| Ref | Part Number | Description |
|---|
| 1 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 1 |
532181038 |
DECAL DANGER Price: $27.99 |
| 1 |
731-3100A |
VALVE HANDLE Not Available Price: |
| 2 |
104-7704 |
SPRING-LATCH, BRAKE Price: $12.68 |
| 2 |
532191378 |
DECAL, AUGER HOUSING Price: $14.99 |
| 2 |
910-0749 |
CHAIN ADJUSTMENT BOLT Not Available This part replaces 710-0749. Price: |
| 3 |
3220-2 |
NUT-JAM Price: $0.50 |
| 3 |
532181034 |
DECAL, DANGER DEFLECTOR Price: $44.99 |
| 3 |
712-0998 |
Nut, Hex Center Lock, #10-24 Not Available Price: |
| 4 |
532181041 |
DECAL, DANGER Price: $54.99 |
| 4 |
913-3000 |
CHAIN LINK Not Available This part replaces 713-3000. Price: |
| 4 |
93-2010-01 |
FRAME ASM Price: $3,690.13 |
| 5 |
532198741 |
DECAL, HUSQVARNA, 1130SBE Price: $7.99 |
| 5 |
93-8062 |
DECAL-BRAKE, PARKING Price: $4.95 |
| 6 |
33123-016 |
SCREW-CARR Price: $1.21 |
| 6 |
532181032 |
DECAL.SNOWTHROWER.CONSOLE.INST Price: $59.99 |
| 6 |
703-1802 |
SINGLE CLAMP Not Available Price: |
| 7 |
33123-016 |
SCREW-CARR Price: $1.21 |
| 7 |
532155798 |
DECAL.TRACT.ASM.ENG.CLUTCH.K Price: $1.99 |
| 7 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 8 |
33093-00 |
WASHER-FLAT This part replaces 48-8010. Price: $0.70 |
| 8 |
532155800 |
DECAL, AUGER LEVER Price: $5.99 |
| 8 |
710-3218 |
Screw, Socket Hd Cap, 1/4-20 X .62 Lg GR8 Price: $3.86 |
| 9 |
33023-00 |
NUT-LOCK This part replaces 49-7810. Price: $0.25 |
| 9 |
532181036 |
DECAL, SPEED CONTROL Price: $19.99 |
| 9 |
727-3066 |
Tube Assy, Return Price: $182.90 |
| 10 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 10 |
532183729 |
DECAL, REMOTE DEFLECTOR Price: $37.99 |
| 10 |
921-3021 |
O-RING .301 IDX.070 This part replaces 721-3021. Price: $3.39 |
| 11 |
104-2096 |
BRACKET-SWITCH Price: $35.42 |
| 11 |
532183907 |
DECAL, LH TRIGGER Price: $5.99 |
| 11 |
727-3067 |
Tube Assy, Pressure Price: $86.36 |
| 12 |
104-7703 |
HINGE-LOWER Price: $22.15 |
| 12 |
532183905 |
DECAL, RH TRIGGER Price: $5.99 |
| 12 |
727-3068 |
Tube Assy, Adapter Price: $40.11 |
| 13 |
104-2094 |
BRAKE-LATCH Price: $150.10 |
| 13 |
532155794 |
DECAL, HUSQVARNA Price: $19.99 |
| 13 |
727-3012 |
Elbow, Tube, 90 Degree Price: $23.35 |
| 14 |
104-7702 |
PLATE-SWITCH Price: $16.15 |
| 14 |
903-1803 |
VALVE DOUBLE CLAMP Not Available This part replaces 703-1803. Price: |
| 15 |
727-3046 |
CYLINDER HOSE Not Available Price: |
| 15 |
83-1700 |
BUSHING-FLANGE Price: $7.80 |
| 16 |
727-3045 |
CYLINDER HOSE Not Available Price: |
| 16 |
93-2073-01 |
SHIELD-WHEEL, LH Price: $104.03 |
| 17 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 17 |
93-2072-01 |
SHIELD-WHEEL, RH Price: $92.07 |
| 18 |
283-61 |
PIN-YOKE Price: $1.56 |
| 18 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 19 |
282-2 |
YOKE Price: $30.04 |
| 19 |
710-0641 |
Screw, Hex Cap, 1/4-20 X 2.25 Lg Price: $3.66 |
| 20 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 20 |
703-1801 |
VALVE MOUNTING BRACKET Not Available Price: |
| 21 |
712-3006 |
HEX NUT Price: $4.05 |
| 21 |
93-2075-01 |
BRAKE PEDAL ASM Price: $188.33 |
| 22 |
93-7629 |
PAD-FOOT, BRAKE Price: $25.13 |
| 23 |
283-87 |
PIN-CLEVIS Price: $8.89 |
| 23 |
721-3002 |
O-RING-1/4 Not Available Price: |
| 24 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 25 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 26 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 26 |
703-1802 |
SINGLE CLAMP Not Available Price: |
| 27 |
33114-020 |
SCREW-HH Price: $0.28 |
| 27 |
717-3331 |
VALVE-RELIEF Not Available Price: |
| 28 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 29 |
104-2057 |
SENSOR Price: $136.35 |
