| Ref | Part Number | Description |
|---|
| 1 |
117-0158 |
LIFT CONTROL MANIFOLD ASM Price: $1,840.83 |
| 1 |
539101109 |
HUB.WHEEL.ZTR Price: $84.99 |
| 2 |
117-0180 |
HOSE-HYD Price: $95.39 |
| 2 |
539101151 |
RETAINING RING, 7/8" Price: $1.99 |
| 3 |
163-3531 |
CYLINDER-HYDRAULIC This part replaces 119-6989. Price: $517.81 |
| 3 |
587653903 |
Nuts This part replaces 539101173. Price: $3.99 |
| 4 |
119-6990 |
HYD CYLINDER ASM Price: $562.41 |
| 4 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 5 |
119-6991 |
HYD CYLINDER ASM Price: $562.41 |
| 5 |
539101332 |
HCS 1/2C X 2 3/4 Price: $4.99 |
| 6 |
117-0253 |
HOSE-HYD Price: $109.19 |
| 6 |
539102797 |
FLANGE BEARING Price: $9.99 |
| 7 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 7 |
539105029 |
BRACKET Price: $8.99 |
| 8 |
539105036 |
GRIP, PARK BRAKE Price: $3.99 |
| 8 |
92-5694 |
HOSE-HYDRAULIC Price: $92.15 |
| 9 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 9 |
522905001 |
TIRE 23X8.5-12 This part replaces 539107432. Price: $299.99 |
| 10 |
117-0262 |
HOSE-HYD Price: $135.67 |
| 10 |
539108554 |
MOTOR STANDOFF, TE, BLK Price: $54.99 |
| 11 |
117-0261 |
HOSE-HYD Price: $133.49 |
| 11 |
539108614 |
TIRE WHEEL ASM 23X8.5-12 Price: $329.99 |
| 12 |
539108616 |
BRAKE LEVER WLDMT Price: $44.99 |
| 12 |
85-4940 |
HOSE-HYD Price: $103.60 |
| 13 |
2412-137 |
CLAMP-R, DOUBLE Price: $5.08 |
| 13 |
539108619 |
BUSHING Price: $2.99 |
| 14 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 14 |
539108621 |
BRAKE SHAFT WLDMT Price: $59.99 |
| 15 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 15 |
539108637 |
LINKAGE Price: $19.99 |
| 16 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 16 |
539109344 |
RIM - 12 X 7 Price: $109.99 |
| 17 |
117-0148 |
PIN-CYLINDER Price: $52.54 |
| 17 |
539912234 |
VALVE STEM TR-412 Price: $3.99 |
| 18 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 18 |
539923787 |
BSHG .875 X 1.375 X .074 ZD Price: $2.99 |
| 19 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 19 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 20 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 20 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 21 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 21 |
596739901 |
Yoke This part replaces 539977465. Price: $27.99 |
| 22 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 22 |
539977703 |
CLEVIS PIN 3/8 X 1 1/8 Price: $4.99 |
| 23 |
323-9 |
SCREW-HH Price: $1.29 |
| 23 |
539990155 |
NUT 3/8F Price: $2.99 |
| 24 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 24 |
539990297 |
COTTER PIN Price: $2.99 |
| 25 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 26 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 27 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 28 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 29 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 30 |
539103527 |
WHEEL MOTOR Price: $649.99 |
| 32 |
539105277 |
CASTLE-NUT Price: $8.99 |
| 33 |
587653903 |
Nuts This part replaces 539101173. Price: $3.99 |
| 34 |
539990622 |
HCS 1/2C X 1 1/4 SERRATED HEAD Price: $3.99 |
