| Ref | Part Number | Description |
|---|
| 1 |
136-0381 |
BOOM-LH Price: $460.17 |
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
108-3725 |
LH SINGLE BODY TURRET ASM Price: $57.64 |
| 4 |
108-3727 |
DOUBLE TURRET BODY ASM Price: $57.64 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
108-3726 |
RH SINGLE BODY TURRET ASM Price: $57.64 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
108-3439 |
TEE Price: $10.76 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 11 |
161-4174 |
CRADLE ASM This part replaces 130-8238-03. Price: $56.88 |
| 12 |
110-5050 |
SCREW-HHF Price: $2.59 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
108-3476-03 |
CRADLE-UPPER Price: $84.74 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
108-3457 |
SPACER Price: $21.03 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
108-3742 |
SCREW-HHF Price: $1.90 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532194746. Price: $34.99 |
| 17 |
108-3489 |
CAP-TUBE Price: $3.25 |
| 18 |
110-5052 |
SCREW-HHF Price: $1.22 |
| 19 |
108-3495 |
COVER-SLIDE Price: $98.16 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
108-3743 |
WASHER Price: $2.31 |
| 21 |
108-3744 |
SCREW-SHOULDER Price: $9.60 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
114-9566 |
CLAMP-R Price: $2.78 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
95-9186 |
CAP Price: $7.89 |
| 24 |
95-9187 |
CAP-BLANK Price: $10.69 |
| 25 |
108-3735 |
HOSE-BOOM, CENTER (LH) Price: $43.48 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 27 |
3256-68 |
WASHER-FLAT Price: $2.69 |
| 28 |
110-5070 |
BUMPER Price: $10.00 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
127-8955-03 |
MOUNT-BOOM Price: $64.84 |
| 30 |
127-8956-03 |
MOUNT-BOOM Price: $69.93 |
| 31 |
110-5057 |
CAPSCREW-HHF Price: $2.71 |
| 32 |
108-3745 |
NUT-HHF, WHIZ Price: $1.15 |
| 33 |
137-1673 |
BRACKET-PIVOT This part replaces 119-4993-03. Price: $270.35 |
| 34 |
137-1674 |
HINGE This part replaces 108-3471-03. Price: $86.08 |
| 35 |
100-8541 |
BUSHING-A ARM Price: $3.49 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
108-3436 |
PIN-CLEVIS Price: $44.88 |
| 37 |
3290-468 |
PIN-COTTER Price: $0.95 |
| 38 |
110-5054 |
WASHER-FLAT Price: $1.75 |
| 39 |
108-3738 |
SCREW-HH Price: $14.09 |
| 40 |
3296-15 |
NUT-LOCK, NI Price: $1.75 |
| 41 |
108-3419 |
PIVOT PIN ASM Price: $49.14 |
| 42 |
108-3605 |
PLATE-BACKING Price: $9.08 |
| 43 |
108-3444 |
RETAINER-SPRING Price: $23.03 |
| 44 |
108-3440 |
SPRING-BREAKAWAY, BOOM Price: $20.19 |
| 45 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 46 |
108-3459 |
BOOT-HINGE Price: $16.67 |
| 47 |
120-8541 |
DAMPENER-HINGE Price: $15.09 |
| 48 |
108-3748 |
SCREW-HHF Price: $1.90 |
| 49 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 50 |
133-0412-03 |
CENTER-CENTER, BOOM Price: $263.10 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 52 |
136-0382 |
BOOM-RH Price: $460.17 |
| 53 |
136-0438 |
HOSE-FORMED Price: $30.00 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
108-3728 |
HOSE-BOOM Price: $17.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
