| Ref | Part Number | Description |
|---|
| 1 |
539106758 |
HANDLE GRAY Price: $249.00 |
| 2 |
539052561 |
FOAM GRIP Price: $5.99 |
| 3 |
539106688 |
CABLE TAB POWER RAKE Price: $19.99 |
| 3 |
741-0370 |
ROLLER BEARING CUP Not Available Price: |
| 4 |
539990639 |
SCW 1/4-20 X 1-1/2 HEX Price: $2.99 |
| 4 |
741-0371 |
BEARING ASSY, PINION SHAFT REAR CONE Not Available Price: |
| 5 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 6 |
539100481 |
KNOB Price: $3.99 |
| 6 |
716-0138 |
RETAINING RING Not Available Price: |
| 7 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 7 |
717-3126 |
GEAR-REDUCTION Not Available Price: |
| 8 |
539100556 |
DETENT PIN RAKE/DT Price: $7.99 |
| 9 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 9 |
741-04548 |
Cup Bearing This part replaces 741-0372. Price: $7.72 |
| 10 |
539106760 |
BAIL - ORANGE Price: $49.99 |
| 10 |
741-04549 |
Cone Bearing This part replaces 741-0373. Price: $17.28 |
| 11 |
539106755 |
HANDLE SIDE GRAY Price: $27.99 |
| 11 |
717-3127 |
RETAINER RING Not Available Price: |
| 12 |
539976526 |
GRIP Price: $2.99 |
| 12 |
726-0216 |
EXPANSION PLUG Not Available Price: |
| 13 |
539106770 |
LEVER, PLATED Price: $39.99 |
| 13 |
715-0146 |
DOWEL PIN 3/8 x 5/8 Not Available Price: |
| 14 |
596434201 |
Bolts This part replaces 539990637. Price: $3.99 |
| 14 |
936-0141 |
Spr. Wash. 7/16" I.D. This part replaces 736-0141. Price: $6.01 |
| 15 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 15 |
710-0850 |
HEX SCREW 7/16-14X2.5 Not Available Price: |
| 16 |
539976438 |
COMPRESSION SPRING Price: $3.99 |
| 16 |
736-0226 |
Washer, Flat, .46 x .875 x .060 Thk Price: $3.64 |
| 17 |
596564401 |
Bolts This part replaces 539990563. Price: $3.99 |
| 17 |
710-3238 |
SCREW 7/16-14X1.75 GR5 Not Available Price: |
| 18 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 19 |
539102563 |
LANYARD Price: $7.99 |
| 20 |
539106768 |
HEIGHT ADJUSTMENT PLATE Price: $54.99 |
| 20 |
717-3097 |
SHIM, BEARING RETAINER, .004 Not Available Price: |
| 21 |
539108068 |
BLT 3/8-16 X 1/2 BTN HD BLK SP Price: $2.99 |
| 21 |
717-3098 |
SHIM, BEARING RETAINER, .007 Not Available Price: |
| 22 |
539108746 |
NUT 3/8-16 ACORN HEX Price: $2.99 |
| 22 |
717-3099 |
Shim, Bearing Retainer, .014 Thk Price: $32.65 |
| 23 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 23 |
717-3100 |
SHIM .028 Not Available Price: |
| 25 |
941-3039 |
ROLLER BEARING CUP This part replaces 741-3039. Price: $19.61 |
| 27 |
727-3096 |
BLADE ASSY, DIPSTICK Not Available Price: |
| 28 |
703-0833 |
BRACKET-TRANS MTG (LH) Not Available Price: |
| 29 |
703-0832 |
BRACKET-TRANS MTG (RH) Not Available Price: |
| 30 |
710-3118 |
Bolt, Hex Patch, 3/8-16 x 1.0 LG GR5 Price: $4.77 |
