| Ref | Part Number | Description |
|---|
| 1 |
233-35 |
KNOB Price: $8.06 |
| 2 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 2 |
812000001 |
E-RING LT Price: $2.99 |
| 3 |
3219-14 |
NUT-HEX Price: $0.25 |
| 3 |
532188967 |
WASHER.HARDENED Price: $2.99 |
| 4 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 4 |
532121749 |
WASHER Price: $1.99 |
| 5 |
38-1670 |
MTNG BRKT W/38-1660 This part replaces 26-4390. Price: $16.06 |
| 5 |
532435324 |
SPINDLE.STEERING.RH.LRVA Price: $17.99 |
| 6 |
27-2360 |
SWITCH Price: $46.56 |
| 7 |
62-7770 |
KEY-IGNITION This part replaces 218-412. Price: $4.39 |
| 8 |
532421076 |
PIN.COTTER.5/64X3/4 Price: $2.99 |
| 8 |
83-0820 |
GAUGE - AMMETER This part replaces 18-2190. Price: $76.09 |
| 9 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 9 |
819131414 |
WASHER Price: $3.99 |
| 10 |
3217-29 |
NUT-HEX Price: $0.25 |
| 10 |
583445401 |
SHAFT.STEERING.LOWER.LRV This part replaces 532428038. Price: $7.99 |
| 11 |
26-6740 |
TEMP RESET RELAY Price: $165.84 |
| 12 |
26-6750 |
ENG TEMP SWITCH GAGE Price: $332.79 |
| 13 |
322-3 |
SCREW-HH Price: $0.79 |
| 13 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874780524. Price: $1.99 |
| 14 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 14 |
819131016 |
WASHER Price: $3.99 |
| 15 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 16 |
3217-6 |
NUT-HEX Price: $1.19 |
| 16 |
532428044 |
BUSHING, STEERING SNAP Price: $2.99 |
| 17 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 17 |
532428252 |
SUPPORT, UPPER STEERING Price: $9.99 |
| 18 |
3290-134 |
SCREW Price: $0.27 |
| 18 |
532195227 |
BUSHING,STEERING Price: $3.99 |
| 19 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 19 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 20 |
532428045 |
CLIP.SPRING.STEERINGG Price: $2.99 |
| 21 |
28-1590 |
THROTTLE CONTROL Price: $35.36 |
| 21 |
532428347 |
FOAM.SHAFT.STEERING Price: $7.99 |
| 22 |
3290-360 |
SCREW-HH Price: $4.34 |
| 22 |
532428213 |
SHAFT, STEERING Price: $22.99 |
| 23 |
22-7810 |
SPACER Price: $16.90 |
| 23 |
532437747 |
STEERING.WHEEL.ADAPTER Price: $19.99 |
| 24 |
119-2865 |
KIT-GM300 BUZZER, LOW OIL PRESSURE This part replaces 22-7820. Price: $135.43 |
| 24 |
819183812 |
WASHER 9/16"ID, 2 3/8""OD Price: $3.99 |
| 25 |
28-1600 |
CHOKE CONTROL Price: $42.26 |
| 25 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 26 |
532441614 |
WHEEL.STEER.STDR.498.OVRM.GRAY Price: $24.99 |
| 26 |
70-2030 |
INST PANEL DECAL This part replaces 26-6730. Price: $18.52 |
| 27 |
218-504 |
DISCONTINUED Price: Call Us |
| 27 |
532436502 |
CAP.WHL.STRNG.STDSRRD.SRS.GREY This part replaces 532441615. Price: $7.99 |
| 28 |
28-1580 |
INST PANEL Price: $130.00 |
| 28 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $2.99 |
| 30 |
532436499 |
CAP.HUB.AXLE.LRVA/B Price: $3.99 |
| 31 |
819343210 |
WASHER Price: $1.99 |
