| Ref | Part Number | Description |
|---|
| 1 |
29-5670-01 |
TRACTION PEDAL This part replaces 29-5670. Price: $71.84 |
| 1 |
481876 |
Ring, Split Price: Call Us |
| 2 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 2 |
28-5130 |
TRACTION PEDAL PAD Price: $33.21 |
| 3 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 3 |
45842 |
Brake Shaft Assembly Weldment (16" Small Frame) Price: Call Us |
| 3A |
45854 |
Brake Shaft Assembly Weldment (20" Large Frame) Price: Call Us |
| 4 |
04062-01 |
COTTER PIN, HAIR - 0.94 X 1.62 Price: Call Us |
| 4 |
29-5630 |
DISCONTINUED Price: Call Us |
| 5 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 5 |
70-9830 |
SHAFT - TRACT. PEDAL This part replaces 29-5640. Price: $21.93 |
| 6 |
28-5220 |
FRICTION WHEEL ASM Price: $108.15 |
| 6 |
44126 |
Rod, Brake Lower Price: Call Us |
| 7 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 7 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 8 |
43415 |
B ushing, Brake Price: Call Us |
| 8 |
5-7570 |
WASHER-FLAT Price: $6.19 |
| 9 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 9 |
48114-05 |
Greese Fitting, Straight 1/4 - 28 Price: Call Us |
| 10 |
29-5600 |
DISCONTINUED Price: Call Us |
| 10 |
45860 |
Brake Actuator Weldment, LH Price: Call Us |
| 10A |
45861 |
Brake Actuator Weldment, RH Price: Call Us |
| 11 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" - 61" Price: Call Us |
| 11 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 12 |
3218-5 |
NUT-JAM Price: $0.27 |
| 12 |
481618 |
Tire, 16 x 6.50, 4 ply Price: Call Us |
| 13 |
481890 |
Rim Assy 481868 Rim Assy Price: Call Us |
| 13 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 14 |
3220-5 |
NUT-JAM Price: $0.65 |
| 14 |
422214 |
Lock Washer, Wheel Motor Price: Call Us |
| 15 |
04027-01 |
Hex Castle Nut, 3/4-28 UNEF Price: Call Us |
| 15 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 16 |
04028-02 |
Wheel Nut, 1/2-20 x 13/16 Price: Call Us |
| 17 |
481502 |
Wheel Assy., Price: Call Us |
| 18 |
422215 |
Brake Drum Price: Call Us |
| 19 |
04008-01 |
Bolt, Serr. Flange 1/2-20 x 4.563" Price: Call Us |
| 20 |
46928 |
Wheel Hub Assembly Price: Call Us |
| 21 |
481470 |
Brake Band Assembly Price: Call Us |
| 22 |
04063-07 |
KEY, WOODRUFF #9, 3/16 X 3/4" Price: Call Us |
| 23 |
481416 |
Wheel Motor Price: Call Us |
| 24 |
48553 |
Belt, Pump Drive (16" Small Frame) Price: Call Us |
| 24A |
48587 |
Belt, Pump Drive (20" Large Frame) Price: Call Us |
| 25 |
461397 |
Clutch, Electric (Ogura) Price: Call Us |
| 26 |
04041-28 |
Flatwasher, 7/16-.469 x 1.75 x .25 (48, 52) Price: Call Us |
| 27 |
04030-05 |
Lockwasher, 7/16” Spring Price: Call Us |
| 28 |
04102-05 |
Bolt, Hex Head 7/16-20 x 2-3/4” w/Patch, (Kawasaki FX & FT, Yamaha MX) Price: Call Us |
| 29 |
422534 |
Plate, backing Clutch Pad Price: Call Us |
| 30 |
48030-09 |
Clamp, Cable 1/2" I.D. Price: Call Us |
| 31 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 32 |
481716 |
Rubber Pad, Clutch Stop Price: Call Us |
| 33 |
422533 |
Backing Plate, Clutch Stop Price: Call Us |
| 34 |
04001-12 |
Bolt, Hex Head 5/16-18 x 1-1/2" - Front Price: Call Us |
| 35 |
482755 |
Pulley, Pump Drive Engine Price: Call Us |
| 36 |
04001-13 |
Bolt, Hex Head, 5/16-18 x 2.75 Zinc. Price: Call Us |
| 37 |
04021-05 |
Bolt, Hex Head 3/8-16 x 1" Ser. Flg. Price: Call Us |
| 38 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 39 |
461783 |
Idler Arm Weldment, Pump (incl. 38) Price: Call Us |
| 40 |
04001-172 |
Bolt, Hex Head 1/4-20 x 1" Grade 8 Black Price: Call Us |
| 41 |
483526 |
Spring, Transmission Idler Price: Call Us |
| 42 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 43 |
04050-02 |
RETAINING RING, 3/4" EXTERNAL "E" Price: Call Us |
| 44 |
04063-29 |
Key, 1/4 x 1/4 x 3-3/4" Price: Call Us |
| 45 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 46 |
483213 |
Pulley, Idler 4-1/2" Price: Call Us |
| 47 |
482649 |
Pulley, 5.45 OD - Tapered Bore" Price: Call Us |
| 48 |
482085 |
Hub, Tapered, 15mm Bore Price: Call Us |
| 49 |
04030-04 |
Lockwasher, 3/8” Spring, Kawasaki FX / FT & FT-EFI / B&S 32BV Price: Call Us |
| 50 |
04063-14 |
KEY, 5 MM X 5 MM X 25 MM Price: Call Us |
| 51 |
43504 |
Pivot, Idler Long - 52" Price: Call Us |
| 52 |
43032 |
SWIVEL JOINT, SPEED CONTROL ROD Price: Call Us |
| 53 |
422713 |
Pivot Weldment, Idler Price: Call Us |
| 54 |
04001-54 |
Bolt, Hex Head 3/8-16 x 3" - 52" Price: Call Us |
| 55 |
04001-161 |
Bolt, Hex Head 3/8-16 x 2-3/4" Full Thread Price: Call Us |
| 56 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 57 |
481873 |
Chain Price: Call Us |
| 58 |
04001-59 |
SERR. FLG. HEX HEAD CAPSCREW, 5/16-18 X 3/4 Price: Call Us |
| 59 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 60 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
