| Ref | Part Number | Description |
|---|
| 1 |
3214 |
Bolt Price: Call Us |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG Price: $149.99 |
| 2 |
33-0300 |
DISCONTINUED Price: Call Us |
| 2 |
532140551 |
SEAT PIVOT BRKT Price: $3.99 |
| 3 |
274910 |
P.T.O. Lever Price: Call Us |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $2.99 |
| 4 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 4 |
819131610 |
WASHER PM Price: $3.99 |
| 5 |
32104-111 |
SCREW This part replaces 32104-11. Price: $0.20 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 6 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 7 |
251-269 |
BEARING Price: $19.20 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $2.99 |
| 8 |
32121-31 |
PIN-SPRING Price: $0.26 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 9 |
3-6514 |
THRUST WASHER Price: $1.74 |
| 9 |
819131612 |
Washer 13/32 X 1 X 12 Ga (AYP part number) This part replaces 819131614. Price: $3.99 |
| 10 |
28342 |
Clevis Pin Price: Call Us |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $14.99 |
| 11 |
27-4940 |
ENGAGE ARM WA Price: $209.84 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 12 |
3230-16 |
SCREW-CARR Price: $1.79 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $4.99 |
| 13 |
32534 |
Lockwasher Price: Call Us |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 14 |
251-253 |
BEARING Price: $22.84 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 15 |
323-8 |
SCREW-HH Price: $1.20 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
251-255 |
FLANGE Price: $15.34 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
3218-3 |
NUT-JAM Price: $0.25 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 18 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 19 |
27-8410 |
PTO BRAKE BRKT WA *BO Price: $205.83 |
| 20 |
27-8450 |
DISCONTINUED Price: Call Us |
| 21 |
27-9220 |
COMP SPRING *O Price: $25.06 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $1.99 |
| 22 |
33-0890 |
DISCONTINUED Price: Call Us |
| 22 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 23 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 24 |
3296-45 |
NUT-HEX Price: $3.79 |
| 25 |
41-9150 |
V-BELT, TORQUE TEAM This part replaces 27-4630. Price: $33.98 |
| 25 |
532127018 |
BOLT,SHOULD Price: $3.99 |
| 26 |
323-18 |
SCREW-HH Price: $0.82 |
| 27 |
29-4730 |
WASHER-FLAT Price: $13.10 |
| 28 |
274530 |
P.T.O. Pulley Price: Call Us |
| 29 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 30 |
28-5640 |
SPECIAL WASHER Price: $3.58 |
| 31 |
30240 |
Fitting-Grease Price: Call Us |
| 32 |
274980 |
Shaft P.T.O. Price: Call Us |
| 33 |
3217-6 |
NUT-HEX Price: $1.19 |
| 34 |
28-9050 |
DISCONTINUED Price: Call Us |
| 35 |
251-268 |
BEARING Price: $73.04 |
| 36 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 37 |
321-6 |
SCREW-HH Price: $0.25 |
| 38 |
251-77 |
COLLAR-LOCK, BEARING Price: $10.22 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 40 |
3217-7 |
NUT-HEX Price: $0.28 |
| 41 |
28-8950 |
DISCONTINUED Price: Call Us |
| 42 |
325641 |
Washer Price: Call Us |
| 43 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 44 |
44-9350 |
DISCONTINUED This part replaces 37-0010. Price: Call Us |
| 45 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 46 |
27-6650 |
BRG RETAINER Price: $23.44 |
| 47 |
27-6970 |
BEARING STUD Price: $23.97 |
| 48 |
321-3 |
SCREW-HH Price: $0.28 |
| 49 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 50 |
3296-5 |
NUT-HEX Price: $3.09 |
| 51 |
3220-3 |
NUT-HJ Price: $0.28 |
| 52 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 53 |
282-1 |
DISCONTINUED Price: Call Us |
| 54 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 55 |
3256-22 |
WASHER-FLAT Price: $0.39 |
