| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
98-9453 |
PULLEY-DYNAMO Price: $138.04 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029901. Price: $14.99 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
98-7708 |
NUT Price: $7.76 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 40 |
117-0316 |
DRIVE END FRAME ASM Price: $1,076.07 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 50 |
133-2811 |
BEARING This part replaces 107-0137. Price: $46.67 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 60 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 70 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683702. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
| 80 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 90 |
117-0317 |
ROTOR ASM Price: $662.02 |
| 100 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 110 |
107-0138 |
BEARING-BALL Price: $48.37 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
| 130 |
117-0322 |
HOLDER Price: $393.13 |
| 140 |
107-0141 |
BRUSH HOLDER ASM Price: $107.10 |
| 150 |
98-7724 |
BRUSH Price: $12.41 |
| 160 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 170 |
117-0319 |
REGULATOR ASM Price: $363.64 |
| 180 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 190 |
98-7727 |
SCREW-HEAD, ROUND Price: $0.94 |
| 200 |
98-7729 |
BOLT Price: $2.35 |
| 210 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 220 |
98-7731 |
BOLT Price: $3.94 |
| 230 |
117-0320 |
COVER-END Price: $107.22 |
| 240 |
117-0321 |
INSULATION-BRUSH Price: $39.99 |
| 250 |
98-7730 |
NUT Price: $1.31 |
| 260 |
98-7732 |
NUT Price: $1.45 |
