| Ref | Part Number | Description |
|---|
| 1 |
21-1820 |
STUD-RETAINER, BELT Price: $36.84 |
| 1 |
578178901 |
FENDER RT, GRAY Price: $99.99 |
| 2 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 2 |
539130374 |
FENDER, LT Price: $74.99 |
| 3 |
33114-045 |
SCREW-HH This part replaces 42-9500. Price: $0.68 |
| 3 |
599306304 |
FUEL TANK, RZ, 2.25" NECK, 202 This part replaces 578180601. Price: $229.99 |
| 4 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 4 |
575018103 |
CAP 3.5IN SEALED This part replaces 575018101. Price: $27.99 |
| 5 |
33114-030 |
SCREW-HH This part replaces 48-7730. Price: $0.50 |
| 5 |
585974906 |
THROTTLE CABLE 37" This part replaces 585974902. Price: $32.99 |
| 6 |
33113-025 |
SCREW-HH This part replaces 43-2600. Price: $1.97 |
| 6 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 7 |
48-9590 |
WASHER-LOCK This part replaces 42-9600. Price: $0.25 |
| 7 |
532175566 |
IGNITION SWITCH This part replaces 539107541. Price: $22.99 |
| 8 |
48-7800 |
SCREW-HH Price: $1.78 |
| 8 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174652. Price: $24.99 |
| 9 |
539101080 |
SWITCH, INTERLOCK This part replaces 532109553. Price: $14.99 |
| 9 |
75-9900-01 |
SUPPORT-ENGINE, FRONT This part replaces 75-9900. Price: $226.52 |
| 10 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 10 |
539102678 |
TAPPED PLATE Price: $12.99 |
| 11 |
585813002 |
PLATE.CONTROL.R/START.RZ.X431 Price: $9.99 |
| 11 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 12 |
579411601 |
BATTERY, 12 V 300 AMP DRY This part replaces 539102436. Price: $129.99 |
| 12 |
67-8890 |
DISCONTINUED Price: Call Us |
| 13 |
539131209 |
BATTERY TIE DOWN ASSEMBLY Price: $27.99 |
| 13 |
67-8310-03 |
MOUNT-ENGINE ASM This part replaces 67-8310. Price: $118.51 |
| 14 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 14 |
510231302 |
BOX, BATTERY, BLACK Price: $89.99 |
| 15 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 15 |
67-8350 |
BRACKET-GUIDE, BELT Price: $18.53 |
| 16 |
539102759 |
INSULATOR Price: $3.99 |
| 16 |
67-8340 |
BAR-SPACER Price: $15.05 |
| 17 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 17 |
576618101 |
VALVE.FUEL.CHECK Price: $14.99 |
| 18 |
539916325 |
FUEL VALVE Price: $9.99 |
| 19 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 19 |
67-8910 |
DISCONTINUED Price: Call Us |
| 20 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 20 |
70-1920 |
HOSE-VACUUM Price: $14.02 |
| 21 |
384007-5 |
Clamp-Valve Price: Call Us |
| 21 |
505280001 |
TIE WRAP, 8-3/8", W/CLIP Price: $2.99 |
| 22 |
3250-29 |
SCREW-PPH Price: $0.25 |
| 22 |
539105245 |
RUBBER GROMMET Price: $3.99 |
| 23 |
3256-21 |
WASHER-FLAT Price: $0.25 |
| 23 |
584648201 |
GROMMET.CHECK.FUEL This part replaces 576618201. Price: $3.99 |
| 24 |
532139277 |
STEM FUEL TANK This part replaces 539110432. Price: $6.99 |
| 24 |
D23E-9C369-AA |
Fuel Separator Price: Call Us |
| 25 |
539110457 |
LEFT HEADLIGHT LENS This part replaces 539110056. Price: $4.99 |
| 25 |
70-1910 |
HOSE-ADVANCE, VACUUM Price: $3.68 |
| 26 |
353055-57 |
Plug-Water Drain Price: Call Us |
| 26 |
539110455 |
LEFT HEADLIGHT RIM GREY Price: $4.99 |
