| Ref | Part Number | Description |
|---|
| 1 |
984-04037 |
Chute Assembly This part replaces 684-04037. Price: $70.39 |
| 2 |
710-04071 |
Carriage Bolt 5/16-18 x 1.0" Price: $3.94 |
| 3 |
710-0451 |
Carriage Bolt 5/16-18 x 0.750" Price: $3.53 |
| 4 |
712-04063 |
Flange Lock Nut, 5/16-18 Price: $3.56 |
| 5 |
720-0284 |
Chute Knob Assembly Price: $4.08 |
| 6 |
731-04388A |
Chute Handle Price: $23.54 |
| 7 |
731-04426C |
UPPER CHUTE (W/LBL MANUAL TILT) This part replaces 731-04426A. Price: $17.04 |
| 8 |
736-0159 |
Washer Price: $3.71 |
| 9 |
712-04064 |
Flange Lock Nut, 1/4-20 Price: $3.64 |
| 10 |
931-2636A |
Chute Adapter 5" Dia. This part replaces 731-2636A. Price: $18.43 |
| 11 |
710-0134 |
Carriage Screw 1/4-20 x 0.62" Price: $3.71 |
| 12 |
931-2643 |
Chute Cleanout Tool This part replaces 731-2643. Price: $16.68 |
| 13 |
725-0157 |
Cable Tie Price: $3.46 |
| 14 |
731-11421 |
Cleanout Tool Mount This part replaces 731-2635. Price: $9.83 |
| 15 |
931-04353 |
Lower Chute Ring This part replaces 731-04353. Price: $16.59 |
| 16 |
710-0451 |
Carriage Bolt 5/16-18 x 0.75" Price: $3.53 |
| 17 |
931-04127 |
Lower Chute, 5inch Diameter This part replaces 731-04127. Price: $29.43 |
| 18 |
932-04111 |
Chute Adjustment Spring This part replaces 732-04111. Price: $4.11 |
| 19 |
731-06439 |
SLIDE SHOE (POLYMER SMALL) Price: $18.94 |
| 20 |
731-04870 |
Spacer, 1.25OD x .75ID x 1.00Lg. Price: $4.06 |
| 21 |
710-0726 |
AB Screw 5/16-12 Price: $3.82 |
| 22 |
738-04124A |
Shear Pin, .25 x 1.50 This part replaces 738-04124. Price: $1.56 |
| 23 |
790-00120 |
Shave Plate Price: $27.34 |
| 24 |
950-04191 |
Spacer, .76 ID x 1.16 OD x .25 This part replaces 750-04191. Price: $5.32 |
| 25 |
731-04218B |
Impeller This part replaces 731-04218A. Price: $72.15 |
| 26 |
917-1772A |
WORM SHAFT Not Available This part replaces 717-1772A. Price: |
| 27 |
715-04020 |
Spiral Pin Price: $10.52 |
| 28 |
721-0327 |
Oil Seal Price: $6.10 |
| 29 |
741-0662 |
Flange Bearing Price: $9.52 |
| 30 |
736-3084 |
Flat Washer, .51 x 1.12 x.06 Price: $4.39 |
| 31 |
715-04021 |
Spiral Pin Price: $3.68 |
| 32 |
721-0325 |
Plug Price: $3.82 |
| 33 |
718-04071 |
Thrust Collar Price: $6.73 |
| 34 |
714-04040 |
Bow Tie Cotter Pin Price: $1.28 |
| 35 |
741-0663 |
Flange Bearing Price: $8.86 |
| 36 |
914-0161 |
KEY 3/16 x 5/8 H This part replaces 714-0161. Price: $3.82 |
| 37 |
917-04861 |
WORM GEAR 20T This part replaces 717-0528A. Price: $37.82 |
| 38 |
736-0351 |
Flat Washer Price: $3.93 |
| 40 |
918-0123A |
REDUCER HOUSING ASSEMBLY (RH) This part replaces 618-0123. Price: $46.04 |
| 40 |
918-0418A |
Housing Assembly, LH This part replaces 618-0418. Price: $54.72 |
| 41 |
710-0642 |
TT Screw 1/4-20x 0.75" Price: $4.05 |
| 42 |
918-04196 |
GEARBOX ASSEMBLY 24" Not Available This part replaces 618-04196. Price: |
| 43 |
684-04113A |
Auger Assembly - LH This part replaces 684-04113. Price: $61.80 |
| 43 |
684-04114A |
Auger Assembly - RH This part replaces 684-04114. Price: $61.80 |
| 44 |
790-00138A-0637 |
BEARING HOUSING 1" HEX Not Available This part replaces 790-00138. Price: |
| 45 |
941-0245 |
Hex Flange Bearing, .75 ID This part replaces 741-0245. Price: $9.07 |
| 47 |
741-0493C |
FLANGE BUSHING This part replaces 741-0493A. Price: $3.86 |
| 48 |
736-0351 |
Flat Washer Price: $3.93 |
