| Ref | Part Number | Description |
|---|
| 1 |
137-6113 |
LONG REAR ROLLER ASM (3IN DIA)(22IN) This part replaces 107-4024. Price: $383.80 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532121265. Price: $139.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
874760412 |
Bolt Hex Hd 1/4-20unc X 3/4 (AYP part number) Price: $3.99 |
| 3 |
106-3925 |
SHIM-ROLLER (0.25) Price: $5.22 |
| 3 |
819091016 |
Washer 9/32 X 5/8 X 16 Ga. (AYP part number) Price: $2.99 |
| 4 |
810040400 |
Washer Lock Hvy Helical 1/4 (AYP part number) Price: $3.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
532121264 |
Caps Battery 20/25/30 AMP (AYP part number) Price: $10.91 |
| 6 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 6 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM This part replaces 110-4050. Price: $477.85 |
| 7 |
532109238 |
Tube Plastic 12" (AYP part number) Price: $5.46 |
| 8 |
532144940 |
Case Battery (AYP part number) This part replaces 532129965. Price: $24.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
532109596 |
Clamp Hose Olive (AYP part number) Price: $2.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 107-2952. Price: $20.85 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 19 |
810040400 |
LOCKWASHER This part replaces 810090400. Price: $3.99 |
| 20 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873350400. Price: $3.99 |
| 21 |
532136850 |
Harness Asm Light W/4152j (AYP part number) Price: $15.99 |
| 22 |
532004152 |
Bulb Light #1156 (AYP part number) Price: $2.99 |
| 23 |
811150400 |
Washer Lock Internal Tooth 1/4 (AYP part number) Price: $2.99 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $6.99 |
| 25 |
532132202 |
Cable Battery 6 Ga 43" red (AYP part number) Price: $14.69 |
| 26 |
532108824 |
Fuse 30 AMP Auto Green (AYP part number) Price: $3.99 |
| 28 |
532124773 |
Cable Ground 6 Ga 12" black (AYP part number) Price: $4.99 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $7.99 |
| 30 |
532140301 |
Switch Ign 4 pos w/lights (AYP part number) Price: $22.99 |
| 31 |
532124211 |
Nut Ignition (AYP part number) Price: $3.99 |
| 32 |
532141226 |
Cover Sw Ignition (AYP part number) Price: $3.99 |
| 33 |
532122147 |
Key Ign Modleded Generic (AYP part number) Price: $4.99 |
| 35 |
532108236 |
Bracket Switch Clutch (AYP part number) Price: $2.99 |
| 36 |
817021008 |
Screw Tap Hex #10-24unc X 1/2 (AYP part number) Price: $1.99 |
| 37 |
532104445 |
Switch Intlk Clutch Red 2 Term (AYP part number) Price: $9.99 |
| 38 |
532140336 |
Bracket, Switch, Interlock (AYP part number) Price: $2.42 |
| 39 |
539101080 |
SWITCH, INTERLOCK This part replaces 532109553. Price: $4.99 |
| 40 |
532140707 |
Harness Chassis LT PL Mech (AYP part number) Price: $58.53 |
| 41 |
539990071 |
HCS 1/4-20. This part replaces 871110408. Price: $1.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532138406 |
Solenoid (AYP part number) Price: $19.99 |
| 44 |
873640400 |
Nut Keps Hex 1/4-20 Unc (AYP part number) Price: $2.99 |
| 45 |
532140844 |
Adapter Ammeter Rectangular (AYP part number) Price: $3.99 |
| 46 |
532141940 |
Protection Wire Loop Price: $3.99 |
| 69 |
532140660 |
Harness Adapter Serv Geardrive (AYP part number) Price: $3.35 |
| 70 |
532141163 |
Harness, Eng. (AYP part number) Price: $14.09 |
