| Ref | Part Number | Description |
|---|
| 94 |
847026 |
KIT, Idle Mixture Price: $14.59 |
| 98 |
808177 |
KIT, Idle Speed Price: $11.64 |
| 102 |
692077 |
GASKET, Carburetor Body Price: $20.70 |
| 104 |
690723 |
PIN, Float Hinge Price: $8.23 |
| 105 |
797410 |
VALVE, Float Needle Price: $14.67 |
| 108 |
844989 |
VALVE, Choke Price: $7.91 |
| 125 |
845241 |
CARBURETOR Price: $314.57 |
| 127 |
847028 |
PLUG, Welch Price: $5.28 |
| 130 |
690726 |
VALVE, Throttle Price: $16.12 |
| 131 |
846578 |
KIT, Throttle Shaft Price: $61.59 |
| 133 |
844546 |
FLOAT, Carburetor Price: $26.40 |
| 141 |
808398 |
KIT, Choke Shaft Price: $37.94 |
| 163 |
844931 |
GASKET, Air Cleaner Price: $4.53 |
| 187 |
791766 |
LINE, Fuel Price: $7.27 |
| 231 |
690718 |
SCREW Price: $4.73 |
| 255 |
690721 |
BUSHING, Choke Shaft Price: $6.85 |
| 276A |
806137 |
WASHER, Sealing Price: $5.73 |
| 387 |
597338 |
PUMP, Fuel Price: $26.55 |
| 601 |
691038 |
CLAMP, Hose Price: $3.12 |
| 633 |
690722 |
SEAL, Choke/Throttle Shaft Price: $13.00 |
| 633A |
806131 |
SEAL, Choke/Throttle Shaft Price: $5.03 |
| 674A |
692062 |
SCREW Price: $2.92 |
| 674B |
692056 |
SCREW Price: $4.82 |
| 788 |
691559 |
BRACKET, Fuel Pump Price: $20.66 |
| 918 |
791760 |
GASKET, Breather Passage This part replaces 791880. Price: $7.74 |
