| Ref | Part Number | Description |
|---|
| 1 |
125-7044 |
OIL PUMP ASM Price: $432.63 |
| 1 |
583810001 |
DECK.SVC.48.CC.ASM.668 Price: $699.99 |
| 2 |
539131898 |
MANDREL ASM, CAST IRON Price: $69.99 |
| 3 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 4 |
532173434 |
MANDREL PULLEY Price: $14.99 |
| 5 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 7 |
593649701 |
GSPW Deflectors Price: $84.99 |
| 8 |
587354701 |
SPRING.42.FCS.DEFLECTOR Price: $5.99 |
| 10 |
588811002 |
BLADE.BAGGER.RES.CLRCT.48".BLK Price: $29.99 |
| 11 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 14 |
125-7021 |
GASKET Price: $2.87 |
| 15 |
125-7232 |
BOLT Price: $3.28 |
| 15 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 16 |
125-6987 |
DIPSTICK Price: $68.96 |
| 16 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 17 |
125-6954 |
GUIDE-DIPSTICK Price: $9.80 |
| 18 |
125-7022 |
GASKET Price: $7.07 |
| 18 |
529470302 |
IDLER ARM This part replaces 588812202. Price: $6.99 |
| 19 |
125-7023 |
PIPE ASM Price: $44.23 |
| 19 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 20 |
125-7217 |
BOLT Price: $4.58 |
| 21 |
125-7074 |
COOLER ASM Price: $811.84 |
| 22 |
125-7075 |
O-RING Price: $20.90 |
| 22 |
589527301 |
WHEEL.GAUGE.RALLY Price: $8.99 |
| 23 |
125-7041 |
NUT-COOLER, OIL Price: $51.50 |
| 23 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 24 |
125-6989 |
BRACKET ASM Price: $67.51 |
| 24 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 25 |
127-3009 |
BRACKET ASM This part replaces 125-6930. Price: $82.05 |
| 26 |
125-7042 |
STUD Price: $37.63 |
| 26 |
588438301 |
SCREW.7/16-14 X 2.125.WASHER Price: $5.99 |
| 27 |
125-7024 |
GASKET Price: $3.16 |
| 29 |
125-6990 |
JOINT Price: $64.80 |
| 30 |
125-7078 |
PIPE ASM Price: $40.64 |
| 31 |
125-7162 |
CLIP Price: $6.55 |
| 31 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 33 |
125-7191 |
CLAMP-HOSE Price: $15.78 |
| 34 |
125-7079 |
PIPE ASM Price: $41.11 |
| 34 |
532178515 |
WASHER Price: $5.99 |
| 35 |
125-7162 |
CLIP Price: $6.55 |
| 36 |
536050602 |
LINK FIXED MOWER DRAWBAR BLACK This part replaces 587140502. Price: $5.99 |
| 37 |
125-6946 |
TUBE Price: $44.23 |
| 38 |
125-7191 |
CLAMP-HOSE Price: $15.78 |
| 39 |
125-7001 |
ELBOW Price: $40.49 |
| 39 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 40 |
125-7595 |
BOLT Price: $2.39 |
| 40 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 41 |
125-7171 |
PLUG-DRAIN Price: $23.08 |
| 41 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 42 |
583810001 |
DECK.SVC.48.CC.ASM.668 This part replaces 589428801. Price: $699.99 |
| 50 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 53 |
599275701 |
Belts This part replaces 588814301. Price: $54.99 |
| 54 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 55 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 56 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 57 |
587358401 |
SPRING.EXTN.42.FCS.TR.DECK.DRV Price: $6.99 |
| 58 |
532110485 |
BEARING Price: $11.99 |
| 61 |
596274401 |
Rods This part replaces 532400337. Price: $9.99 |
| 62 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 63 |
596637301 |
Screws This part replaces 817490410. Price: $2.99 |
| 64 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 67 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 68 |
599972501 |
BOLT This part replaces 817490628. Price: $2.99 |
| 69 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 70 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 71 |
532110452 |
NUT PUSH M Price: $2.99 |
| 73 |
588812402 |
COVER.PNT.MANDREL.RH.GREY Price: $34.99 |
| 74 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 75 |
588813102 |
COVER.PNT.MANDREL.LH.TR.GREY Price: $17.99 |
| 76 |
582541103 |
BUMPER 48 CLEARCUT TRIM SIDE A Price: $11.99 |
| 77 |
582360501 |
BUSHING.NOSE.ROLLER Price: $3.99 |
| 79 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 80 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 81 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
