| Ref | Part Number | Description |
|---|
| 1 |
140-5560 |
FULL REAR ROLLER(2.0IN DIA)(21IN) This part replaces 119-4093. Price: $291.30 |
| 1 |
530015899 |
Screw Price: $1.99 |
| 2 |
119-4166 |
SPACER-HEIGHT, ROLLER Price: $6.17 |
| 2 |
530095646 |
Assy-Fuel Pickup This part replaces 530014199. Price: $2.99 |
| 3 |
119-4157 |
RETAINER-SHAFT Price: $6.03 |
| 3 |
530001543 |
Nut Price: Call Us |
| 4 |
119-4165 |
SHIM-HEIGHT, ROLLER Price: $4.02 |
| 4 |
530069247 |
Fuel Line Price: $3.99 |
| 5 |
119-4035 |
SCREW-HSH Price: $1.00 |
| 5 |
545057701 |
Filter-Air This part replaces 530036141. Price: $2.99 |
| 6 |
119-4040 |
NUT-FLANGE, NI Price: $0.52 |
| 6 |
530015970 |
Screw Price: $1.99 |
| 7 |
140-5691 |
BRACKET-GR FRONT HOC This part replaces 115-7041. Price: $20.85 |
| 7 |
530059738 |
Filter-Air This part replaces 530037478. Price: $7.99 |
| 8 |
110-7352 |
SCREW-HOC Price: $17.51 |
| 8 |
530071987 |
CARBURETOR W-29 This part replaces 530035291. Price: $29.99 |
| 9 |
530071654 |
Kit-Carb.-Adapter This part replaces 530037668. Price: $17.99 |
| 9 |
99-3773 |
BOLT-PLOW Price: $10.65 |
| 10 |
48-9220 |
WASHER-PLAIN This part replaces 119-4158. Price: $0.87 |
| 10 |
530037464 |
Carb. Grommet This part replaces 530037530. Price: $1.99 |
| 11 |
133-7570 |
NUT-FLANGE, NI This part replaces 115-7193. Price: $0.45 |
| 11 |
530015814 |
Screw-Line Limiter This part replaces 530015905. Price: $1.99 |
| 12 |
119-4067 |
SCREW-HH Price: $0.81 |
| 12 |
530053396 |
Carb. Adaptor This part replaces 530037667. Price: $2.99 |
| 13 |
545199901 |
IGNITION MODULE This part replaces 530039143. Price: $22.99 |
| 14 |
530019203 |
Turbo Clean Seal Price: $1.99 |
| 15 |
530029813 |
Turbo Air Cleaner Ass'y. Price: $1.99 |
| 16 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 17 |
530016154 |
Screw This part replaces 530015903. Price: $0.99 |
| 18 |
530036088 |
Cylinder Shield Price: $3.33 |
| 19 |
530015406 |
Screw Price: $1.99 |
| 20 |
530027181 |
Handguard Price: $3.33 |
| 22 |
530015895 |
Screw Price: $1.99 |
| 23 |
530037467 |
Switch Wire Ass'y. Price: $19.99 |
| 24 |
530015897 |
Screw Price: $1.99 |
| 25 |
530016170 |
Muffler Bolt This part replaces 530015938. Price: $1.99 |
| 26 |
530037249 |
Muffler Cover Price: $3.99 |
| 27 |
530036103 |
Spark Screen Price: Call Us |
| 28 |
530037813 |
Diffuser Price: $1.99 |
| 29 |
530015902 |
Bolt Price: $1.99 |
| 30 |
530037728 |
Muffler Body Price: $5.99 |
| 31 |
530037380 |
Piston Ring Price: $2.99 |
| 32 |
530015697 |
Piston Pin Retainer Price: $1.99 |
| 33 |
530014943 |
C'case & Cylinder Assy Price: Call Us |
| 34 |
503920801 |
ASSY-CRANKSHAFT & ROD This part replaces 530029794. Price: $129.99 |
| 35 |
530032117 |
Piston Pin Bearing Price: $4.99 |
| 37 |
530019170 |
C'shaft Seal Price: $1.99 |
| 38 |
530032118 |
C'shaft Bearing Price: Call Us |
| 39 |
530019205 |
Muffler Gasket Price: $1.99 |
| 40 |
530037640 |
Muffler Plate Price: $1.99 |
| 41 |
530037652 |
Heat Insulator Price: $1.99 |
