TRANSMISSION
Parts (35)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 125-3013 | BRACKET-THROTTLE Price: $14.91 |
| 2 | 125-3014 | LEVER-THROTTLE Price: $25.95 |
| 2 | 589533501 | NEEDS DESCRIPTION Price: Call Us |
| 3 | 593806401 | NEEDS DESCRIPTION Price: $49.99 |
| 4 | 3290-277 | NUT-SPEED Price: $0.61 |
| 4 | 535482401 | PULLEY Price: $69.99 |
| 5 | 131-2046 | DECAL-LIGHT, CONSOLE Price: $5.90 |
| 5 | 506509201 | SPACER Price: $9.99 |
| 6 | 121-5159 | IGNITION SWITCH ASM Price: $84.21 |
| 6 | 506555901 | KEY Price: $3.99 |
| 7 | 132-9550 | DECAL-CONSOLE Price: $11.37 |
| 7 | 506597501 | WASHER Price: $6.99 |
| 8 | 125-3017 | CABLE-THROTTLE Price: $33.53 |
| 8 | 506556002 | SCREW Price: $5.99 |
| 9 | 99-7420 | PLUG-HOLE Price: $7.64 |
| 10 | 732212001 | NUT This part replaces 732212051. Price: $3.99 |
| 11 | 535484402 | TENSIONER Price: $59.99 |
| 12 | 735312600 | RETAINING RING SGA 25 Price: $2.99 |
| 13 | 506665601 | SPRING Price: $24.99 |
| 14 | 140-5247 | COVER-CHOKE This part replaces 132-9592. Price: $9.87 |
| 15 | 506675402 | BOLT Price: $5.99 |
| 16 | 581916302 | NEEDS DESCRIPTION Price: Call Us |
| 17 | 120-9751 | KNOB-OVAL, BLACK Price: $7.70 |
| 18 | 120-6310 | LCD DISPLAY ASM Price: $584.72 |
| 19 | 125-3015 | BRACKET-CLAMP, CABLE Price: $10.93 |
| 20 | 104-7201 | NUT-HF Price: $0.69 |
| 20 | 505153901 | BELT TENSIONER WHEEL ASSY Price: $54.99 |
| 21 | 66-2921 | WASHER-FRICTION Price: $2.17 |
| 22 | 321-5 | SCREW-HH Price: $0.22 |
| 23 | 104-2065 | SCREW-HWH Price: $0.28 |
| 23 | 725246151 | BOLT Price: $4.99 |
| 24 | 734116441 | SPACER Price: $3.99 |
| 25 | 544002901 | NEEDS DESCRIPTION Price: Call Us |
| 27 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 28 | 725249371 | Screw M10x25 Price: $1.82 |
