| Ref | Part Number | Description |
|---|
| 1 |
107-0807 |
VALVE-FLUSHING, RH Price: $129.44 |
| 1 |
579866104 |
SUSPENSION SEAT Price: $999.99 |
| 2 |
107-0857 |
PLUG Price: $31.81 |
| 2 |
582478802 |
Bars This part replaces 582478801. Price: $8.99 |
| 3 |
107-0817 |
O RING-PLUG Price: $3.09 |
| 3 |
582478203 |
Brackets This part replaces 582478201. Price: $11.99 |
| 4 |
120-5150 |
CENTER CASE ASM Price: $2,743.66 |
| 4 |
590555002 |
BRACKET.SEAT.STAY.ROD Price: $8.99 |
| 5 |
107-0858 |
U-NUT Price: $2.71 |
| 5 |
590481801 |
ISOLATOR Price: $6.99 |
| 6 |
107-0805 |
PLATE-VALVE Price: $114.64 |
| 6 |
539116377 |
ISO-MOUNT INSERT Price: $3.99 |
| 7 |
107-0824 |
CYLINDER BLOCK ASM Price: $1,216.33 |
| 7 |
590373501 |
LATCH.ROTARY Price: $39.99 |
| 8 |
107-0830 |
PLATE-THRUST Price: $77.36 |
| 8 |
590506802 |
PLATE.PNT.MTG.SEAT.EDIP Price: $139.99 |
| 9 |
590507202 |
Rods This part replaces 590507201. Price: $24.99 |
| 9 |
92-0765 |
PIN-PARALLEL Price: $3.03 |
| 10 |
107-0859 |
BOLT Price: $1.56 |
| 10 |
594891901 |
Springs This part replaces 539113952. Price: $1.99 |
| 11 |
107-0858 |
U-NUT Price: $2.71 |
| 11 |
582478102 |
Nuts This part replaces 582478101. Price: $5.99 |
| 12 |
120-0008 |
CONTROL ARM KIT This part replaces 107-0831. Price: $153.36 |
| 12 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $17.99 |
| 13 |
107-0832 |
SIDE COVER ASM Price: $444.99 |
| 13 |
596031601 |
Screws This part replaces 539108392. Price: $2.99 |
| 14 |
107-0829 |
WASHER Price: $35.71 |
| 14 |
582478902 |
Screws This part replaces 582478901. Price: $5.99 |
| 15 |
120-5151 |
PUMP HOUSING ASM Price: $4,033.93 |
| 16 |
107-0826 |
BEARING Price: $32.70 |
| 16 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 17 |
107-0821 |
BEARING Price: $40.03 |
| 17 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 582478601. Price: $1.99 |
| 18 |
107-0838 |
BEARING Price: $62.42 |
| 18 |
539913847 |
NUT 3/8 PALNUT RTNG BLK PHOS Price: $3.99 |
| 19 |
107-0860 |
BOLT Price: $2.27 |
| 19 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 20 |
522023401 |
WASHER, 3/8 THICK Price: $2.99 |
| 21 |
596135501 |
Washers This part replaces 532413524. Price: $4.99 |
| 22 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 23 |
107-0861 |
PLUG-NPTF Price: $11.67 |
| 23 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 24 |
237-79 |
O-RING This part replaces 107-0862. Price: $5.46 |
| 25 |
107-0867 |
PLUG Price: $14.59 |
| 26 |
107-0812 |
PIPE Price: $75.78 |
| 27 |
107-0852 |
CENTER CASE SEAL KIT Price: $12.50 |
| 28 |
107-0813 |
SPACER Price: $8.69 |
| 29 |
107-0853 |
PUMP HOUSING SEAL KIT Price: $190.09 |
| 30 |
107-0828 |
PLATE-SWASH Price: $639.83 |
| 31 |
107-0808 |
VALVE-BYPASS Price: $86.68 |
| 32 |
107-0804 |
VALVE-REAR Price: $414.56 |
| 33 |
107-0803 |
VALVE-FRONT Price: $414.56 |
| 34 |
107-0863 |
BOLT Price: $1.22 |
| 35 |
107-0806 |
VALVE-FLUSHING, LH Price: $129.44 |
