing-Release Price: Call Us |
| 43 |
A-234054 |
Sleeve, Release Price: Call Us |
| 44 |
234055 |
Sleeve-Return Price: Call Us |
| 45 |
234056 |
Ring-Adjusting Price: Call Us |
| 45 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 46 |
234057 |
Lock-Screw Price: Call Us |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
234073 |
Screw-H.C. Price: Call Us |
| 48 |
234046 |
Lever-Pressure Plate Price: Call Us |
| 48 |
532133944 |
WASHER Price: $3.99 |
| 49 |
234047 |
Pin-Lever Price: Call Us |
| 50 |
234048 |
Roller Price: Call Us |
| 51 |
X-7-29 |
Screw-HH Price: Call Us |
| 52 |
532139888 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 52 |
X-21-1 |
Washer Price: Call Us |
| 53 |
531168401 |
SERVICE KIT ARM BRAKE ASSY This part replaces 532184907. Price: $19.99 |
| 53 |
X-22-1 |
Washer Price: Call Us |
| 54 |
532178515 |
WASHER Price: $5.99 |
| 54 |
X-22-11 |
Washer Price: Call Us |
| 55 |
531166601 |
SERVICE KIT ARM ARM IDLER 42" This part replaces 532155046. Price: $14.99 |
| 55 |
X-52-22 |
Screw Price: Call Us |
| 56 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 56 |
X-83-4 |
Nut-Hex Price: Call Us |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 67 |
532106932 |
KNOB T (3/8 HOLE) Price: $6.99 |
| 68 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 92 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 129 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 130 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 131 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 142 |
529845801 |
SERVICE KIT ARM SPRING BRAKE M This part replaces 532165890. Price: $5.99 |
| 143 |
529844301 |
SERVICE KIT BRACKET This part replaces 532157109. Price: $7.99 |
| 144 |
532173441 |
KEEPER BELT 42" CLUTCH This part replaces 532158634. Price: $6.99 |
| 145 |
532173437 |
PULLEY.IDLER.FLAT.PLATED This part replaces 532165888. Price: $24.99 |
| 146 |
532173443 |
BOLT CARRIAGE IDLER This part replaces 532171977. Price: $4.99 |
| 147 |
532179748 |
SPRING This part replaces 532131335. Price: $4.99 |
| 148 |
532169022 |
IDLER RETURN SPRING Price: $4.99 |
| 149 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 150 |
596204201 |
Washers This part replaces 819091216. Price: $2.99 |
| 151 |
532169670 |
BRACKET.CLUTCH.CABLE Price: $17.99 |
| 152 |
532175067 |
KIT.CLUTCH.CABLE This part replaces 532169676. Price: $39.99 |
| 153 |
596140201 |
Washers This part replaces 532169674. Price: $2.99 |
| 154 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 155 |
532169671 |
SPRING RETENTION LEVER Price: $4.99 |
| 156 |
532169672 |
SPACER.CLUTCH.CABLE Price: $4.99 |
| 157 |
532169669 |
ROD CLUTCH CABLE 3/8" Price: $27.99 |
| 158 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 159 |
596987501 |
Bolts This part replaces 872140614. Price: $3.99 |
| 184 |
596134901 |
GSPH This part replaces 819131410. Price: $2.99 |
