Engine Assembly Type 1

Engine Assembly Type 1

Parts (81)

RefPart NumberDescription
1 137-6113 LONG REAR ROLLER ASM (3IN DIA)(22IN) This part replaces 114-5415. Price: $383.80
1 530069989 Kit-Muffler Old Style Price: $3.99
1 530071390 Kit-Muffler New Style Price: $11.99
2 104-8300 NUT-HF, NI Price: $0.39
2 530036577 Muffler Cover Price: $2.99
3 119-0626 SHIM-ROLLER Price: $3.23
3 530053500 Muffler Baffle-Exit Price: $0.99
4 530053499 Muffler Baffle-First Price: $1.99
5 106-3924 BRACKET-ROLLER, REAR Price: $23.58
5 530036578 Muffler Body Price: $2.99
6 3230-7 BOLT-CARR Price: $0.88
6 530042088 Muffler Spring Price: $1.99
7 114-5400 PLASTIC WIEHLE ROLLER ASM Price: $477.85
7 530015953 Screw -Cylinder Price: $1.99
8 503235112 Spark Plug This part replaces 952030201. Price: $5.99
9 32128-20 NUT-HF Price: $0.99
9 530069913 Gasket Cyl./Carb.(kit) Price: $4.99
10 322-16 SCREW-HH Price: $3.39
10 530069994 Carb. Adapter Kit This part replaces 530049301. Price: $3.99
11 3231-4 SCREW-CARR Price: $3.59
11 530016014 Screw-Carb Adaptor Price: $1.99
12 140-5690 BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85
12 530069913 Gasket-Carb.(kit) Price: $4.99
13 104-8301 NUT-HF, NI Price: $1.09
13 530038747 Choke Plate Price: $1.99
14 48-9220 WASHER-PLAIN Price: $0.87
14 530038686 Choke Shutter Price: $1.99
15 107-4026 SCREW-HH Price: $5.28
15 530036569 Filter Plate Price: $1.99
16 530015254 Washer Price: $1.99
16 94-6936 WASHER-HARDENED Price: $0.58
17 530036575 Air Filter Foam Price: $1.99
18 530036568 Air Filter Cover Price: $1.99
19 530015880 Screw Air Box Price: $1.99
20 530015887 Screw Price: $1.99
21 530015852 Choke Spacer Price: $1.99
22 530052431 Air Box Price: $1.99
23 530069971 Kit Carburetor Assy. Zama (C1U W7) Price: $17.28
24 530012416 Cylinder This part replaces 530069757. Price: $17.99
25 530036145 Spacer Ignit. Module Price: $1.99
26 530055160 Module Ignition Price: $34.99
27 530015954 Screw Ignit. Module Price: $1.99
28 581425901 SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99
29 530014663 Assy Lead Wire Price: $5.99
30 530071548 Assy Throttle Cable Price: $3.99
31 530015767 Screw Price: $1.99
32 530071356 Kit Momentary Switch Price: $4.99
33 530027569 Starter Handle Price: $1.99
34 530069232 Kit Rope Price: $3.99
35 530016080 Screw Rope Retain. Price: $1.99
36 530027953 Coupling Drive Price: $1.99
37 530069913 Gasket Cylinder (kit) Price: $4.99
38 530069615 Assy Connecting Rod Price: $14.99
39 530015162 Retainer Piston Pin Price: $1.99
40 545154009 PISTON RING This part replaces 530012472. Price: $1.99
42 530015941 Retainer Ring C'shaft Price: $1.99
43 530032124 Bearing Outer Price: $4.99
44 530019179 Seal C'case Price: $2.99
45 530015945 Retain. Ring C'case Price: $1.99
46 530032125 Bearing Inner Price: $11.99
47 530015934 Screw Shrd/Fan Hsg. Price: $1.99
48 530016386 SCREW This part replaces 530015810. Price: $5.99
49 530054536 Guard Muffler Price: $1.99
50 530038685 Shroud Rear Price: $3.99
52 530054083 Assy Crankshaft Price: $5.99
55 545221701 FLYWHEEL ASSY This part replaces 530069886. Price: $8.99
56 530015828 Washer Flat Price: $1.99
57 530016224 Screw Pulley Price: $1.99
58 530053985 Retainer Pulley Price: $0.99
60 545008010 STARTER SPRING This part replaces 530042085. Price: $3.99
61 530014919 Assy Fan Housing Price: $3.33
62 530015768 Locknut Price: $1.99
63 530016386 SCREW This part replaces 530015810. Price: $5.99
65 530069380 Kit Spark Arrestor Old Style Price: $3.99
65 530071391 Kit Spark Arrestor New Style Price: $7.99
66 530015886 Screw Price: $1.99
67 530016131 Washer Price: $1.99
68 545103802 FUEL TANK ASSY This part replaces 530049379. Price: $12.99
69 530014347 Assy Fuel Cap Price: $4.99
70 530095646 Assy Fuel Pickup Price: $2.99
71 530069216 Fuel Line Tank/Purge Price: $3.99
