| Ref | Part Number | Description |
|---|
| 1 |
119-5043 |
MANIFOLD ASM Price: $2,479.58 |
| 2 |
119-5044-03 |
BRACKET-CONTROLLER MOUNT Price: $45.05 |
| 3 |
114-3321 |
CONTROLLER-TEC Price: $1,515.96 |
| 3 |
873220600 |
NUT.HEX.3/8-16UNC Price: $3.99 |
| 4 |
120-8589-03 |
BRACKET-TUBE Price: $60.38 |
| 4 |
532432420 |
SHIELD.INNER.BELT.GUARD.RT Price: $29.99 |
| 5 |
120-0608-03 |
HINGE Price: $130.93 |
| 5 |
532164329 |
PIN.SPIROL.FLARED Price: $3.99 |
| 6 |
120-0611-03 |
STRAP Price: $70.31 |
| 6 |
532110111 |
LEVER ASM CRT Price: $11.99 |
| 7 |
120-0613-03 |
STRAP Price: $81.86 |
| 7 |
872110404 |
BOLT Price: $3.99 |
| 8 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 8 |
532008700 |
PANEL.INDICATOR.SHIFT.BLACK Price: $2.99 |
| 9 |
322-20 |
SCREW-HH Price: $1.79 |
| 9 |
532086777 |
Screw, Hex, Washer Hd., Slotted, Thd. Cutting #10-24 x 1/2 Type D (AYP part number) Price: $1.99 |
| 10 |
110-5331 |
SPRING-COMPRESSION Price: $22.18 |
| 10 |
532009484 |
CONDUIT CLIP T Price: $3.99 |
| 11 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 12 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 12 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 13 |
321-7 |
SCREW-HH Price: $4.19 |
| 13 |
823230506 |
SET SCREW Price: $2.99 |
| 14 |
104-7201 |
NUT-HF Price: $0.69 |
| 14 |
532156117 |
SPACER-SPLIT.327 X .42 Price: $3.99 |
| 15 |
120-0646 |
HOUSING-LOWER, ULTRASONIC SENSOR Price: $89.58 |
| 15 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 16 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 16 |
532145102 |
SHEAVE, TRANSMISSION Price: $37.99 |
| 17 |
117-8114 |
SENSOR-SONIC Price: $850.04 |
| 18 |
120-0645 |
COVER-SENSOR, ULTRASONIC Price: $80.27 |
| 19 |
812000028 |
RETAINING RING LT Price: $4.99 |
| 19 |
92-0010 |
U-BOLT Price: $10.65 |
| 20 |
100-8490 |
SWITCH-ROCKER, ON-NONE-ON Price: $33.76 |
| 21 |
532110652 |
SPACER CRT Price: $3.99 |
| 22 |
874770508 |
BOLT Price: $2.99 |
| 23 |
120-0647 |
NUT Price: $21.97 |
| 23 |
532102190 |
TIRE.CHV.13X5-6 Price: $59.99 |
| 24 |
120-0648 |
PLUG-PROGRAMMING Price: $62.08 |
| 24 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 25 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 25 |
95-7652 |
LIGHT-INDICATOR Price: $45.99 |
| 26 |
120-0772 |
CAP-TUBE Price: $5.21 |
| 27 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 27 |
532132801 |
V-BELT Price: $19.99 |
| 28 |
120-0757-03 |
BRACKET-TUBE Price: $29.00 |
| 28 |
532104679 |
PULLEY-IDLER TI Price: $11.99 |
| 29 |
120-0799-03 |
STRAP Price: $92.15 |
| 29 |
812000032 |
KLIP RING Price: $3.99 |
| 30 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532159229. Price: $11.99 |
| 31 |
117-8115 |
CABLE-ULTRASONIC SENSOR, 4 METER Price: $152.18 |
| 31 |
532102194 |
BOLT CRT Price: $3.99 |
| 32 |
122-0756 |
HARNESS-WIRE, SONIC BOOM This part replaces 119-1759. Price: $920.12 |
| 32 |
532102141 |
SHIFT ARM CRT Price: $3.99 |
| 33 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 33 |
874780616 |
BOLT This part replaces 874760614. Price: $3.99 |
| 34 |
120-0761 |
BUSHING Price: $3.39 |
| 34 |
532102173 |
COUNTERWEIGHT, RH Price: $44.99 |
| 35 |
119-9432 |
DECAL-CONTROLLER Price: $24.95 |
| 35 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874760524. Price: $1.99 |
| 36 |
584366901 |
BRACKET.REINFORCEMENT.LH.PNT This part replaces 532102331. Price: $5.99 |
| 37 |
120-8575-03 |
UPPER CRADLE ASM Price: $147.46 |
| 37 |
532130812 |
ENGINE PULLEY Price: $17.99 |
| 38 |
120-8576 |
COVER-SLIDE Price: $97.57 |
| 38 |
874780544 |
BOLT HEX This part replaces 874760544. Price: $3.99 |
| 39 |
532140062 |
CAP.PLUNGER.BLACK Price: $3.99 |
| 40 |
532170488 |
SCREW.HEX.WSH.SLT.#10-24X.50 Price: $2.99 |
| 44 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 65 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873970500. Price: $2.99 |
| 66 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 532065139 |
VALVE |
STEM LT This part replaces 532124718. Price: $5.99 532065139 |
