| Ref | Part Number | Description |
|---|
| 1 |
850724 |
SUB= 155890 Price: Call Us |
| 3 |
851708X479 |
SUB= 145640X479 Price: Call Us |
| 4 |
63601 |
SUB= 73800400 Price: Call Us |
| 6 |
85723 |
WASHER PM Price: Call Us |
| 8 |
86055 |
SUB= 144929 Price: Call Us |
| 010 |
112-7018 |
VALVE-INLET This part replaces 98-9494. Price: $41.87 |
| 10 |
83816 |
SCREW PM Price: Call Us |
| 11 |
213146 |
CABLE CLAMP Price: Call Us |
| 12 |
48137 |
SUB= 91848137 Price: Call Us |
| 13 |
750097 |
TAPPING SCREW Price: Call Us |
| 14 |
87930 |
GUIDE CLIP PM Price: Call Us |
| 16 |
74100412 |
SCREW Price: Call Us |
| 17 |
107339X |
DECAL HYT Price: Call Us |
| 18 |
86344 |
SCREW PM Price: Call Us |
| 19 |
73510400 |
NUT Price: Call Us |
| 020 |
120-2564 |
VALVE-EXHAUST This part replaces 98-9495. Price: $34.21 |
| 20 |
84596 |
ENGINE.PULLEY.FWG Price: Call Us |
| 21 |
87677 |
HI PRO KEY PM Price: Call Us |
| 22 |
59708 |
SCREW Price: Call Us |
| 23 |
133040X479 |
REAR BAFFLE Price: Call Us |
| 24 |
128796 |
SUB= 140540 Price: Call Us |
| 25 |
700365X479 |
BAFFLE.SIDE Price: Call Us |
| 26 |
700360X479 |
PLATE.BACK Price: Call Us |
| 28 |
54583 |
SCREW Price: Call Us |
| 29 |
133190X479 |
DISCHARGE BAFFLE Price: Call Us |
| 030 |
98-9648 |
SPRING-VALVE Price: $13.49 |
| 30 |
132001 |
ROPE GUIDE Price: Call Us |
| 31 |
664-26 |
SUB= 7192J Price: Call Us |
| 32 |
132813X479 |
SUB= 151721X479 Price: Call Us |
| 33 |
131959 |
BOLT.HANDLE.LM Price: Call Us |
| 34 |
51793 |
HAIRPIN COTTER Price: Call Us |
| 35 |
77400 |
HUB CAP Price: Call Us |
| 36 |
85179 |
RETAINER CLIP PM Price: Call Us |
| 37 |
52160 |
WASHER Price: Call Us |
| 38 |
800390 |
SUB= 146247 Price: Call Us |
| 39 |
84921 |
SUB= 142748 Price: Call Us |
| 040 |
107-9092 |
RETAINER-SPRING This part replaces 98-9498. Price: $2.58 |
| 41 |
85021X004 |
AXLE ARM Price: Call Us |
| 42 |
700331X004 |
SPRING SELECTOR Price: Call Us |
| 43 |
87877 |
KNOB PM Price: Call Us |
| 44 |
700376 |
SUB= 700326X007 Price: Call Us |
| 45 |
84920 |
SUB= 146630 Price: Call Us |
| 46 |
700377 |
SUB= 700327X007 Price: Call Us |
| 47 |
55187 |
SCREW Price: Call Us |
| 050 |
117-7572 |
COLLET-SPRING, VALVE This part replaces 98-9390. Price: $9.43 |
| 50 |
700915X505 |
SUB= 150956 Price: Call Us |
| 51 |
700913X505 |
SUB= 150956 Price: Call Us |
| 52 |
751592 |
LOCKNUT PM Price: Call Us |
| 53 |
135030 |
DEBRIS SHLD RET Price: Call Us |
| 54 |
851201X004 |
WASHER Price: Call Us |
| 55 |
850998 |
SCREW Price: Call Us |
| 57 |
132255X479 |
SUB= 144964 Price: Call Us |
| 59 |
851084 |
SCREW Price: Call Us |
| 060 |
99-8385 |
SEAL-STEM, VALVE Price: $7.29 |
| 60 |
850263 |
LOCKWASHER Price: Call Us |
| 62 |
134768 |
SUB= 141114 Price: Call Us |
| 63 |
851514 |
ADAPTOR.BLADE.LM Price: Call Us |
| 64 |
701437 |
KIT.HSG.22RD.FWGD Price: Call Us |
| 68 |
88652 |
HINGE SCREW Price: Call Us |
| 69 |
133170X479 |
MULCHER PLATE Price: Call Us |
| 070 |
98-9497 |
CAP-VALVE Price: $8.36 |
| 080 |
105-3790 |
R-ARM SHAFT ASM Price: $28.61 |
| 090 |
100-1762 |
BOLT This part replaces 100-9265. Price: $1.68 |
| 100 |
98-9505 |
BRACKET-ARM, ROCKER Price: $22.17 |
| 110 |
98-7602 |
PIN-SPRING Price: $0.64 |
| 120 |
98-9507 |
WASHER-SHAFT, ROCKER ARM Price: $0.85 |
| 130 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 140 |
98-9504 |
SPRING-ARM, ROCKER Price: $0.66 |
| 160 |
98-9501 |
ROCKER ARM ASM Price: $28.78 |
| 170 |
98-9502 |
SCREW-ADJUSTING Price: $2.78 |
| 180 |
98-9503 |
NUT Price: $1.33 |
| 190 |
98-9506 |
STUD Price: $5.98 |
| 200 |
98-9393 |
NUT Price: $2.72 |
| 700480 |
"MANUAL,OP" |
Price: Call Us 700480 |