| 27 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 27 |
539110453 |
RT HEADLIGHT LENS This part replaces 539110057. Price: $4.99 |
| 28 |
539110451 |
RT HEADLIGHT RIM GREY Price: $4.99 |
| 28 |
D8RZ-11002-A |
Starter Price: Call Us |
| 29 |
33114-040 |
SCREW-HH This part replaces 42-9530. Price: $1.22 |
| 29 |
586123904 |
FUEL.HOSE.SHUT.OFF.ASM.10".3" This part replaces 576660701. Price: $11.99 |
| 30 |
33094-00 |
WASHER-PLAIN This part replaces 42-9780. Price: $0.25 |
| 30 |
539932956 |
GAS LINE 10" Price: $6.99 |
| 31 |
505215101 |
FUEL LINE 3" Price: $2.99 |
| 31 |
67-9010 |
SPACER - ALT ARM Price: $7.62 |
| 32 |
574521305 |
HOSE, FUEL, 3/16" X 20" Price: $9.99 |
| 32 |
68-9400 |
NUT-FLANGE This part replaces 48-7930. Price: $2.29 |
| 33 |
33115-025 |
SCREW-HH This part replaces 48-7780. Price: $0.61 |
| 33 |
522559101 |
SHIELD, HEAT Price: $32.99 |
| 34 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 34 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 35 |
53-9480 |
WASHER-SNUBBER Price: $3.87 |
| 35 |
539133049 |
KNOB.ROUND.BALL.BLACK Price: $5.99 |
| 36 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 36 |
586108201 |
CABLE BATTERY POS RZ This part replaces 539103306. Price: $8.99 |
| 37 |
539110068 |
BATTERY CABLE, NEGATIVE Price: $7.99 |
| 37 |
67-8260 |
DISCONTINUED Price: Call Us |
| 38 |
539990053 |
WASHER 1/4 INT TOOTH Price: $2.99 |
| 38 |
67-8900 |
SPACER - ALT Price: $7.98 |
| 39 |
596437001 |
Screws This part replaces 817490408. Price: $2.99 |
| 39 |
86AB-10300-AB |
Alternator Price: Call Us |
| 40 |
574822701 |
SCR #10-24 X .75 SKT HD BLK Price: $2.99 |
| 40 |
92-9785 |
V-BELT This part replaces 67-8520. Price: $18.65 |
| 41 |
596917001 |
Screws This part replaces 539110673. Price: $2.99 |
| 41 |
89BF-10145-AB |
Arm Adjust Alternator Price: Call Us |
| 42 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 42 |
67-8460 |
PULLY-ENGINE Price: $452.39 |
| 43 |
3257-33 |
KEY-WOODRUFF Price: $1.76 |
| 43 |
596789701 |
Screws This part replaces 539111229. Price: $1.99 |
| 44 |
32128-23 |
NUT-HF Price: $1.51 |
| 44 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 45 |
32128-37 |
NUT-HF Price: $3.63 |
| 45 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 46 |
131-1821 |
MOUNT-ENGINE This part replaces 53-9680. Price: $105.39 |
| 46 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 47 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 47 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 48 |
43-3720 |
COLLAR-BEARING Price: $249.41 |
| 48 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 49 |
251-252 |
BEARING Price: $98.35 |
| 49 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 50 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 51 |
32120-69 |
RING-SNAP Price: $2.78 |
| 52 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 53 |
110-5236 |
HUB-ENGINE This part replaces 27-1960. Price: $30.97 |
| 54 |
63-1400 |
ROD-BELT Price: $17.83 |
| 55 |
3290-224 |
LOCKWASHER-PYRAMID Price: $33.25 |
| 56 |
3234-18 |
SCREW-HHF Price: $0.87 |
| 57 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
