| Ref | Part Number | Description |
|---|
| 2 |
23-2780 |
PLOW WA *R Price: $1,543.43 |
| 2 |
530042088 |
Muffler Spring Price: $1.99 |
| 3 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 3 |
530071391 |
Kit-Spark Arrestor Price: $7.99 |
| 4 |
3217-7 |
NUT-HEX Price: $0.28 |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 5 |
20-9420-01 |
COMP SPRING This part replaces 20-9420. Price: $106.49 |
| 5 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 6 |
23-2760 |
SPRING MOUNT WA *R Price: $94.93 |
| 6 |
530012353 |
CYLINDER This part replaces 530069619. Price: $6.99 |
| 7 |
23-2740 |
PIN-ACTUATING Price: $94.46 |
| 7 |
530069616 |
Gasket-Cyl./Carb. (kit) Price: $6.99 |
| 8 |
23-2770 |
ROD-ACTUATING Price: $97.95 |
| 8 |
530047659 |
Carb. Adaptor Price: $2.99 |
| 9 |
23-2790-01 |
BLADE-SCRAPER This part replaces 23-2790. Price: $323.46 |
| 9 |
530016014 |
Screw Price: $1.99 |
| 10 |
530069616 |
Gasket-Carb.(kit) Price: $6.99 |
| 10 |
67-1300 |
DECAL This part replaces 18-6900. Price: $29.99 |
| 11 |
323-7 |
SCREW-HH Price: $0.65 |
| 12 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 12 |
530038747 |
Choke Plate Mounting Price: $1.99 |
| 13 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 13 |
530038686 |
Choke Shutter Price: $1.99 |
| 14 |
283-40 |
PIN-CLEVIS Price: $2.85 |
| 14 |
530052431 |
Air Box Price: $1.99 |
| 15 |
23-2750 |
SCARIFIER 43 FIN *R Price: $779.94 |
| 15 |
530015887 |
Screw Price: $1.99 |
| 16 |
23-2810 |
LH ANCHOR WA Price: $274.79 |
| 16 |
530036569 |
Plate-Filter Support Price: $1.99 |
| 17 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 17 |
530036575 |
Air Filter Foam Price: $1.99 |
| 18 |
23-2710 |
MOUNT WA *R Price: $594.78 |
| 18 |
530036568 |
Air Filter Cover Price: $1.99 |
| 19 |
23-2680 |
LIFT ARM WA *R Price: $759.10 |
| 19 |
530015880 |
Screw Price: $1.99 |
| 20 |
323-5 |
SCREW-HH Price: $0.41 |
| 20 |
530015852 |
Spacer-Choke Price: $1.99 |
| 21 |
23-2690 |
RH ANCHOR WA Price: $254.05 |
| 21 |
530015254 |
Washer Price: $1.99 |
| 22 |
23-2730 |
LOCK COLLAR Price: $61.42 |
| 23 |
3246-1 |
SCREW-SET Price: $6.24 |
| 23 |
530036404 |
Piston Ring Price: $4.99 |
| 24 |
23-2720 |
ADJ SLEEVE WA *R Price: $213.57 |
| 24 |
530015162 |
Piston Pin Retainer Price: $1.99 |
| 25 |
3217-11 |
NUT-HEX Price: $0.95 |
| 25 |
530069615 |
Connecting Rod Ass'y. Price: $14.99 |
| 26 |
256-237 |
BUSHING Price: $14.99 |
| 26 |
530069616 |
Gasket-Cylinder (kit) Price: $6.99 |
| 27 |
530055160 |
Ignition Module Price: $34.99 |
| 28 |
530016357 |
Screw Price: $1.99 |
| 29 |
581425901 |
SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 30 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 32 |
530016381 |
Screw-Nose Cone Price: $2.99 |
| 33 |
530016382 |
Nut-Nose Cone Price: $2.99 |
| 34 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 35 |
530071356 |
Kit-On/Off Switch Price: $4.99 |
| 36 |
530027569 |
Starter Handle Price: $1.99 |
| 37 |
530069232 |
Kit-Rope Price: $3.99 |
| 38 |
530016080 |
Screw Price: $1.99 |
| 39 |
530038604 |
Drive Coupling Price: $1.99 |
| 40 |
530023817 |
Starter Dog Spring Price: $1.99 |
| 41 |
530015941 |
Retain. Ring-C'shaft Price: $1.99 |
| 42 |
530055728 |
Outer Bearing Price: $6.99 |
| 43 |
530071615 |
Kit-C'case Seal Price: $4.99 |
| 44 |
530032125 |
Inner Bearing Price: $11.99 |
| 45 |
530069685 |
Assy.-Fan Hsg/Shroud Price: $22.99 |
| 46 |
530015886 |
Screw Price: $1.99 |
| 47 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 48 |
530054536 |
Guard-Muffler Price: $1.99 |
| 50 |
530054753 |
Assy-Crankshaft Price: $27.99 |
| 53 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 54 |
530015828 |
Washer-Flat Price: $1.99 |
| 55 |
530015775 |
Screw Price: $1.99 |
| 56 |
530027523 |
Retainer-Can Price: $2.99 |
| 58 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 59 |
530069685 |
Kit-Fan Hsg/Shroud Price: $22.99 |
| 61 |
530016379 |
Retainer Price: $2.99 |
| 62 |
530014347 |
Assy-Fuel Cap Price: $4.99 |
| 63 |
530095646 |
Assy-Fuel Pickup Price: $2.99 |
| 64 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 65 |
530069216 |
Kit-Fuel Line (Large Price: $3.99 |
