| Ref | Part Number | Description |
|---|
| 1 |
931-05304 |
DOG CLUTCH ASSEMBLY Price: $73.75 |
| 3 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 4 |
710-04605B |
HEX SCREW WASHER 5/16-18 x 1.5 Price: $6.01 |
| 5 |
710-05074 |
SCREW 1/4-20 x 1.0 Price: $2.90 |
| 6 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 7 |
710-3209 |
SCREW M6-1.0X10MM GR8.8 Price: $7.30 |
| 8 |
712-04064 |
FLANGE LOCK NUT Price: $3.64 |
| 9 |
712-04065 |
NUT Price: $3.68 |
| 10 |
712-04150 |
NUT Price: $3.74 |
| 11 |
718-05413 |
WATER PUMP ASSEMBLY Not Available Price: |
| 12 |
923-0383 |
RETAINER STRAP ASSEMBLY Price: $13.70 |
| 13 |
731-10490 |
HANDLE Price: $34.32 |
| 14 |
734-06265 |
DECK WHEEL (5.0 DIA X 1.38) This part replaces 734-0973. Price: $11.69 |
| 15 |
735-04121 |
BUMPER Price: $3.21 |
| 16 |
735-05103 |
BUMPER PAD Not Available Price: |
| 17 |
736-0173 |
FLAT WASHER .28 ID x .74 OD x .063 Price: $3.76 |
| 18 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 19 |
937-05086 |
SUCTION HOSE Not Available Price: |
| 20 |
937-05087 |
DISCHARGE HOSE Price: $101.94 |
| 21 |
938-0373 |
SHOULDER SCREW Price: $8.45 |
| 22 |
738-04502 |
SHOULDER SCREW 1/4-20 x .50 Price: $3.75 |
| 23 |
738-1226 |
Shoulder Screw This part replaces 938-1226. Price: $6.73 |
