| Ref | Part Number | Description |
|---|
| 1 |
898000129 |
Nut, Flange 5/16-18 (AYP part number) Price: $5.99 |
| 2 |
532108711 |
Shield, Side, Outer, L.H. (AYP part number) Price: Call Us |
| 3 |
532008393 |
Pin, Depth Stake (AYP part number) Price: $17.99 |
| 4 |
812000036 |
Ring, Klip (AYP part number) Price: $3.99 |
| 5 |
872140508 |
Bolt, Carriage 5/16-18 x 1 (AYP part number) Price: $2.99 |
| 6 |
532008394 |
Spring (AYP part number) Price: $3.99 |
| 7 |
532008392 |
Bracket, Latch (AYP part number) Price: $3.99 |
| 8 |
532109230 |
Spring, Depth Stake (AYP part number) Price: $3.99 |
| 9 |
532144566 |
Shield, Tine (AYP part number) Price: Call Us |
| 10 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 11 |
873220500 |
Nut, Hex 5/16-18 (AYP part number) Price: $3.99 |
| 12 |
810040500 |
Washer, Lock 5/16 (AYP part number) Price: $2.99 |
| 13 |
810040400 |
Washer, Lock 1/4 (AYP part number) Price: $3.99 |
| 14 |
532008386 |
Bracket, Shield Tine (AYP part number) Price: $7.99 |
| 15 |
532108710 |
Shield, Side, Outer R.H. (AYP part number) Price: $9.47 |
| 16 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 17 |
532144568 |
Shield, Side (AYP part number) Price: Call Us |
| 18 |
872040410 |
Bolt, Carriage 1/4-20 x 1-1/4 Gr. 5 (AYP part number) Price: $3.99 |
| 19 |
532102701 |
Grip (AYP part number) Price: $3.99 |
| 20 |
873220600 |
Nut, Hex 3/8-16 (AYP part number) Price: $3.99 |
| 21 |
532138420 |
Stake, Depth (AYP part number) Price: $49.99 |
| 22 |
874930632 |
Bolt, Hex 3/8-16 x 2 (AYP part number) Price: $3.99 |
| 23 |
532004440 |
Hinge (AYP part number) Price: $3.99 |
| 24 |
872140408 |
Bolt, Carriage 1/4-20 x 1/2 Gr. 5 (AYP part number) Price: $2.99 |
| 25 |
532006712 |
VINYL CAP This part replaces 532124717. Price: $3.99 |
| 26 |
532109227 |
Pad, Idler (AYP part number) Price: $2.99 |
| 27 |
532144567 |
Shield, Leveling (AYP part number) Price: Call Us |
