| Ref | Part Number | Description |
|---|
| 2 |
710-04194 |
Cover Screw This part replaces 753-04595. Price: $3.66 |
| 3 |
710-04604A |
SCREW M5X0.8 This part replaces 753-05377. Price: $3.63 |
| 4 |
753-05209 |
ROCKER COVER Not Available Price: |
| 5 |
721-04132 |
O-RING Not Available This part replaces 753-05210. Price: |
| 7 |
753-05229 |
PISTON RING ASSEMBLY Not Available Price: |
| 9 |
753-05232 |
Cylinder O-Ring Not Available Price: |
| 10 |
791-182379 |
Breather Hose Price: $4.10 |
| 12 |
791-182290 |
Oil Plug O-Ring Price: $4.29 |
| 13 |
753-05237 |
CRANKCASE COVER Not Available Price: |
| 14 |
753-05238 |
Crankcase Cover O-ring Price: $9.20 |
| 16 |
753-05240 |
Flywheel Assembly Price: $67.61 |
| 18 |
710-04584 |
Cam Bracket Screw This part replaces 753-05242. Price: $3.29 |
| 19 |
753-05785 |
Lead Wires Price: $9.46 |
| 20 |
753-05301 |
Module Assembly This part replaces 753-05243. Price: $99.77 |
| 21 |
753-05244 |
Muffler Gasket Price: $5.11 |
| 23 |
710-04809 |
SCREW M5 x 44MM This part replaces 753-05246. Price: $2.83 |
| 24 |
794-00082 |
Spark Plug This part replaces 753-05255. Price: $6.35 |
| 25 |
753-05247 |
GASKET/INSULATOR Not Available Price: |
| 26 |
712-04099 |
Nut This part replaces 753-05248. Price: $5.94 |
| 28 |
753-05366 |
Carburetor Gasket Price: $17.21 |
| 29 |
753-05251 |
Carburetor w/Primer Price: $65.76 |
| 30 |
753-04030 |
O-Ring Not Available Price: |
| 31 |
710-04517 |
Screw This part replaces 753-05507. Price: $4.71 |
| 33 |
791-182097 |
Breather Tube Price: $10.13 |
| 34 |
791-181000 |
O-RING Not Available Price: |
| 35 |
791-182409 |
Washer Price: $4.04 |
| 36 |
712-04099 |
Nut This part replaces 753-05248. Price: $5.94 |
| 37 |
791-182657 |
PLATE, WALBRO AIR Not Available Price: |
| 38 |
753-05506 |
Air Filter Price: $3.76 |
| 39 |
791-182659 |
COVER, AIR CLEANER ( Not Available Price: |
| 41 |
753-1229 |
Fuel Cap Price: $19.90 |
| 42 |
753-05259 |
Fuel Tank Pads Price: $5.72 |
| 43 |
712-04096 |
PUSH NUT Not Available This part replaces 753-05260. Price: |
| 44 |
1755 |
Screw This part replaces 753-1202. Price: $3.37 |
| 46 |
750-04434 |
Powershaft Spacer This part replaces 753-05078. Price: $5.91 |
| 48 |
753-05509 |
Rope Price: $8.93 |
| 49 |
753-04286 |
Recoil Spring Price: $24.35 |
| 50 |
631-04164B |
Pull Handle This part replaces 791-181079. Price: $3.38 |
| 51 |
791-611061 |
Rope Guide Price: $9.62 |
| 53 |
9162-1 |
Washer This part replaces 791-182396. Price: $3.91 |
| 54 |
756-04269 |
DRIVE PULLEY Not Available This part replaces 753-05790. Price: |
