| Ref | Part Number | Description |
|---|
| 1 |
115-8293-0P |
TUBE-SHORT This part replaces 115-8293-03. Price: $224.35 |
| 1 |
585864805 |
HANDLE.UP.DST.SS/VS.FG/RG.NHB Price: $11.99 |
| 2 |
114-5410 |
SHAFT-SHORT, REAR ROLLER Price: $128.74 |
| 2 |
532420939 |
CABLE.MZR.FGD.PLUS Price: $11.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
532430034 |
BRACKET.UPSTOP.RT Price: $2.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
532191938 |
KNOB, DEFLECTOR Price: $2.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
532178848 |
SCREW Price: $3.99 |
| 8 |
581802001 |
BAIL.MZR.STRAIGHT.22+.YELLOW Price: $11.99 |
| 9 |
532421084 |
DOOR.REAR.22PLUS.MB.FGD.SAFETY Price: $17.99 |
| 11 |
532425575 |
COTTER.HAIRPIN.DOOR/HANDLE.PIV Price: $2.99 |
| 13 |
532437516 |
PLUG.PLASTIC.7/8".14-20.GAUGE Price: $2.99 |
| 17 |
532427307 |
BAFFLE.22PLUS.FGD.REAR. Price: $11.99 |
| 18 |
581912601 |
T-KNOB.NEW ROPE GUIDE Price: $1.99 |
| 19 |
581902101 |
GUIDE.ROPE.BLK.ZINC.CHROM Price: $1.99 |
| 20 |
532429157 |
SKIRT.REAR.22PLUS.RGD/FGD.NEW Price: $11.99 |
| 21 |
532419949 |
SPRING.LH.GRAY Price: $2.99 |
| 22 |
532141841 |
SCREW.PAN.HEAD.#10 Price: $3.99 |
| 24 |
532419948 |
SPRING.RH.GRAY Price: $2.99 |
| 25 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT Price: $2.99 |
| 26 |
532419945 |
SCREW,DOOR/HANDLE.PIVOT Price: $2.99 |
| 27 |
581009412 |
WHEEL.8X1.75.CF5SPK.RAD3.MARIG Price: $8.99 |
| 28 |
586212501 |
BOLT.CARRIAGE.LN.5/16-18X.5/8 Price: $1.99 |
| 31 |
532701037 |
SELECTOR KNOB Price: $2.99 |
| 34 |
532438134 |
BRACKET.GRASSBAG.ATTACHING.BLK Price: $2.99 |
| 39 |
585900702 |
BRACKET.ASM.HANDLE.LT.22+.BLAC Price: $17.99 |
| 40 |
585900802 |
BRACKET.ASM.HANDLE.RT.22+.BLAC Price: $17.99 |
| 41 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $3.99 |
| 44 |
585951402 |
KIT.HSG.22+REAR.FGD.WO.428.TRI Price: $109.99 |
| 46 |
581352401 |
ADAPTOR.BLADE.7/8".STAR Price: $19.99 |
| 47 |
532420463 |
BLADE.22PLUS Price: $12.99 |
| 48 |
532851074 |
WASHER,HARDEN Price: $2.99 |
| 49 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 50 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.99 |
| 51 |
532430599 |
BAFFLE.FRONT.22.PLUS Price: $11.99 |
| 53 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 55 |
532191730 |
NUT.HEX.FLANGE.1/4 Price: $3.99 |
| 56 |
817411312 |
SCREW.HX.13X.750 Price: $3.99 |
| 57 |
532155377 |
NUT.FLANGE.5/16 Price: $3.99 |
| 58 |
585908202 |
HANDLE.LOWER.22+.BT.2PC.BLK Price: $5.99 |
| 59 |
532191574 |
BOLT, HANDLE 5/16-18X1.75 Price: $1.99 |
| 62 |
532425711 |
BRACKET.KEEPER.BELT This part replaces 532435059. Price: $4.99 |
| 83 |
817021008 |
Screw, Hex Hd. Tap #10-24 x 1/2 (AYP part number) This part replaces 532750097. Price: $1.99 |
| 84 |
532428124 |
FASTENER.PUSH.O.250X0.783 Price: $2.99 |
| 85 |
532434530 |
BRACKET.SKIRT.22+.BZP Price: $2.99 |
| 96 |
532197991 |
CLIP.CABLE.BLK Price: $3.99 |
