| Ref | Part Number | Description |
|---|
| 1 |
117-9532 |
DISCONTINUED-ORDER COMPONENTS This part replaces 99-1481. Price: Call Us |
| 1 |
532411423 |
KIT.LEVER.CONTROL.RH.AUGER This part replaces 532184110. Price: $22.99 |
| 2 |
532184109 |
LEVER, TRACTION DRIVE CONTROL Price: $9.99 |
| 2 |
99-1495 |
ADAPTER-FAN Price: $76.23 |
| 3 |
532179439 |
NUT, CAGE 1/4-20 Price: $2.99 |
| 3 |
93-2049 |
TANK-OVERFLOW Price: $89.55 |
| 4 |
532178888 |
BUSHING, FLANGE Price: $3.99 |
| 4 |
93-2090 |
FAN-ENGINE Price: $222.39 |
| 5 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 5 |
93-2445 |
BRACKET-ALTERNATOR, UPPER Price: $79.79 |
| 6 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 6 |
532199640 |
SCREW HEX This part replaces 532180402. Price: $3.99 |
| 7 |
51-2070 |
NUT Price: $0.68 |
| 7 |
532178652 |
ROD.INTERLOCK Price: $9.99 |
| 8 |
108-3283 |
HOSE-FUEL This part replaces 94-1348. Price: $4.60 |
| 8 |
532184003 |
TUBE ASSM, INTERLOCK Price: $13.99 |
| 9 |
532178651 |
TUBE.WELDMENT.INTERLOCK.LH Price: $20.99 |
| 9 |
93-2048 |
CAP-TANK, OVERFLOW Price: $39.28 |
| 10 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 10 |
532178645 |
PANEL, CONTROL This part replaces 532184106. Price: $22.99 |
| 11 |
100-3190-03 |
ENGINE MOUNT ASM Price: $241.12 |
| 11 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 12 |
874780528 |
SCREW Price: $4.99 |
| 12 |
92-5753 |
CLAMP-HOSE Price: $2.10 |
| 13 |
532436114 |
TUBE.HANDLE.LOOP.LH.BLACK This part replaces 532184107. Price: $54.99 |
| 13 |
99-1473-03 |
MOUNT-ENGINE, FRONT Price: $248.08 |
| 14 |
532407857 |
TUBE.HANDLE.LOOP.RH.BLACK This part replaces 532184108. Price: $39.99 |
| 14 |
93-2020-01 |
BRACKET-SUPPORT Price: $40.67 |
| 15 |
33114-020 |
SCREW-HH Price: $0.28 |
| 15 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 16 |
33024-00 |
NUT-LOCK, NI Price: $0.75 |
| 16 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 17 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 17 |
93-2446 |
BRACKET-ALTERNATOR, LOWER Price: $28.92 |
| 18 |
121-9076 |
MOUNT-ENGINE This part replaces 83-1030. Price: $37.76 |
| 18 |
580797701 |
ROD.IMPELLER.CONTROL.SNOW This part replaces 532179093. Price: $12.99 |
| 19 |
323-11 |
SCREW-HH Price: $1.08 |
| 19 |
532179098 |
ROD.TRACTION.CONTROL Price: $12.99 |
| 20 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 20 |
532180428 |
ROD, END CONTROL Price: $8.99 |
| 21 |
596436301 |
Nuts This part replaces 873350500. Price: $2.99 |
| 21 |
83-1040 |
WASHER-FLAT Price: $2.31 |
| 22 |
872120618 |
BOLT 3/8-16 X 2-1/4 Price: $5.99 |
| 22 |
99-9209 |
ALTERNATOR Price: $714.65 |
| 23 |
532184087 |
TUBE.LOWER.HANDLE.24.BLACK Price: $59.99 |
| 23 |
99-8153 |
BELT-V Price: $75.56 |
| 24 |
532180447 |
SLEEVE, SPRING Price: $5.99 |
| 24 |
99-4189-03 |
BRACKET-ENGINE, LH Price: $26.50 |
| 25 |
532180926 |
SPRING, TRACTION DRIVE Price: $5.99 |
| 25 |
99-4188-03 |
BRACKET-ENGINE, RH Price: $28.59 |
| 26 |
33113-016 |
SCREW-HH Price: $0.34 |
| 26 |
532178669 |
SPRING, AUGER CONTROL Price: $7.99 |
| 27 |
871210616 |
Screw, Hex Head 3/8-16 x 1 Price: $4.99 |
| 27 |
99-4190-03 |
PLATE-PUMP Price: $249.13 |
| 28 |
532180494 |
PANEL CLIP Price: $2.64 |
| 28 |
93-2588 |
SPACER-UPPER Price: $38.68 |
| 29 |
93-2174 |
SPACER Price: $76.28 |
| 30 |
33116-130 |
SCREW-HH Price: $5.61 |
| 30 |
532183346 |
PANEL.CONSOLE.HEADLIGHTS Price: $29.99 |
| 31 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 31 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 32 |
33026-00 |
NUT-HEX Price: $1.02 |
| 32 |
532750634 |
SCREW Price: $2.99 |
| 33 |
33115-050 |
SCREW-HH Price: $1.36 |
| 33 |
532184111 |
ARM.LATCH.INTERLOCK.YELLOW Price: $3.99 |
| 34 |
532183518 |
BOLT, SHOULDER Price: $2.99 |
| 34 |
99-4240 |
BRACE-WIREFORM, LH Price: $41.97 |
| 35 |
873850400 |
This part replaces 532068038. Price: $2.51 |
| 35 |
99-4238 |
BRACE-WIREFORM, RH Price: $41.15 |
| 36 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 36 |
532443215 |
SPRING.TORSION.LEVER This part replaces 532178831. Price: $3.99 |
| 37 |
323-4 |
SCREW-HH Price: $1.02 |
| 37 |
532178658 |
SPRING, INTERLOCK Price: $2.99 |
| 38 |
532178666 |
HEADLIGHT.HALOGEN.SNOW Price: $219.99 |
| 38 |
94-4538 |
SPACER-MOUNT Price: $9.70 |
| 39 |
33116-120 |
SCREW-HH Price: $1.70 |
| 39 |
532178668 |
BEZEL.HEADLIGHT.BLACK Price: $5.99 |
| 40 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 41 |
94-8156-03 |
DEFLECTOR-FAN Price: $37.85 |
| 42 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 43 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 44 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 45 |
66-6480 |
WASHER Price: $1.29 |
| 46 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
