| Ref | Part Number | Description |
|---|
| 1 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 1 |
601505147 |
COVER, TOP Price: $191.99 |
| 2 |
601400002 |
SCREW, 10-24X.50 WAHH Price: $4.99 |
| 2 |
98-4517 |
AIR CLEANER ASM Price: $272.15 |
| 3 |
601505148 |
NUT, 1/4-10 SPEED J-TYPE Price: $8.99 |
| 3 |
93-6692 |
DISCONTINUED Price: Call Us |
| 4 |
48-7430 |
PRECLEANER Price: $50.85 |
| 4 |
601505149 |
SCREW 1/4-14 X .75 Price: $6.99 |
| 5 |
601002153 |
BEARING, FLANGED Price: $8.99 |
| 5 |
98-4578-03 |
BRACKET-FILTER, FUEL Price: $35.38 |
| 6 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 6 |
601505152 |
SCREW 1/4-20 X 1.00 Price: $6.99 |
| 7 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 7 |
601400080 |
WASHER, FLAT .281X.63 Price: $4.99 |
| 8 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 8 |
601505153 |
NUT #10-24 HEX CONTROL LOCK Price: $2.99 |
| 9 |
32128-33 |
NUT-HF Price: $0.25 |
| 9 |
601505154 |
NUT 1/4-20 HEX CONTROL LOCK Price: $3.99 |
| 10 |
601505133 |
SCREW 1/4-20X.75 Price: $2.99 |
| 10 |
98-4525 |
BRACKET-CLEANER, AIR Price: $52.87 |
| 11 |
322-4 |
SCREW-HH Price: $0.35 |
| 11 |
601505156 |
AUGER HOUSING ASSEMBLY Price: $219.99 |
| 12 |
601400073 |
SCREW .25-20X0.62 HHC Price: $5.99 |
| 12 |
66-2750 |
DISCONTINUED Price: Call Us |
| 13 |
104-0086 |
CABLE-BATTERY, POSITIVE Price: $78.07 |
| 13 |
601001798 |
AUGER ASSY COMP 21" This part replaces 601505157. Price: $220.99 |
| 14 |
323-9 |
SCREW-HH Price: $1.29 |
| 14 |
601505158 |
BLADE, SCRAPER Price: $69.99 |
| 15 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 15 |
601400074 |
PLATE & BEARING ASY Price: $29.99 |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
601001381 |
RETAINER, BRNG Price: $5.99 |
| 17 |
138-6335 |
RETAINER-BATTERY This part replaces 66-2490. Price: $10.49 |
| 17 |
601400086 |
NUT .25-20 HEX CTRLOCK Price: $6.99 |
| 18 |
601002087 |
SPACER, SLEEVE Price: $4.99 |
| 18 |
94-7343 |
BASE-BATTERY Price: $118.61 |
| 19 |
601002095 |
PULLEY, RIBBED 6" OD Price: $54.99 |
| 19 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 20 |
601505159 |
COVER, BELT Price: $42.99 |
| 20 |
93-7276 |
DECAL-DANGER Price: $15.13 |
| 21 |
32128-20 |
NUT-HF Price: $0.99 |
| 21 |
601505160 |
COVER, BOTTOM Price: $59.99 |
| 22 |
601400076 |
KEY SET - 691959 Price: $24.99 |
| 22 |
98-4576-03 |
BRACKET-RESERVOIR, WATER Price: $43.21 |
| 23 |
321-5 |
SCREW-HH Price: $0.22 |
| 23 |
601000111 |
NUT, 5/8-32 IGN SWIT PLA Price: $4.99 |
| 24 |
601400044 |
WASHER .640X1.1X.05 Price: $6.99 |
| 24 |
93-9164 |
INDICATOR-MINI Price: $55.24 |
| 25 |
601505189 |
BULB, PRIMER Price: $22.99 |
| 25 |
98-4518-03 |
BRACKET-CLEANER, AIR Price: $75.61 |
| 26 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 26 |
601000102 |
NUT, 1/4-20 REGHEXKEPS Price: $2.99 |
| 27 |
601001358 |
SWITCH Price: $27.99 |
| 27 |
94-1416 |
ADAPTER-INDICATOR Price: $11.87 |
| 28 |
601505165 |
HOSE, PRIMER 9.5" Price: $2.99 |
| 28 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 29 |
601505166 |
PANEL, CONTROL Price: $38.99 |
| 29 |
92-2379 |
CLAMP-HOSE Price: $0.34 |
| 30 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 30 |
601400070 |
GROMMET AND WASHER, ROP Price: $6.99 |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 31 |
601505140 |
STARTER ROPE GRIP Price: $20.99 |
| 32 |
108-0638 |
BOTTLE-OVERFLOW This part replaces 98-9323. Price: $33.20 |
| 32 |
601505168 |
PANNEL ACCESS Price: $24.99 |
| 33 |
601505169 |
SCREW 1/4-20 X 1.25 Price: $2.99 |
| 33 |
98-4509 |
HOSE-CLEANER, AIR Price: $97.00 |
| 34 |
98-9305 |
WATER / FUEL FILTER ASM Price: $116.51 |
| 35 |
353-783 |
FITTING-STR Price: $29.05 |
| 36 |
322-6 |
SCREW-HH Price: $0.45 |
| 37 |
106-1126 |
HOSE-FUEL This part replaces 71-3381. Price: $10.06 |
| 38 |
110-4107 |
HOSE-FUEL This part replaces 95-4275. Price: $7.77 |
| 39 |
2412-108 |
CLAMP-WORM Price: $1.29 |
