| Ref | Part Number | Description |
|---|
| 1 |
186093X428 |
Wheel, Steering Price: Call Us |
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 2 |
195968 |
Axle Asm., Front Price: Call Us |
| 2 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 3 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 4 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 4 |
403087 |
Spindle Asm., LH Price: Call Us |
| 5 |
403088 |
Spindle Asm., RH Price: Call Us |
| 5 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 11 |
106-6895-03 |
BALL JOINT ASM This part replaces 69-9810-03. Price: $258.08 |
| 12 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 14 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 15 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 15 |
73540600 |
Nut, Crown Lock 3/8-24 unf Price: Call Us |
| 16 |
194746 |
Shaft Steering Price: Call Us |
| 16 |
82-9210 |
SHAFT-PIVOT Price: $187.73 |
| 19 |
194729 |
Plate Steering Price: Call Us |
| 19 |
60-3670 |
PIN Price: $12.56 |
| 20 |
199743X428 |
Boot, Steering Price: Call Us |
| 20 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 21 |
186737 |
Adapter, Wheel Steering Price: Call Us |
| 21 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 22 |
194845 |
Bushing, Strg. Blk Price: Call Us |
| 23 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 24 |
48-6660 |
WASHER Price: $5.22 |
| 25 |
48-6640 |
BEARING Price: $10.04 |
| 26 |
186095X428 |
Insert, Wheel Steering Price: Call Us |
| 28 |
17000612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 28 |
32136-13 |
NUT-SHH Price: $2.85 |
| 30 |
69-9870 |
WIDE WHEEL AND 6-PLY TIRE ASM Price: $513.71 |
| 32 |
110-9719-03 |
TIE ROD ASM This part replaces 82-9260-03. Price: $380.21 |
| 35 |
194732 |
Gear, Sector Plate Price: Call Us |
| 35 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 36 |
340-88 |
FITTING-STRAIGHT Price: $11.24 |
| 37 |
340-54 |
ELBOW-45 DEG Price: $40.72 |
| 44 |
104-5202 |
HOSE ASM Price: $114.43 |
| 45 |
104-5233 |
MOTOR-WHEEL Price: $2,275.70 |
| 45 |
19183812 |
Washer 9/16 ID x 2-3/8 x 12 Ga. Price: Call Us |
| 47 |
115-8015 |
CYLINDER-HYDRAULIC This part replaces 92-6057. Price: $905.66 |
| 48 |
92-4755-03 |
REAR AXLE ASM Price: $1,618.24 |
| 49 |
86-6560 |
WASHER-THRUST Price: $29.68 |
| 50 |
3274-5 |
SCREW-HSH Price: $4.00 |
| 50 |
73900600 |
Nut Lock 3/8-16 UNC Price: Call Us |
| 51 |
73940800 |
Nut Hex Jam Toplock 1/2-20 unf Price: Call Us |
| 51 |
92-4779-03 |
LH MOTOR HOUSING ASM Price: $969.47 |
| 52 |
92-4787-03 |
RH MOTOR HOUSING ASM Price: $739.13 |
| 53 |
188967 |
Washer Hardened .793 x 1.637 x .060 Price: Call Us |
| 53 |
92-4749-03 |
HUB-WHEEL Price: $96.67 |
| 54 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 54 |
74760636 |
Bolt Hex 3/8-16 UNC x 2-1/4 Price: Call Us |
| 55 |
197636 |
Spacer Brace Axle Price: Call Us |
| 55 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 56 |
92-5698 |
HOSE ASM Price: $262.64 |
| 57 |
407465 |
Bracket Upstop Price: Call Us |
| 57 |
92-5688 |
HOSE ASM Price: $119.23 |
| 58 |
194747 |
Bolt Shoulder Sector Pivot CFM Price: Call Us |
| 58 |
92-5686 |
HOSE ASM Price: $275.50 |
| 59 |
194748 |
Washer Thrust Sector Steering Price: Call Us |
| 59 |
340-70 |
NUT-LOCK Price: $2.10 |
| 60 |
340-117 |
CAP Price: $10.30 |
| 60 |
73971000 |
Nut Flange Lock 5/8-11 Price: Call Us |
| 61 |
194740 |
Draglink LH Price: Call Us |
| 61 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 62 |
194741 |
Draglink, RH Price: Call Us |
| 62 |
323-4 |
SCREW-HH Price: $1.02 |
| 63 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 63 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 64 |
199849 |
Retainer Clip Spring Steering Price: Call Us |
| 64 |
340-115 |
FITTING-TEE, SWIVEL NUT Price: $56.09 |
| 65 |
194734 |
Brace Axle Front Price: Call Us |
| 65 |
92-5665 |
HOSE ASM Price: $72.72 |
| 66 |
71020748 |
Bolt Hex Fghd 7/16-14 x 3 Serr Price: Call Us |
| 66 |
83-2720 |
BOLT-LUG Price: $3.69 |
| 67 |
194737 |
Bushing PM Front Axle Price: Call Us |
| 67 |
340-14 |
FITTING-HYD, 45 DEG Price: $42.29 |
| 68 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 68 |
94-8271 |
TRACTION HOSE ASM Price: $127.83 |
| 69 |
199162 |
Washer 1.5 x .505 x .118 Price: Call Us |
| 69 |
94-8272 |
TRACTION HOSE ASM Price: $114.06 |
| 70 |
340-76 |
FITTING-BULKHEAD UNION, STRAIGHT Price: $37.98 |
| 71 |
94-8277-03 |
BRACKET-BULKHEAD Price: $41.95 |
| 72 |
94-8275 |
INNER TUBE ASM Price: $301.27 |
| 73 |
94-8276 |
OUTER TUBE ASM Price: $301.27 |
| 74 |
94-8278 |
CASE DRAIN TUBE ASM Price: $83.72 |
| 75 |
3210-7 |
SCREW-HH Price: $0.61 |
