| Ref | Part Number | Description |
|---|
| 1 |
3220-3 |
NUT-HJ Price: $0.28 |
| 1 |
532199114 |
DECAL.FEND.INS/WARN.HY Price: $8.99 |
| 2 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 2 |
532402128 |
DECAL.HOOD.TOP.INSERT. Price: $11.99 |
| 3 |
323-8 |
SCREW-HH Price: $1.20 |
| 3 |
581579501 |
DECAL.MOWER.WARN.KEEP.HAND.AWY This part replaces 532170563. Price: $3.99 |
| 4 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 5 |
532178502 |
DECAL CLUTCH/BRAKE Price: $7.99 |
| 6 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 6 |
532191652 |
DECAL.ENG.B&S.24 Price: $3.99 |
| 7 |
75-6580 |
CABLE-PEDAL Price: $34.72 |
| 8 |
531229002 |
DECAL.DECK.BELT.ROUTING.48/54 This part replaces 532198785. Price: $1.99 |
| 8 |
75-3270-03 |
HUB-PIVOT, TRACTION This part replaces 75-3270. Price: $144.73 |
| 9 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 9 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 10 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 11 |
49-6440-03 |
PEDAL-FORWARD This part replaces 49-6440. Price: $84.90 |
| 12 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 13 |
532404484 |
DECAL.WHEEL.STRG.LGN.H Price: $7.99 |
| 13 |
75-2970 |
PEDAL-TRACTION Price: $135.64 |
| 14 |
532404471 |
DECAL.PANEL.SIDE.GTH2454T.HUSQ Price: $5.99 |
| 14 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 15 |
532423829 |
DECAL.WARNING.CUST.RESP.E85. This part replaces 532180941. Price: $14.99 |
| 16 |
112-5084 |
BRACKET-LEVER This part replaces 75-6510. Price: $61.39 |
| 16 |
581627301 |
DECAL.BADGE.170MM.TEXTLOGO. This part replaces 532402832. Price: $11.99 |
| 17 |
532404313 |
DECAL.RPL.B&S.24/HYD.5 Price: $2.99 |
| 17 |
75-6550 |
DISC-FRICTION Price: $7.96 |
| 18 |
75-6710 |
DECAL - FAST/SLOW Price: $5.87 |
| 19 |
233-42 |
KNOB Price: $12.88 |
| 20 |
75-6490 |
LEVER ASM Price: $78.45 |
| 21 |
3290-461 |
WASHER-SPRING Price: $3.89 |
| 22 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 23 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 24 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 25 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 28 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 29 |
63-7733 |
LH BRAKE CABLE ASM Price: $210.39 |
| 30 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 31 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 32 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 33 |
75-1440-03 |
PEDAL-BRAKE, LH This part replaces 75-1440. Price: $207.74 |
| 34 |
256-42 |
BUSHING Price: $7.03 |
| 35 |
75-1430 |
RH BRAKE PEDAL ASM Price: $255.51 |
| 36 |
75-1470 |
PIN-PIVOT, BRAKE Price: $45.68 |
| 37 |
75-2170-03 |
TUBE-CONTROL, PUMP This part replaces 75-2170. Price: $103.73 |
| 38 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 39 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 40 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 532404382 |
MANUAL.O.GTH2454T.E |
Price: $10.62 532404382 |
| 532439882 |
PAD.FOOTREST.HUSQ.GT.LH.GREY |
This part replaces 532401771. Price: $5.99 532439882 |
| 532441542 |
PAD.FOOTREST.HUSQ.GT.RH |
This part replaces 532401770. Price: $9.99 532441542 |
| 581724801 |
DECAL.BYPASS.FENDER.CRD/LT/YT |
This part replaces 532166960. Price: $3.99 581724801 |
