| Ref | Part Number | Description |
|---|
| 4 |
680Z00444 |
FRONT DECK LIFT SHAFT Price: $215.75 |
| 5 |
680E00445 |
DECK LIFT HUB ASSEMBLY (LH) This part replaces 680Z00445. Price: $45.61 |
| 6 |
680E01834 |
LIFT BRACKET Price: $145.22 |
| 7 |
703-08384 |
DECK LIFT INDEX LINK Price: $9.41 |
| 8 |
703-08388A |
LIFT INDEX SLIDER ARM Price: $282.19 |
| 12 |
710-0182A |
SCREW-HEX 1/2-13 x 3.00 Price: $6.88 |
| 13 |
710-04186 |
SCREW 1/2-13 x 1.25 GR5 Price: $6.17 |
| 14 |
710-06047 |
SCREW 5/8-11 x 2.25 GR5 Price: $3.74 |
| 15 |
710-06428 |
EYE BOLT 5/8-11 x 3.63 Price: $20.29 |
| 16 |
710-3067A |
FLANGE BOLT 1/2-13:1.75:GR5 Price: $6.51 |
| 17 |
710-3096 |
SCREW 3/8-16 x 2.0 GR 8 Price: $7.03 |
| 18 |
710-3168 |
CARRIAGE BOLT 3/8-16 x 1.00 GR5 Price: $3.61 |
| 19 |
711-0231A |
CLEVIS PIN .500 x 1.875 Price: $5.48 |
| 20 |
711-04061 |
CLEVIS PIN .500 x 1.25 Price: $3.74 |
| 21 |
711-05072 |
FRONT LIFT SHAFT Price: $53.64 |
| 22 |
711-06798 |
LIFT SHAFT 1.25 DIA Price: $78.76 |
| 23 |
711-1400 |
CLEVIS PIN .50"OD Price: $37.63 |
| 24 |
712-04065 |
NUT Price: $3.68 |
| 25 |
712-04150 |
NUT Price: $3.74 |
| 26 |
712-04151 |
FLANGE LOCK NUT Price: $3.37 |
| 27 |
712-3015 |
HEX NUT Price: $4.02 |
| 28 |
714-0115 |
COTTER PIN-1/8 D Price: $3.48 |
| 29 |
714-0149B |
COTTER PIN Price: $3.95 |
| 30 |
753-04070 |
LYNCH PIN .1875 Price: $8.64 |
| 31 |
714-04003 |
COTTER PIN .125X2. Price: $7.09 |
| 32 |
718-04783 |
ELEC/HYD LIFT CYLINDER Price: $809.65 |
| 33 |
720P05965 |
DECK LIFT KNOB Price: $25.71 |
| 35 |
925-04761 |
DECK LIFT SWITCH Price: $67.14 |
| 36 |
728-04016 |
FULL TUBULAR RIVET Price: $2.85 |
| 38 |
736-0208 |
WASHER .51 x 1.5 x .07 Price: $4.02 |
| 39 |
736-0272 |
FLAT WASHER .510 x .995 Price: $4.37 |
| 40 |
736-0326 |
FLAT WASHER .510 x 1.000 x .125 Price: $3.89 |
| 41 |
736-05642 |
FLAT WASHER .53"x2.125"x.25" Price: $6.20 |
| 42 |
736-0748 |
THRUST WASHER 1.25X1.94X.063 7000 Price: $17.46 |
| 43 |
948-3051A |
FLANGE BEARING Price: $23.56 |
| 44 |
750-06078 |
SPACER 0.535 x 0.68 x 0.83 Price: $3.66 |
| 45 |
950-0960A |
SPACER .635X1.25X.445 Price: $11.65 |
