| Ref | Part Number | Description |
|---|
| A |
117-6988 |
CHARGE PUMP KIT This part replaces 38-2670. Price: $1,753.04 |
| 1 |
92-5716 |
SECTION-CENTER Price: $2,472.04 |
| 2 |
46-7310 |
SPRING Price: $18.78 |
| 2 |
530015241 |
SCREW-6-19X5/16PLAST PA Price: $1.99 |
| 3 |
525592801 |
ASSY MUFFLER WELDED This part replaces 545081845. Price: $22.99 |
| 4 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 4 |
530058982 |
BOLT MUFFLER Price: $1.99 |
| 5 |
545081832 |
KIT GASKET 25CC Price: $11.99 |
| 6 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 6 |
545115301 |
CYLINDER CHROME 25CC Price: $26.99 |
| 7 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 7 |
530015953 |
SCREW Price: $1.99 |
| 8 |
952030249 |
PLUG-SPARK (RCJ-6Y) Price: Call Us |
| 9 |
545084901 |
ADAPTER CARBURETOR Price: $9.99 |
| 10 |
251-8 |
BEARING-BALL Price: $30.06 |
| 10 |
530016441 |
SCREW Price: $1.99 |
| 11 |
545115501 |
LINKAGE THROTTLE Price: $2.99 |
| 11 |
94-2975 |
SEAL-SHAFT Price: $24.63 |
| 12 |
28-3640 |
SHAFT-PUMP Price: $1,171.13 |
| 13 |
38-2680 |
PIN Price: $23.93 |
| 13 |
545157104 |
Price: $7.99 |
| 14 |
28-3520 |
O-RING Price: $8.44 |
| 14 |
545139303 |
Price: $0.88 |
| 15 |
530016429 |
SCREW Price: $1.99 |
| 16 |
545146501 |
Filter Price: $3.99 |
| 17 |
545139201 |
Price: $4.99 |
| 18 |
530058709 |
PURGE BULB ZAMA Price: $4.69 |
| 19 |
25-2460 |
PLUG-HH Price: $37.38 |
| 19 |
545081832 |
KIT GASKET 25CC Price: $11.99 |
| 20 |
545081832 |
KIT GASKET 25CC Price: $11.99 |
| 21 |
25-2460 |
PLUG-HH Price: $37.38 |
| 22 |
28-3400 |
O-RING Price: $6.67 |
| 22 |
530012472 |
RING-PISTON Price: $2.99 |
| 23 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 23 |
530015162 |
WRIST PIN RET. Price: $1.99 |
| 24 |
545156002 |
KIT PISTON CONN ROD FORGED This part replaces 545081865. Price: $14.99 |
| 25 |
545081826 |
KIT MODULE W/O INTERRUPT This part replaces 545158001. Price: $31.99 |
| 26 |
530016357 |
SCREW Price: $1.99 |
| 27 |
545127601 |
HARNESS WIRE Price: $5.99 |
| 28 |
545081832 |
KIT GASKET 25CC Price: $11.99 |
| 28 |
83-3880 |
PIN-SPRING Price: $2.29 |
| 29 |
530015828 |
WASHER FLAT Price: $1.99 |
| 30 |
28-3670 |
SHAFT-TRUNNION Price: $149.64 |
| 30 |
530054115 |
FLYWHEEL Price: $27.99 |
| 31 |
530015941 |
RETAINING RING Price: $1.99 |
| 32 |
530055728 |
OUTER BEARING Price: $6.99 |
| 33 |
530019264 |
Kit-Fuel Line (Small) Price: $2.99 |
| 34 |
738210101 |
BEARING BALL 6001 This part replaces 530032125. Price: $8.99 |
| 37 |
545081832 |
KIT GASKET 25CC Price: $11.99 |
| 39 |
530016386 |
SCREW Price: $5.99 |
| 42 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 43 |
110-3051 |
PLATE-VALVE Price: $684.62 |
| 47 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 49 |
83-7260 |
CONE-RELIEF, CHARGE This part replaces 67-8070. Price: $50.57 |
| 50 |
28-3480 |
BEARING Price: $74.83 |
| 69 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 70 |
25-3210 |
SEAL-LIP This part replaces 103461. Price: $23.14 |
| 71 |
252-82 |
BEARING-NEEDLE Price: $51.31 |
| 73 |
28-3400 |
O-RING Price: $6.67 |
| 300 |
110-3052 |
HOUSING ASM Price: $1,923.12 |
| 302 |
353-599 |
PIN-DOWEL Price: $2.65 |
| 308 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 309 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 315 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 324 |
28-3340 |
GASKET Price: $16.81 |
| 326 |
107-4370 |
PLUG-EXPANSION Price: $6.00 |
| 327 |
67-9090 |
PLUG Price: $41.68 |
| 328 |
136-3219 |
PLUG ASM This part replaces 28-3440. Price: $21.54 |
| 336 |
323-10 |
SCREW-HH Price: $0.89 |
| 337 |
75-0110 |
CAPSCREW-HH Price: $2.14 |
| 338 |
28-3530 |
CAPSCREW Price: $4.00 |
| 339 |
49-7830 |
CHECK VALVE KIT Price: $311.16 |
| 339A |
28-3570 |
O-RING Price: $6.06 |
| 339B |
28-3580 |
RING-BACK UP Price: $20.88 |
| 339C |
28-3590 |
O-RING Price: $4.60 |
| 340 |
75-0160 |
PLUG-PIPE Price: $4.39 |
| 342 |
136-3219 |
PLUG ASM This part replaces 28-3440. Price: $21.54 |
| 357 |
92-1773 |
SCREW-HHF Price: $3.05 |
| 358 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 373 |
94-2976 |
RING-RETAINING Price: $6.24 |
| 401 |
49-8200 |
SHAFT-MOTOR Price: $1,051.65 |
| 403 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 406 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 408 |
28-3300 |
BEARING-ROLLER Price: $137.87 |
| 409 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 416 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 419 |
28-3380 |
PLATE-VALVE, MOTOR Price: $468.61 |
