| Ref | Part Number | Description |
|---|
| 1 |
598602801 |
Decks This part replaces 532441275. Price: $349.99 |
| 1 |
98-2354-03 |
LATCH-SEAT Price: $41.34 |
| 1 |
BS-691982 |
HEX SCREW Not Available This part replaces BS-805406. Price: |
| 2 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 2 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 2 |
BS-805025 |
SCREW Not Available Price: |
| 3 |
32128-25 |
NUT-HF Price: $3.19 |
| 4 |
104-0082 |
DISCONTINUED Price: Call Us |
| 5 |
98-9302 |
PLATE-STOP, IDLER Price: $12.42 |
| 5 |
BS-805260 |
SCREW-STAR Not Available Price: |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 6 |
66-4190-03 |
SPRING-IDLER, CLUTCH Price: $7.20 |
| 6 |
BS-807663 |
BACK PLATE Not Available Price: |
| 7 |
92-5524 |
DISCONTINUED Price: Call Us |
| 7 |
BS-690677 |
CARB COVER SCREW Not Available This part replaces BS-805009. Price: |
| 8 |
63-9920 |
DISCONTINUED Price: Call Us |
| 8 |
BS-805505 |
SHIELD Not Available Price: |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 9 |
BS-805738 |
COVER-AIR GUIDE BS-690750 Not Available Price: |
| 10 |
25-8640 |
SCREW-HH Price: $1.09 |
| 10 |
BS-805636 |
COVER-CARBURETOR (BS-80 Not Available Price: |
| 11 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 11 |
580921101 |
BLADE.REVOLUTION.42"3IN1.PT43 Price: $24.99 |
| 11 |
BS-807898 |
HOUSING-BL Not Available Price: |
| 12 |
98-9311 |
SWIVEL-THROTTLE Price: $28.41 |
| 12 |
BS-841319 |
AIR GUIDE COVER Not Available This part replaces BS-807661. Price: |
| 13 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 13 |
587820201 |
KIT,MANDREL,NONGREASE,REVOL This part replaces 580854701. Price: $32.99 |
| 13 |
712-0689 |
HEX NUT Not Available This part replaces BS-805383. Price: |
| 14 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 14 |
587820201 |
KIT,MANDREL,NONGREASE,REVOL This part replaces 580796101. Price: $32.99 |
| 14 |
BS-805448 |
REGULATOR SCREW Not Available Price: |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 15 |
585323901 |
BEARING.MANDREL.TOP.EXTENDED Price: $12.99 |
| 15 |
BS-691077 |
Washer (Ground Terminal) This part replaces BS-92791. Price: $11.38 |
| 16 |
712-0142 |
Nut, Hex Price: $3.90 |
| 16 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 17 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350-03. Price: $166.30 |
| 17 |
BS-691084 |
Terminal Ground This part replaces BS-93722. Price: $11.38 |
| 18 |
93-8060 |
DECAL-REELS Price: $53.80 |
| 18 |
BS-690744 |
GROMMET Not Available This part replaces BS-805641. Price: |
| 19 |
233-42 |
KNOB Price: $12.88 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 21 |
98-3926 |
CABLE-THROTTLE Price: $32.00 |
| 22 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
98-2352-03 |
FRAME-SEAT Price: $456.00 |
| 25 |
32121-38 |
PIN-ROLL Price: $0.53 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
93-0021 |
SWIVEL-CABLE, THROTTLE Price: $33.15 |
| 27 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 27 |
532403004 |
SHIELD.DEFLECTOR.MOWER.42"BLAC Price: $29.99 |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
321-4 |
SCREW-HH Price: $0.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 31 |
75-3680-03 |
ROD-SEAT Price: $38.90 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 55 |
531171201 |
SERVICE KIT IDLER.ARM.42" This part replaces 532437110. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 62 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 68 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 111 |
531170801 |
SERVICE KIT BRKT.WHEEL.GAUGE B This part replaces 532404784. Price: $8.99 |
| 112 |
531170901 |
SERVICE KIT BRKT.WHEEL.GAUGE B This part replaces 532404785. Price: $8.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 116 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $9.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 190 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 246 |
580954003 |
HOLDER.BLADE.REVOLUTION Price: $179.99 |
| 254 |
585316805 |
PLATES.RENFRC.42DECK.PT431FRNT Price: $11.99 |
| 255 |
585317005 |
PLATES.RENFRCE.42DECK.X431SIDE Price: $11.99 |
| 256 |
592807801 |
BOLT CUP HEAD SQUARE NECK 1/4- This part replaces 539109800. Price: $2.99 |
| 257 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 263 |
586638501 |
CAP.REVOLUTION ASM Price: $29.99 |
