| Ref | Part Number | Description |
|---|
| 1 |
104-3930 |
TANK-RADIATOR, SURGE Price: $91.58 |
| 1 |
401042 |
Seat Price: Call Us |
| 2 |
104-3931 |
MOUNTING-TANK, SURGE Price: $204.70 |
| 2 |
140551 |
Bracket Seat Pivot Price: Call Us |
| 3 |
104-3944-03 |
SHROUD-RADIATOR, TOP Price: $129.26 |
| 3 |
71110616 |
Bolt Hex 3/8 - 16 x 1 Price: Call Us |
| 4 |
19131610 |
Washer 13/32 x 1 x10 Ga. Price: Call Us |
| 4 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 5 |
145006 |
Clip Push-In Hinged Price: Call Us |
| 5 |
83-8040 |
COVER-LEFT Price: $247.94 |
| 6 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 6 |
73800600 |
Nut Lock Hex w/Ins 3/8 - 16 Price: Call Us |
| 7 |
124181X |
Spring Seat Cprsn 2 250 Blk Zi Price: Call Us |
| 7 |
83-9030 |
FOAM-TOP Price: $5.26 |
| 8 |
17000616 |
Screw 3/8-16 x 1.5 Price: Call Us |
| 8 |
32128-44 |
NUT Price: $2.69 |
| 9 |
104-4000 |
SCREW-THUMB Price: $3.12 |
| 9 |
19131614 |
Washer 13/32 x 1 x 14 Ga. Price: Call Us |
| 10 |
195530 |
Pan Pnt Seat Price: Call Us |
| 10 |
3234-28 |
SCREW-HHF Price: $1.59 |
| 11 |
104-4006-03 |
REAR RADIATOR BRACKET ASM Price: $169.50 |
| 12 |
174648 |
Bracket Pnt Mounting Switch Price: Call Us |
| 12 |
32148-8 |
NUT-CLINCH Price: $2.31 |
| 13 |
121248X |
Bushing Snap Blk Nyl Price: Call Us |
| 13 |
323-6 |
SCREW-HH Price: $0.66 |
| 14 |
72050412 |
Bolt Rdhd Sht Nk 1/4 - 20 x 1 -1/2 Price: Call Us |
| 14 |
83-8150-03 |
SCREEN ASM Price: $354.15 |
| 15 |
134300 |
Spacer Split .28 x .96 Price: Call Us |
| 15 |
83-8070-03 |
SHIELD-RADIATOR, BOTTOM Price: $29.88 |
| 16 |
121250X |
Spring Cprsn Price: Call Us |
| 16 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 17 |
123976X |
Nut Lock 1/4 Lge Flg Price: Call Us |
| 17 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 18 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 19 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 20 |
104-4008-03 |
FRONT RADIATOR BRACKET ASM Price: $177.23 |
| 21 |
104-3861 |
RADIATOR ASM Price: $1,403.47 |
| 21 |
171852 |
Bolt Shoul der 5/16-18 unc-2A Price: Call Us |
| 22 |
104-3945-03 |
SHROUD-RADIATOR, BOTTOM Price: $107.05 |
| 22 |
73800500 |
Nut Lock Hex w/Ins 5/16 - 18 Price: Call Us |
| 23 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 23 |
71110814 |
Bolt Hex Price: Call Us |
| 24 |
19171912 |
Washer 17/32 x 1-3/16 x 12 Ga. Price: Call Us |
| 24 |
32128-33 |
NUT-HF Price: $0.25 |
| 25 |
117-3276 |
DECAL-DANGER This part replaces 106-5976. Price: $10.70 |
| 25 |
127018X |
Bolt Shoul der 5/16-18 x .62 Price: Call Us |
| 26 |
93-7272 |
DECAL-WARNING Price: $6.37 |
| 27 |
104-3912 |
HOSE-RADIATOR Price: $8.44 |
| 28 |
104-4029 |
SEAL-BULB Price: $10.78 |
| 29 |
104-3911 |
HOSE-RADIATOR, TOP Price: $70.92 |
| 30 |
104-3914-03 |
TUBE-RADIATOR Price: $101.92 |
| 31 |
3234-17 |
SCREW-HHF Price: $0.72 |
