| Ref | Part Number | Description |
|---|
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532140840. Price: $219.99 |
| 1 |
603-04011-0637 |
Rops. Upper Price: Call Us |
| 2 |
100-6169 |
VALVE-SOLENOID Price: $814.43 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
603-04012-0637 |
Rops, Lower Price: Call Us |
| 3 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 3 |
703-05032-0637 |
REAR SEAT BRACKET (POWDER BLACK) Not Available Price: |
| 3 |
95-6014 |
VALVE-CHECK Price: $198.80 |
| 4 |
710-0514 |
Screw, Hex Cap, 3/8-16 x 1.0 GR5 Price: $3.78 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 4 |
95-5639 |
VALVE-SOLENOID Price: $325.77 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
710-1260A |
Screw, Hex Wash. Hd. Tapp 5/16-18 x .75 Price: $3.34 |
| 5 |
95-5638 |
VALVE-SOLENOID Price: $353.93 |
| 6 |
161-8350 |
COIL ASM This part replaces 83-2010. Price: $111.53 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
710-3032 |
Screw, Hex Cap, 1/2-13 x 1.25 GR5 Price: $5.66 |
| 7 |
100-3389 |
COIL ASM Price: $126.11 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
710-3038 |
Screw, Hex Cap, 5/16-18 x .875 GR5 Price: $4.17 |
| 8 |
353-991 |
PLUG-HEX, HOLLOW Price: $10.21 |
| 8 |
817000616 |
SCREW 3/8-16X1 This part replaces 817490616. Price: $5.99 |
| 8 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 9 |
353-988 |
PLUG-HEX Price: $10.61 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
912-3066 |
Hex Nut, 1/2-20 This part replaces 712-3066. Price: $6.01 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532155925. Price: $17.99 |
| 10 |
725-3279B |
HAZARD LAMP SWITCH Not Available This part replaces 725-3279. Price: |
| 11 |
725-3280 |
HAZARD LAMP ASSEMBLY Not Available Price: |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 12 |
726-0211 |
Nut, Speed, 5/16-18 Price: $3.90 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
731-0757-16 |
CONVOLUTED CONDUIT Not Available Price: |
| 14 |
736-0148 |
Washer, Ext. Tooth Lock, 3/8 Price: $3.19 |
| 14 |
872050411 |
Bolt Rdhd Sqnk 1/4-20x1-3/8 Price: $3.99 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 15 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 7360272. Price: $4.37 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 16 |
736-0275 |
FLAT WASHER This part replaces 7360275. Price: $5.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 17 |
736-0921 |
Washer, Lock, 1/2 Price: $3.90 |
| 18 |
532124238 |
CAP SPRING Price: $4.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532153236. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
871110814 |
BOLT.HEX.BLACK This part replaces 874780814. Price: $8.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
