| Ref | Part Number | Description |
|---|
| 3 |
W92531GS |
Bracket, Support Engine Price: $20.99 |
| 4 |
190220GS |
Adapter, Engine Price: $40.82 |
| 7 |
W190723GS |
Bracket, Support Eng/Muffler Price: $22.49 |
| 8 |
96796GS |
Washer, 8.4 x 22.2 x 3 Price: $2.79 |
| 10 |
190274DGS |
SBHC, 3/8-16 x 7/8" Price: $2.85 |
| 11 |
187365CGS |
HHCS, 5/16 - 24 x 9.29 Price: $20.99 |
| 12 |
189302LGS |
Wire, #16, Red Price: $18.39 |
| 14 |
92532GS |
Bracket, Muffler Price: $18.18 |
| 15 |
710250 |
Gasket, Exhaust Price: $7.18 |
| 17 |
B4206AGS |
Muffler Price: $50.70 |
| 18 |
67989GS |
Nut, M8 Flange Serrated Price: $2.77 |
| 19 |
83083GS |
Screen, Spark Arrest Price: $8.49 |
| 20 |
B4986GS |
Decal, Ground Price: $2.75 |
| 21 |
194155GS |
Kit, Vibration Mount Price: $13.90 |
| 22 |
86494GS |
Screw, Wing M6 - 1.0 x 16 Price: $2.51 |
| 24 |
194390GS |
Assy., Heat Shield Price: $75.99 |
| 25 |
191190GS |
Cap Price: $3.09 |
| 26 |
74908GS |
Taptite, M5 - 0.8 x 10 Price: $2.69 |
| 29 |
198222GS |
Kit, Vibration Mount Price: $14.76 |
| 30 |
204418GS |
Decal, Warning, Exhaust Price: $7.19 |
| 31 |
200310GS |
Decal, Warning Exhaust Price: $14.83 |
| 34 |
195422GS |
Cover, RBC Plastic with Cap Price: $12.35 |
| 36 |
192376GS |
Screw, 12 - 24 x 1/2 Thread Forming Price: $2.89 |
| 37 |
56893GS |
Crimptite, 10-24 x 1/2 Price: $1.95 |
| 38 |
B2153GS |
Screw, Self Driller, 12-14 x 7/8 Price: $3.95 |
| 39 |
B196810GS |
Bracket, Starter Price: $28.88 |
| 40 |
198221GS |
Kit, Hardware, Fuel Tank Price: $6.10 |
| 41 |
310574GS |
VALVE, Fuel This part replaces 193272GS. Price: $9.40 |
| 42 |
200311GS |
Decal, Neutral Bonded Price: $6.99 |
| 43 |
691656 |
SOLENOID, Starter Price: $29.23 |
| 45 |
189135GS |
Cap, Tank Fuel Price: $17.23 |
| 47 |
77395GS |
Nut, M6 Flange Lock Price: $3.09 |
| 48 |
195373GS |
Wire, Ground Price: $1.85 |
| 50 |
188333GS |
Decal, Instruction Fuel Level Price: $20.85 |
| 51 |
194984GS |
Decal, Warning, French Price: $13.99 |
| 52 |
94480GS |
Decal, Start Instructions Price: $14.83 |
| 53 |
192724GS |
Gauge, Fuel Price: $6.70 |
| 54 |
194448GS |
Kit, Insulation w/Clip Price: $25.55 |
| 55 |
197798GS |
Decal, Fuel Shutoff Price: $7.89 |
| 56 |
202997GS |
Decal, Co Warning Price: $12.80 |
| 58 |
204726GS |
Assy, Control Panel Price: $189.91 |
| 59 |
189164GS |
Palnut, 3/16 Price: $3.28 |
| 60 |
204594GS |
Heatsheild Price: $78.99 |
| 61 |
704130 |
SCREW, HEX, 1/4-20X.5 This part replaces B4300GS. Price: $3.28 |
| 68 |
195680GS |
Tray, Battery Price: $58.29 |
| 69 |
193463GS |
Battery Price: $139.09 |
| 70 |
87799GS |
Switch, Rocker On/Off Price: $4.89 |
| 71 |
312004GS |
JACK-COAXIAL This part replaces 196626GS. Price: $8.35 |
| 73 |
192351GS |
Lug, 1/4, #22/18 Price: $1.65 |
| 74 |
193347GS |
Kit, Hardware Battery Price: $2.49 |
| 75 |
196627AGS |
Wire-A, #13, Red Price: $3.70 |
| 76 |
185939KGS |
Wire, #55 Blk Price: $10.30 |
| 77 |
196627BGS |
Wire-A, #13B, Red Price: $3.70 |
| 78 |
189302MGS |
Wire, #13 Red Price: $18.39 |
| 81 |
196627EGS |
Wire-A, #0, Blk Price: $2.75 |
| 99 |
310574GS |
VALVE, Fuel This part replaces 189759GS. Price: $9.40 |
