| Ref | Part Number | Description |
|---|
| 1 |
111-4783 |
RH LIFT ARM ASM This part replaces 111-4784-01. Price: $679.09 |
| 1 |
31834 |
SHAFT & LEV Price: $6.54 |
| 1 |
530015880 |
Screw Price: $1.99 |
| 2 |
530058982 |
Bolt-Muffler Price: $1.99 |
| 2 |
631767 |
SPRING This part replaces 632016. Price: $1.25 |
| 3 |
631036 |
SHUTTER Price: $1.20 |
| 4 |
119-2200 |
PAD-RUBBER, REAR HOC Price: $10.33 |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 4 |
650506 |
SCREW Price: $0.87 |
| 5 |
119-2230 |
PAD-PLASTIC, REAR HOC Price: $7.14 |
| 5 |
630766 |
SPRING Price: $1.25 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: $3.99 |
| 6 |
110-0606 |
RIVET-BLIND Price: $1.15 |
| 6 |
530012541 |
Cylinder Price: $11.99 |
| 6 |
651025 |
SCREW This part replaces 650417. Price: $1.18 |
| 7 |
105-7441 |
BEARING-SPHERICAL Price: $56.85 |
| 7 |
530071750 |
Seal-Cylinder (kit) Price: $8.99 |
| 7D |
31836 |
SHAFT & LEV Price: $5.21 |
| 8 |
32151-34 |
RING-RETAINING Price: $0.67 |
| 8 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 8 |
632042 |
SPRING Price: $3.00 |
| 9 |
31837 |
SHUTTER Price: $1.18 |
| 9 |
3269-26 |
WASHER-PLAIN Price: $0.99 |
| 9 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 10 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 10 |
630748 |
WELCH PLUG Price: $1.17 |
| 11 |
530057829 |
Assy-Crankshaft Price: $12.99 |
| 11 |
631027 |
WELCH PLUG Price: $1.17 |
| 12 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 13 |
530071750 |
Seal-Cyl/Carb.(kit) Price: $8.99 |
| 13 |
631022 |
CLIP Price: $1.25 |
| 14 |
530057547 |
Adapter-Carb. Price: $7.99 |
| 14 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 15 |
530016309 |
Screw Price: $1.99 |
| 15 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 16 |
530071750 |
Gasket-Carb. (kit) Price: $8.99 |
| 16 |
631867 |
FLOAT BOWL Price: $2.34 |
| 17 |
530071822 |
KIT CARB ASSY # C1U-W24 This part replaces 530071752. Price: $29.99 |
| 18 |
580731001 |
BASE AIRBOX BLACK This part replaces 530057585. Price: $1.99 |
| 19 |
530016429 |
Screw Price: $1.99 |
| 20 |
530057781 |
Foam-Air Filter Price: $1.99 |
| 21 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 21 |
530057584 |
Cover-Air Box Price: $4.99 |
| 22 |
31839 |
POWER SCREW Price: $10.89 |
| 22 |
530039223 |
Ignition Module Price: $17.99 |
| 23 |
530038604 |
Coupling-Drive Price: $1.99 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
530016357 |
Screw Price: $1.99 |
| 24 |
631838 |
ADJ SCREW This part replaces 631078. Price: $2.71 |
| 25 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 25 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 26 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 26 |
632164 |
FUEL FITTING This part replaces 631803. Price: $5.95 |
| 27 |
530016392 |
Screw Price: $1.99 |
| 27 |
631183 |
WASHER This part replaces 631971. Price: $1.25 |
| 27A |
631183 |
WASHER Price: $1.25 |
| 28 |
530058600 |
Assy.-Fan Hsg Price: $14.99 |
| 28 |
631184 |
WASHER Price: $1.25 |
| 29 |
530071356 |
Kit-Switch Price: $4.99 |
| 29 |
631972 |
WASHER Price: $1.25 |
| 30 |
530027569 |
Handle-Starter Price: $1.99 |
| 30 |
630738 |
SPRING Price: $1.25 |
| 31 |
530071767 |
Kit - Rope Price: $3.99 |
| 31 |
630735 |
SPRING Price: $1.25 |
| 32 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 32 |
630739 |
WASHER Price: $1.25 |
| 33 |
530016124 |
Nut Price: $1.99 |
| 34 |
530057588 |
Clip-Spring Price: $1.99 |
| 35 |
530016430 |
Screw Price: $2.99 |
| 36 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 37 |
530071786 |
Kit-Pulley-Starter Price: $3.99 |
| 38 |
530027523 |
Retainer-Pulley Price: $2.99 |
| 39 |
530015775 |
Screw Price: $1.99 |
| 40 |
530015828 |
Washer-Flat Price: $1.99 |
| 41 |
545221701 |
FLYWHEEL ASSY This part replaces 530054115. Price: $8.99 |
| 43 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 44 |
530055728 |
Outer Bearing Price: $6.99 |
| 45 |
530019264 |
Seal-C'case Price: $2.99 |
| 46 |
530032125 |
Inner Bearing Price: $11.99 |
| 47 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 48 |
530071750 |
O-Ring-C'case (kit) Price: $8.99 |
| 50 |
530016386 |
Screw Price: $5.99 |
| 51 |
530057580 |
Shroud-Rear Price: $7.99 |
| 52 |
530016431 |
Retainer-Tank Price: $3.99 |
| 54 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 55 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 56 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 57 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
