| Ref | Part Number | Description |
|---|
| MK420 |
Mulcher |
Kit with Blades Price: Call Us MK420 |
| 1 |
3219-14 |
NUT-HEX Price: $0.25 |
| 1 |
532157032 |
DECAL SET Price: $12.99 |
| 2 |
38-1670 |
MTNG BRKT W/38-1660 Price: $16.06 |
| 2 |
532145005 |
DECAL BTRY SYMBOLS Price: $3.99 |
| 3 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 3 |
532150729 |
DECAL, HOOD RH YTH150 Price: $9.03 |
| 4 |
3290-134 |
SCREW Price: $0.27 |
| 4 |
532150730 |
DECAL, HOOD LH YTH150 Price: $9.57 |
| 5 |
38-1650 |
FUEL GAUGE Price: $185.83 |
| 5 |
532166103 |
DECAL Price: $2.97 |
| 6 |
44-2220 |
LEAD WIRE ASM Price: $9.24 |
| 7 |
233-35 |
KNOB Price: $8.06 |
| 8 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 8 |
532137259 |
DECAL WARNING (ENGLISH/FRENCH) Price: $8.99 |
| 9 |
218-533 |
LENS Price: $17.62 |
| 9 |
532150617 |
DECAL FENDER HUSQ Price: $2.39 |
| 10 |
532157140 |
DECAL FENDER DANGER Price: $12.99 |
| 10 |
99-2319 |
KEY-SWITCH Price: $39.94 |
| 11 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 12 |
532157007 |
DECAL Price: $2.89 |
| 12 |
83-0820 |
GAUGE - AMMETER This part replaces 38-1660. Price: $76.09 |
| 13 |
218-539 |
DISCONTINUED Price: Call Us |
| 14 |
42-9190 |
GLOW LAMP (F/W & PPP) Price: $89.59 |
| 14 |
531229001 |
DECAL.DECK.BELT.ROUTE.42"2021 This part replaces 532160396. Price: $1.99 |
| 15 |
26-6750 |
ENG TEMP SWITCH GAGE Price: $332.79 |
| 16 |
43-3970-03 |
INSTRUMENT PANEL This part replaces 43-3970. Price: $111.29 |
| 17 |
218-473 |
BOOT-SWITCH Price: $17.61 |
| 18 |
26-6740 |
TEMP RESET RELAY Price: $165.84 |
| 19 |
6-1659 |
SWITCH & BOOT ASM Price: $78.15 |
| 21 |
43-4000 |
CIRCUIT BREAKER Price: $116.55 |
| 22 |
3250-17 |
SCREW-PPH Price: $1.76 |
| 23 |
43-3990 |
CONTROL-THROTTLE Price: $49.39 |
| 24 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 25 |
43-0410 |
REGULATOR (F/W & PPP) Price: $416.45 |
| 26 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 27 |
43-1880 |
CONT UNIT (F/W ENG&PPP) Price: $434.93 |
| 28 |
3290-424 |
SCREW-SHH Price: $2.54 |
| 29 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 30 |
321-4 |
SCREW-HH Price: $0.99 |
| 31 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 32 |
3217-6 |
NUT-HEX Price: $1.19 |
| 33 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 34 |
43-3820 |
BUZZER SPACER Price: $2.80 |
| 35 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 36 |
119-2865 |
KIT-GM300 BUZZER, LOW OIL PRESSURE This part replaces 22-7820. Price: $135.43 |
| 37 |
3217-25 |
NUT-HEX Price: $0.25 |
| 38 |
3255-20 |
WASHER-LOCK Price: $0.25 |
| 40 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 41 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 42 |
70-1480 |
RELAY Price: $105.19 |
| 43 |
70-1190 |
DISCONTINUED Price: Call Us |
| 44 |
321-6 |
SCREW-HH Price: $0.25 |
| 46 |
43-3980 |
INST PANEL DECAL Price: $32.94 |
| 47 |
2412-74 |
R-CLAMP Price: $2.37 |
| 48 |
37-2690 |
CAPACITOR Price: $155.98 |
| 49 |
38-2860 |
RESISTOR- 5 OHM Price: $71.95 |
| 50 |
100-6560 |
BRACKET-CAPACITOR Price: $11.89 |
| 51 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 532142341 |
DECAL |
DRAWBAR CONTROL Price: $2.42 532142341 |
| 532168439 |
Manual |
Owner's (English) Price: Call Us 532168439 |
| 532168440 |
Manual |
Owner's (French) Price: Call Us 532168440 |
| 532184310 |
PAD |
FOOTREST LH This part replaces 532154515. Price: $8.99 532184310 |
| 532184311 |
PAD |
FOOTREST RH BLACK This part replaces 532154516. Price: $8.99 532184311 |
| 581724901 |
DECAL.TRACTOR.6MIL.H/ADJUST |
This part replaces 532138311. Price: $9.99 581724901 |
